Message Area

The oscilloscope displays a message area (item number 15 in the
previous figure) at the bottom of the screen that conveys the
following types of helpful information:
H Directions to access another menu, such as when you push the
TRIG MENU button:
For TRIGGER HOLDOFF, go to HORIZONTAL Menu
H Suggestion of what you might want to do next, such as when you
push the MEASURE button:
Push an option button to change its measurement
H Information about the action the oscilloscope performed, such as
when you push the DEFAULT SETUP button:
Default setup recalled
H Information about the waveform, such as when you push the
AUTOSET button:
Square wave or pulse detected on CH1
