D Settings for "UR" and "R2," depending on the communication form

Destination: CQ
<Communication form: Local area call>
• UR setting: CQCQCQ
• R2 setting : NOT USE✱
<Communication form: Zone call>
• UR setting: CQCQCQ
• R2 setting : Destination repeater to send CQ in
the same zone
<Communication form: Gateway call>
• UR setting: Destination repeater to send CQ
• R2 setting : Your gateway repeater
NOTE: R1 setting is set to your access repeater's call sign.
CQ
CQ
CQ
DV MODE OPERATION
Destination: An individual station
<Communication form: Local area call>
• UR setting: An individual station
• R2 setting : NOT USE✱
<Communication form: Zone call>
• UR setting: An individual station
• R2 setting : Destination repeater in the same
zone
<Communication form: Gateway call>
• UR setting: An individual station
• R2 setting : Your gateway repeater
