Likewise, if the oscilloscope has two battery packs installed, it will
operate from the battery pack with the lowest available capacity until
it reaches full discharge. The oscilloscope will then operate from the
second battery pack until it reaches full discharge.
To charge a battery pack in the oscilloscope, follow these steps:
1. Place the battery pack in the battery compartment. See page 1- - 8
for instructions.
2. Apply external power from the oscilloscope AC adaptor. The
green, BATTERY CHARGING indicator on the front panel lights
and the battery pack begins to charge immediately.

External Charge

You can use the optional TPSCHG battery charger (see Optional
Accessories, page B- - 2 ) to externally charge battery packs. For
complete information, refer to the manual for the external charger.
To use the external charger, follow these steps:
1. Place up to two battery packs in the charger slots. Battery packs
are keyed, so you can insert them only one way.
2. The battery packs begin to charge immediately.
LEDs indicate which battery pack is being charged, the status of
the charge, and when the charge is complete.
TPS2000 Series Digital Oscilloscope User Manual
Managing TPSBAT Battery Packs
8- 7
