EBS00327
OIL PUMP
1
5 Nm (0.5 m
Order
Disassembling the oil pump
1
Oil pump housing cover
2
Pin
3
Oil pump shaft
4
Oil pump inner rotor
5
Oil pump outer rotor
6
Oil pump housing
CRANKSHAFT AND OIL PUMP
2
5
4
kg, 3.6 ft
Ib)
•
•
Job/Part
4 - 78
6
3
E
E
Q'ty
Remove the parts in the order listed.
1
1
1
1
1
1
For assembly, reverse the disassembly
procedure.
ENG
Remarks
