Tektronix TPS2000 Series User Manual page 282

Index
probe terminal, 1- - 15
terminal, 2- - 16
Reference lead, isolated channel
connections, 1- - 6
Reference waveforms
readout, 2- - 4
removing, 9- - 35
saving and recalling, 9- - 36
Remote control using RS- - 232
interface, 6- - 5
Removable memory storage, 7- - 1
Removing waveforms, 9- - 52
Renaming files or folders, 9- - 51
Replace battery packs, 8- - 11
Resolution, fine, 9- - 54
Rise time measurements
automatic, 9- - 27
using cursors, 4- - 17
RLE file format, 6- - 4
RMS measurements, 9- - 26
Roll mode. See scan mode
RS- - 232 port, 6- - 2
cable part numbers, 6- - 6
connecting a cable, 6- - 6
connector pinout, 6- - 12
setup, 6- - 5
RS- - 232 protocol
Break signals, 6- - 11
I/O errors, 6- - 11
setup options, 6- - 7
testing, 6- - 8
troubleshooting, 6- - 9
RUN/STOP button, 2- - 14, 9- - 5
steps taken by the oscilloscope
when pushed, 3- - 4
S
Safety summary, vii
Index- 10
TPS2000 Series Digital Oscilloscope User Manual
Sample acquisition mode, 3- - 7, 9- - 2,
9- - 3
Sample mode, icon, 2- - 3
Sample rate, maximum, 9- - 3
Save, setups, 3- - 2
Save All menu, 9- - 29
Save Image menu, 9- - 30
Save Setup menu, 9- - 31
SAVE to a CompactFlash card,
2- - 14
Save Waveform menu, 9- - 32
SAVE/RECALL button, 2- - 13
Save/Recall menu, 9- - 28
Saving
All files to a CF card, 7- - 4
image files to a CF card, 7- - 7
setups, 9- - 35
waveforms, 9- - 36
Scale
current probe, 1- - 20, 9- - 53
horizontal, 3- - 8
vertical, 3- - 8
Scaling waveforms, basic concepts,
3- - 8
Scan mode, 9- - 6, 9- - 22
Scanning waveforms, 9- - 22
Screen buttons, xv
Screen data
saving to a file, 7- - 7
sending to a printer, 6- - 5
sending to an external device,
6- - 5
SEC/DIV control, 2- - 10, 9- - 22
SECAM video standard, 9- - 41
Security lock, 1- - 12
Self calibration, 1- - 20
Service
battery packs, 8- - 1
error log as a reference, 9- - 47
