THROTTLE BODY

10
9
11
Order
Removing the throttle body
Seats/rear console
1 Intake air pressure sensor coupler
2 Throttle position sensor coupler
3 Throttle body breather hose
4 Fuel injector coupler
5 ISC (idle speed control) unit coupler
6 Throttle cable housing cover
7 Throttle cable
4
12
9
3
7
LS
13 11
Job/Part
6 - 37
THROTTLE BODY
8
1
2
New
6
5
Q'ty Remarks
Remove the parts in the order listed.
Refer to "SEATS, REAR CONSOLE AND
INSTRUMENT PANELS" in chapter 8.
1 Disconnect.
1 Disconnect.
1
1 Disconnect.
1 Disconnect.
1
1 Disconnect.
FI
