Transmission - Yamaha YXR70FX Service Manual

EBS00345

TRANSMISSION

New
Order
Removing the transmission
Crankcase
Middle driven gear
1 Shift drum
2 Shift fork assembly
3 Shift fork "R"
4 Spring
5 Shift fork "L"
6 Shift fork guide bar
7 Secondary shaft
8 Drive axle assembly
9 Reverse idle gear
E
1
New
8
2
Job/Part
4 - 83
TRANSMISSION
5
4
3
New
Q'ty Remarks
Remove the parts in the order listed.
Separate.
Refer to "CRANKCASE".
Refer to "MIDDLE GEAR".
1
1
1
1 Refer to "ASSEM-
BLING THE
1
SHIFT FORK
1
ASSEMBLY".
1
1
1
ENG
New
6
E
Refer to "REMOV-
ING THE TRANS-
MISSION" and
"INSTALLING THE
TRANSMISSION".
