REAR CONSTANT VELOCITY JOINTS, FINAL DRIVE
Order
Disassembling the final gear case
1
Final drive pinion gear assembly
2
Final drive pinion gear shim
3
Drive shaft coupling gear
4
Final drive pinion gear
5
Inner race
6
Oil seal
7
Bearing retainer
8
Bearing
9
Final drive pinion gear bearing housing
0
Ring gear stopper
GEAR AND DRIVE SHAFT
Job/Part
7 - 25
Q'ty
Remarks
Remove the parts in the order listed.
1
*
1
1
Refer to "DISASSEMBLING THE
1
FINAL GEAR CASE" and "ASSEM-
BLING THE FINAL GEAR CASE".
1
1
1
1
1
DRIV
