OPTIONS

IC-PW1/EURO HF/50 MHz ALL BAND 1 kW LINEAR AMPLIFIER
Full-duty 1 kW linear amplifier including an automatic antenna tuner. Has auto-
matic tuning and band selection capability. Full break-in (QSK) operation is possi-
ble. The amplifier/power supply unit and the remote control unit can be separated.
The optional OPC-599
PS-126 dc power supply
• Output voltage : 13.8 V DC
• Max. output current : 25 A
SP-21 external speaker
Designed for base station operation.
• Input impedance: 8 ø
• Max. input power: 5 W
HM-36 hand microphone
Hand microphone equipped with [UP]/
[DOWN] switches.
The same as that attached with the
transceiver.
199
adapter cable is required for connection.
SP-23 external speaker
4 audio filters; headphone jack; can
connect to 2 transceivers.
• Input impedance: 8 ø
• Max. input power: 4 W
SM-30 desktop microphone
Unidirectional, electret microphone for
base station operation. Includes a low
cut switch and mic gain control.
UX-9100 1200
Allows you additional all mode oper-
ation on the 1200 MHz frequency
band.
AH-4
Specially designed to tune a long wire
antenna for the HF/50 MHz bands,
particularly in portable or mobile oper-
ation. The "PTT tune" function pro-
vides simple operation.
• Input power rating: 120 W
AH-2b
SM-50
Unidirectional, dynamic microphone for
base station operation. Includes [UP]/
[DOWN] switches, a low cut switch and
mic gain control.
mhz band unit FL-430
FL-431
(Both filters are for HF/50 MHz Band)
These filters reduce interference
from strong nearby signals.
hf automatic antenna tuner
antenna element
A 2.5 m long antenna ele-
ment for mobile operation
with the AH-4.
• F r e q u e n c y c o v e r a g e
7–54 MHz band with the
AH-4
desktop microphone
1 (6 k
st if filter h
z)
1 (3 k
st if filter h
z)
