Rear Brake Calipers - Yamaha YXR70FX Service Manual

EBS00424

REAR BRAKE CALIPERS

3
2
New
1
27 Nm (2.7 m kg, 19 ft
•
Order
Removing the rear brake calipers
Brake fluid
Rear wheel
1 Union bolt
2 Copper washer
3 Rear brake hose
4 Brake pad holding bolt
5 Rear brake caliper bolt
6 Rear brake caliper assembly
FRONT AND REAR BRAKES
6
Ib)
•
17 Nm (1.7 m
•
Job/Part
8 - 32
4
kg, 12 ft Ib)
•
Q'ty
Remove the parts in the order listed.
The following procedure applies to both
of the rear brake calipers.
Drain.
Refer to "FRONT AND REAR WHEELS".
1
2
1 Disconnect.
2 Loosen.
2
1
For installation, reverse the removal pro-
cedure.
CHAS
5
48 Nm (4.8 m kg, 35 ft Ib)
• •
Remarks
Refer to "INSTALLING
THE FRONT AND REAR
BRAKE CALIPERS".
5
