Icom i9100 Instruction Manual page 195

Data
Cmd. Sub cmd.
1A 05 0016 00 Send/read Split Lock function OFF
01 Send/read Split Lock function ON
0017 see p. 192 Send/read Duplex offset frequency
0018 00 Send/read One Touch Repeater DUP–
01 Send/read One Touch Repeater DUP+
0019 00 Send/read Auto Repeater OFF
01 Send/read Auto Repeater ON-1 (for USA
version) or ON (for Korea version)
02 Send/read Auto Repeater ON-2 (for USA
version)
0020 00 Send/read Tuner Auto Start OFF
01 Send/read Tuner Auto Start ON
0021 00 Send/read PTT Tune OFF
01 Send/read PTT Tune ON
0022 00 Send/read antenna selection OFF
01 Send/read manual antenna selection
02 Send/read auto antenna selection
0023 0000 to Send/read voice synthesizer level
(0000=0% to 0255=100%)
0255
0024 00 Send/read English selection for voice syn-
thesizer speech language
01 Send/read Japanese selection for voice
synthesizer speech language
0025 00 Send/read speech speed slow
01 Send/read speech speed fast
0026 00 Send/read S-meter level announcement
OFF
01 Send/read S-meter level announcement
ON
0027 00 Send/read operating mode announce-
ment (after pushing mode switch) OFF
01 Send/read operating mode announce-
ment (after pushing mode switch) ON
0028 00 Send/read [SPEECH/LOCK] key function
setting
(Push=SPEECH, Hold down=LOCK)
01 Send/read [SPEECH/LOCK] key function
setting
(Push=LOCK, Hold down=SPEECH)
0029 00 Send/read number of memo pad channels
5
01 Send/read number of memo pad channels
10
0030 00 Send/read auto TS for [MAIN DIAL] OFF
01 Send/read auto TS for [MAIN DIAL] Low
02 Send/read auto TS for [MAIN DIAL] High
0031 00 Send/read Low selection for microphone
Up/Down speed
01 Send/read High selection for microphone
Up/Down speed
0032 00 Send/read Quick RIT/∂TX clear OFF
01 Send/read Quick RIT/∂TX clear ON
0033 00 Send/read AFC functioning range limit
OFF
01 Send/read AFC functioning range limit ON
0034 00 Send/read Auto Notch selection for SSB
mode
01 Send/read Manual notch selection for
SSB mode
02 Send/read Auto/Manual Notch selection
for SSB mode
0035 00 Send/read Auto Notch selection for AM
mode
01 Send/read Manual Notch selection for AM
mode
02 Send/read Auto/Manual Notch selection
for AM mode
Description
Cmd.
1A
CONTROL COMMAND
Data
Sub cmd.
05 0036 00 Send/read Manual Notch filter width pop-
up OFF
01 Send/read Manual Notch filter width pop-
up ON
0037 00 Send/read BW Popup (PBT) setting OFF
01 Send/read BW Popup (PBT) setting ON
0038 00 Send/read BW Popup (FIL) setting OFF
01 Send/read BW Popup (FIL) setting ON
0039 00 Send/read SSB/CW Synchronous Tuning
function OFF
01 Send/read SSB/CW Synchronous Tuning
function ON
0040 00 Send/read LSB selection for CW normal
side
01 Send/read USB selection for CW normal
side
Send/read KEYER-Root selection for
0041 00
keyer 1st menu
Send/read KEYER-SEND selection for
01
keyer 1st menu
0042 00 Send/read GPS-Root selection for GPS
1st Menu
01 Send/read GPS-POS selection for GPS
1st Menu
0043 00 Send/read external preamplifier (AG-25)
control for 144 MHz band OFF
01 Send/read external preamplifier (AG-25)
control for 144 MHz band ON
0044 00 Send/read external preamplifier (AG-35)
control for 430 MHz band OFF
01 Send/read external preamplifier (AG-35)
control for 430 MHz band ON
0045 00 Send/read external preamplifier (AG-
1200) control for 1200 MHz band OFF
01 Send/read external preamplifier (AG-
1200) control for 1200 MHz band ON
0046 00 Send/read Separate selection for the ex-
ternal speaker output method
01 Send/read Mix selection for the external
speaker output method
0047 00 Send/read Separate selection for the
headphone audio output method
01 Send/read Mix selection for the head-
phone audio output method
02 Send/read Auto selection for the head-
phone audio output method
0048 00 Send/read SUB Band audio mute during
transmit on the main band OFF
01 Send/read SUB Band audio mute during
transmit on the main band ON
0049 00 Send/read MAIN selection for the [ACC]
AF/SQL line output
01 Send/read SUB selection for the [ACC]
AF/SQL line output
0050 00 Send/read MAIN selection for the [DATA]
AF/SQL line output
01 Send/read SUB selection for the [DATA]
AF/SQL line output
0051 00 Send/read VSEND select OFF
01 Send/read UHF Only selection for VSEND
02 Send/read VSEND select ON
0052 00 Send/read external keypad OFF
Send/read KEYER SEND selection for the
01
external keypad
0053 00 Send/read USB audio squelch OFF
(OPEN)
01 Send/read USB audio squelch ON
18
