Using Autoset

To quickly display a signal, follow these steps:
1. Push the CH 1 MENU button.
2. Push Probe
3. Set the switch to 10X on the P2220 probe.
4. Connect the channel 1 probe tip to the signal. Connect the
reference lead to the circuit reference point.
5. Push the AUTOSET button.
The oscilloscope sets the vertical, horizontal, and trigger controls
automatically. If you want to optimize the display of the waveform,
you can manually adjust these controls.
NOTE. The oscilloscope displays relevant automatic measurements in
the waveform area of the screen based on the signal type detected.
For oscilloscope-specific descriptions, refer to page 9- - 10 in the
Reference chapter.

Taking Automatic Measurements

The oscilloscope can take automatic measurements of most
displayed signals. To measure signal frequency, period, and
peak-to-peak amplitude, rise time, and positive width, follow these
steps:
1. Push the MEASURE button to see the Measure Menu.
TPS2000 Series Digital Oscilloscope User Manual
Voltage Attenuation
Application Examples
10X.
4- 3
