Removable Mass Storage
To remove a CF card, follow these steps:
1. Push and release the eject button until the button fully extends.
2. Push the eject button again to release the card from the slot.
3. Pull the CF card out of the front-panel slot.

CF Card Initial Read Time

The oscilloscope reads the internal structure of a CF card each time
you insert a card. The time to complete the read depends on the size
of the CF card and how it is formatted.
To significantly shorten the initial read time of 64 MB and larger CF
cards, format the CF card in the oscilloscope.

Formatting a CF Card

The Format function deletes all data on the CF card. To format a CF
card, follow these steps:
1. Insert a CF card into the CF card slot.
2. Push the UTILITY button to see the Utility Menu.
3. Push File Utilities
4. Select Yes to format the CF card.
7- 2
More
TPS2000 Series Digital Oscilloscope User Manual
Format.
