Gateway r epeater call sign programming
4.
When the repeater that was programmed in the pre-
vious item has its own gateway capability, skip this
setting and go to the next item. If the programmed
repeater uses a different gateway repeater, program
gateway repeater's call sign as described below.
!8 Push [Z](F-2) to display the "GW" item (Gateway
Repeater Call Sign).
• The programmed repeater's call sign is displayed, and
"G" is automatically added as, or overwrites, the 8th
digit.
RP–L G W : JP3YHH G
Ù Ú
!9 Push [EDT](F-4) to enter the repeater call sign pro-
gramming mode.
• A cursor appears and blinks.
@0 Push [Ω](F-2) or [≈](F-3) to select the character to
program.
@1 Rotate [MAIN DIAL] to select the first character or
symbol ('/' only) to input.
When inputting numbers, push the appropriate key-
pad key.
• Push [DEL](F-4) to delete the selected character, sym-
bol or number.
• Push [SPC](F-5) to input a space.
• When all 8 characters have been programmed, an error
beep sounds. If you want to reprogram, push [Ω](F-2) or
[≈](F-3) to select a character, then push [DEL](F-4) to
delete it.
@2 Repeat steps @0 through @1 to program a repeater
call sign of up to 8 characters.
• The 8th digit must be "G."
• For repeaters in a zone with no gateway, enter a com-
mon name or call sign, up to 7 digits, in all their gateway
repeater cells. The 8th digit must be blank.
@3 Push [MENU] to save the programmed call sign.
epeater group programming
5. R
The IC-9100 has a total of 10 groups (0–9). You can
assign and organize up to 500 repeaters in the 10
groups. Group selection is helpful for quick recall of a
desired repeater.
@4 Push [Z](F-2) to display the "GROUP" item (Re-
peater group).
• Selected group number appears.
GROUP:
RP–L
Ù Ú
@5 Rotate [MAIN DIAL] to select the desired repeater
group.
E D T
GRP1
≈
DV MODE PROGRAMMING
Access repeater setting (R1 USE)
6.
The programmed repeaters can be set as an access
repeater (R1) in the DR mode. To use as R1, the re-
peater frequency, duplex direction and frequency off-
set must be programmed.
@6 Push [Z](F-2) to display the "R1USE" item (Access
Repeater Programming).
• The access repeater programming screen appears.
R1USE:
RP–L
Ù Ú
@7 Rotate [MAIN DIAL] to select "YES" or "NO."
• When "NO" is selected, the repeater cannot be selected
as an access repeater (R1) in the DR mode.
• When "YES" is selected, the repeater can be selected
as an access repeater (R1) in the DR mode.
hen "NO" is selected in step @7 , skip 'Frequency
➥ W
programming (FREQ)' and go to 'Duplex direction
setting (DUP).'
When "YES" is selected in step @7 , push [Z](F-2) to
➥
go to step @8 for the access repeater (R1) program-
ming.
Frequency programming (FREQ)
7.
This content appears when "YES" is selected in "R1
USE," as described in 'Access repeater setting (R1
USE)' above.
@8 Push [Z](F-2) to display the "FREQ" item (Fre-
quency Programming).
• The frequency programming screen is displayed.
RP–L F R E Q :
Ù Ú C L R
@9 Push [EDT](F-4) to enter the frequency program-
ming mode.
• A cursor appears and blinks.
:
RP–L F-INP
Ù Ú
#0 Push the keypad key to input the frequency, then
push [F-INP ENT].
• Hold down [CLR](F-3) for 1 second to clear the dis-
played frequency.
