Page 1 AlphaServer TS15 Owner's Guide Order Number: EK-TS150-OG. A01 This manual is intended for system managers, qualified self-maintenance customers, and others who need to perform system management tasks on AlphaServer TS15 systems. Hewlett-Packard Company...
Page 2 HP shall not be liable for technical or editorial errors or omissions contained herein. The information in this document is provided “as is” without warranty of any kind and is subject to change without notice.
Page 3 Class B Equipment This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
Page 4 Modifications The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by Hewlett-Packard Company may void the user's authority to operate the equipment. Cables Connections to this device must be made with shielded cables with metallic RFI/EMI connector hoods in order to maintain compliance with FCC rules and regulations.
Page 5: European Union Notice
European Union Notice Products with the CE marking comply with the EMC Directive (89/336/EEC) and the Low Voltage Directive (73/23/EEC) issued by the Commission of the European Community and if this product has telecommunication functionality, the R&TTE Directive (1999/5/EC). Compliance with these directives implies conformity to the following European Norms (in parentheses are the equivalent international standards and regulations): •...
Page 7: Table Of Contents
Contents Preface Chapter 1 System Overview System Enclosure Configurations................1-2 Common Components ................... 1-5 Top View ....................... 1-6 Rear Ports and Slots....................1-8 Network Connections .................... 1-9 Operator Control Panel ..................1-11 1.6.1 Remote Commands ..................1-12 System Motherboard.................... 1-13 1.7.1 CPU ......................
Page 8 Setting SRM Environment Variables..............2-17 Setting Console Security..................2-18 2.6.1 Setting the Console Password............... 2-19 2.6.2 Setting the Console to Secure Mode............. 2-20 2.6.3 Turning Off Security During a Console Session .......... 2-21 2.6.4 Returning to User Mode ................2-23 Updating Firmware....................
Page 9 4.12.1 Memory Organization................... 4-24 4.12.2 Physical Layout on the System Motherboard ..........4-24 4.12.3 Configuration Rules..................4-24 4.12.4 Installing and Removing DIMMs..............4-26 4.13 PCI Configuration and Installation ..............4-28 4.13.1 PCI Configuration ..................4-28 4.13.2 PCI Configuration Rules for 66 MHz Modules..........4-29 4.14 Installing a PCI Option Module................
Page 10 5.19.5 Returning to User Mode ................5-37 5.20 Setting and Viewing Environment Variables............5-38 5.20.1 com*_baud ....................5-42 5.20.2 console......................5-43 5.20.3 eg*0_mode, ei*0_mode, or ew*0_mode ............5-44 5.20.4 kbd_hardware_type ..................5-46 5.20.5 language......................5-47 5.20.6 os_type......................5-48 5.20.7 pci_parity...................... 5-49 5.20.8 pk*0_fast ......................
Page 11 7.10 SCSI Problems..................... 7-13 7.11 Fail-Safe Booter Utility ..................7-14 7.11.1 Starting the FSB Automatically..............7-14 7.11.2 Starting the FSB Manually ................7-15 7.11.3 Required Firmware..................7-16 7.11.4 Updating Firmware..................7-16 Appendix A Specifications Physical Specifications ..................A-2 Environmental Specifications ................A-3 Electrical Specifications ..................
Page 12 Example 7–1 Memory Sizing................... 7-11 Example 7–2 Running LFU ..................... 7-16 Figures Figure 1–1 AlphaServer TS15 Systems Installed in NEBS Cabinet ........1-2 Figure 1–2 Rackmount Details for AlphaServer TS15 System.......... 1-3 Figure 1–3 Views of Optional Storage Cages ..............1-4 Figure 1–4 Top View ......................
Page 13 Figure 4–3 Removing the Top Cover................. 4-5 Figure 4–4 Accessing the Center Internal Storage Bay ............. 4-7 Figure 4–5 Replacing the Disk in the Center Internal Storage Bay ........4-8 Figure 4–6 LEDs on the Front Access Drive (Front View) ..........4-9 Figure 4–7 Replacing a Front Access Disk Drive............
Page 14 Table 7–6 Troubleshooting Boot Problems ............... 7-7 Table 7–7 Operating System Reported Failures............... 7-10 Table 7–8 Troubleshooting Memory Problems..............7-11 Table A–1 Physical Characteristics – AlphaServer TS15..........A-2 Table A–2 NEBS Seismic (Earthquake) Cabinets ............A-2 Table A–3 Environmental Characteristics – All System Variants ........A-3 Table A–4 Electrical Characteristics –...
Page 15: Preface
How to Use This Guide Read this guide before operating an AlphaServer TS15 system. Before using the system, review the warranty. The terms of the warranty agreement with HP may require that a qualified HP Services representative install the system. Contact your local HP representative if you have any questions.
Page 16 In examples of command usage, bold text identifies what the user types. Monospace text Used to display onscreen printouts and text entered at the command line. Information on the Internet Visit the AlphaServer Web site at http://h18002.www1.hp.com/alphaserver/ for service tools and more information about the AlphaServer TS15 system.
Page 17: Chapter 1 System Overview
Chapter 1 System Overview This chapter provides an overview of the system including: • System Enclosure Configurations • Common Components • Front View • Top View • Rear Ports and Slots • Network Connection • Operator Control Panel • System Motherboard •...
Page 18: System Enclosure Configurations
System Enclosure Configurations The AlphaServer TS15 system consists of a rackmountable kit that can be installed in a 600 mm Network Equipment Building System (NEBS) cabinet. Figure 1–1 AlphaServer TS15 Systems Installed in NEBS Cabinet MR0652 hp AlphaServer TS15 Owner’s Guide...
Page 19: Figure 1-2 Rackmount Details For Alphaserver Ts15 System
The following figure shows details of a typical installation in a 19-inch cabinet. Notice that the slide bracket is a two-part assembly. Figure 1–2 Rackmount Details for AlphaServer TS15 System MR0651 System Overview...
Page 20: Figure 1-3 Views Of Optional Storage Cages
The following figure shows a system with the front cover opened. Items of interest are the center internal storage bay , the internal storage cage , the front access storage cage and the operator control panel Figure 1–3 Views of Optional Storage Cages MR0650 hp AlphaServer TS15 Owner’s Guide...
Page 21: Common Components
Common Components The basic building block of an AlphaServer TS15 system is the system enclosure that houses the following common components. • Alpha 1 GHz CPU with 2 MB onboard ECC cache • Choice of 512-MB, 1 GB, or 2 GB SDRAM memory − expandable to 4 GB maximum memory capacity •...
Page 22: Top View
Top View The following figure identifies most of the system components that can be seen after removing the cover. Figure 1–4 Top View MR0649 hp AlphaServer TS15 Owner’s Guide...
Page 23: Figure 1-9 System Motherboard
Operator Control Panel DVD/CD-RW drive Internal disk drive Power supply PCI riser (I/O devices) System motherboard Memory Speaker (hidden) Center internal storage bay Cover Side wall Flip-down door and front bezel EMI shielding System Overview...
Page 24: Rear Ports And Slots
Figure 1–5 Rear Ports and Slots MR0622 Serial port (COM1) Serial port (COM2) Mouse connector Keyboard connector SCSI port Ethernet port B Ethernet port A Dual power inputs (A and B) PCI option slots (four available) hp AlphaServer TS15 Owner’s Guide...
Page 25: Network Connections
Network Connections There are two onboard Ethernet network connectors on the rear of the enclosure. The AlphaServer TS15 system has dual onboard 10/100 BaseT Ethernet ports. You can connect an Ethernet cable to either Ethernet connector A or connector B Figure 1–6 Ethernet Network Connection...
Page 26: Operator Control Panel
Green system power LED System Power Switch (On/Off) NOTE: Jumper J22 (pins 13 – 14) must be installed for the halt/reset button to function as a reset button. See the AlphaServer TS15 Service Guide for details on jumper locations and functions . 1-10...
Page 27: Remote Commands
1.6.1 Remote Commands As an alternative to the OCP, you can enter commands from the remote management console (RMC) to reset, halt, and power the system on or off. For information on RMC, see Chapter 6. RMC Command Function Power on Turns on power.
Page 28: System Motherboard
System Motherboard This is the main logic board for the system and is fastened to the base of the enclosure. Figure 1–9 System Motherboard 1-12 hp AlphaServer TS15 Owner’s Guide...
Page 29: Cpu
1.7.2 Memory DIMMS The AlphaServer TS15 system supports up to two pairs of 200-pin synchronous dual inline memory modules (DIMMs). Supported DIMM sizes are 256 MB, 512 MB, and 1 GB, allowing memory to be configured from 512 MB to 4096 MB.
Page 30: Slots On The Pci Riser Card
Slot 4 – 33 MHz, 3.3v – use this slot fourth LED – connected to +5 VAUX Table 1–1 How Physical I/O Slots Map to Logical Slots Port Hose Physical Slot SRM Logical Slot 1-14 hp AlphaServer TS15 Owner’s Guide...
Page 31: Storage Cage Options
Storage Cage Options The AlphaServer TS15 system comes with either an internal storage cage or a front access storage cage. 1.9.1 Internal Storage Cage An internal storage cage includes a half-height DVD/CD-RW drive and a half-height bay for a disk, DVD/CD-RW, or tape drive. The cage supports three 3.5-inch x 1-inch hard disk drives or two internal 3.5 inch x 1-inch hard disk drives and one 5.25-inch x 1.6-inch...
Page 32: Front Access Storage Cage
(AIT or DAT) and two internal disk drives. Figure 1–12 Front Access Storage Cage Configuration MR0590B Center internal storage bay DVD/CD-RW drive Universal drive Universal drive Bottom drive 1-16 hp AlphaServer TS15 Owner’s Guide...
Page 33: Console Terminal
1.10 Console Terminal The console terminal can be a serial (character cell) terminal connected to the COM1 port or a VGA monitor connected to a video card (VGA adapter). The following figures identify the proper connections. Figure 1–13 Console Terminal Connected to COM1 Port MR0646 System Overview 1-17...
Page 34: Figure 1-14 Vga Monitor Connected To Optional Video Card
Figure 1–14 VGA Monitor Connected to Optional Video Card MR0647 1-18 hp AlphaServer TS15 Owner’s Guide...
Page 35: Ground And Power Connections
1.11 Ground and Power Connections The power supply is designed for dual redundant inputs and both power cables must be installed. A ground cable connects the enclosure to the rack’s vertical rail. Figure 1–15 Ground and Power Connections MR0568 System Overview 1-19...
Page 36: System Access Lock
1.12 System Access Lock The system enclosure has a key lock at the rear. Due to the configuration of the enclosure, this lock is not functional and can be ignored. 1-20 hp AlphaServer TS15 Owner’s Guide...
Page 37: Chapter 2 Operating The System
Chapter 2 Operating the System This chapter provides instructions for basic system operation. The following topics are covered: • Powering up the system • Power-up displays • SRM console • Displaying the hardware configuration • Setting SRM environment variables • Setting console security •...
Page 38: Powering Up The System
NOTE: The power button must be in the On position for the RMC power commands to function. To control power to the system remotely, use the RMC power off and power on commands. RMC> power off RMC> power on hp AlphaServer TS15 Owner's Guide...
Page 39: Power-Up Displays
Power-Up Displays Power-up information is displayed on the operator control panel LEDs and on the console terminal startup screen. Messages sent from the serial read-only memory (SROM) program are displayed first, followed by messages from the SRM console. NOTE: The power-up text that is displayed on the screen depends on the kind of terminal that is connected as the console terminal: either VT or VGA.
Page 40: Srom Power-Up Display
Bcache TAG lines tests in progress Memory sizing in progress Memory configuration in progress Testing AAR0 Memory data test in progress Memory address test in progress Memory pattern test in progress Memory initialization Loading console Code execution complete (transfer control) hp AlphaServer TS15 Owner's Guide...
Page 41: Srm Console Power-Up Display
2.2.2 SRM Console Power-Up Display At the completion of SROM power-up, the CPU transfers control to the SRM console, described in Section 2.3. The SRM console (a command-line interface) continues the system initialization. Failures are reported to the console terminal through the power- up screen and a console event log.
Page 42: Srm Console
1536 MB of System Memory Testing the System Testing the Disks (read only) Testing the Network AlphaServer TS15 Console V6.3-1, built on Jun 10 2003 at 11:51:30 >>> Explanation The CPU prints a message indicating that it is running the console. Starting with this message, the power-up display is sent to any console terminal, regardless of the state of the console environment variable.
Page 43: Srm Console
SRM Console The SRM console is the command-line interface that allows you to set up and boot the operating system, display the system configuration, set environment variables, and perform basic system troubleshooting. SRM firmware is located in a flash ROM (read-only memory) on the system board.
Page 44: Selecting The Display Device
In the following example, the operator displays the current console device (a graphics device) and then resets it to a serial device. After the system initializes, output will be displayed on the serial terminal. >>> show console console graphics >>> set console serial >>> init hp AlphaServer TS15 Owner's Guide...
Page 45: Displaying The Hardware Configuration
Displaying the Hardware Configuration View the system hardware configuration from the SRM console. It is useful to view the hardware configuration to ensure that the system recognizes all devices, memory configuration, and network connections. Use the following SRM console commands to view the system configuration: Displays the boot environment variables.
Page 46: Displaying Boot Environment Variables
Additional parameters, if any, specified by the -flags option of the (read only) last boot command. For example, if boot -flags s dka0 was the last boot command, then ‘s’ is stored in the booted_osflags variable. 2-10 hp AlphaServer TS15 Owner's Guide...
Page 47: Displaying The Logical Hardware Configuration
Use the show config command to display the logical configuration. To display the physical configuration, issue the show fru command. The explanation for the following example appears after the example. Example 2–5 Show Config >>>show config hp AlphaServer TS15 Firmware SRM Console: X6.6-24 PALcode: OpenVMS PALcode V1.98-6, Tru64 UNIX PALcode V1.92-7 SROM Extended: V1.0-1...
Page 48 Onboard Acer chip. Provides bridge to ISA Bus 1 Slot 8 Slots 8/0, 8/1 Onboard Dual Channel Adaptec controller Slot 9 Onboard 10/100 Mb Ethernet (Port A) Slot 10 Onboard 10/100 Mb Ethernet (Port B) Slot 13 Onboard Acer chip IDE 2-12 hp AlphaServer TS15 Owner's Guide...
Page 49: Displaying The Bootable Devices
Hose 0, Bus 1 The Acer is configured to use a floppy, but the device is not present. Hose 2, Bus 0, PCI Slots 7 and 8 are 66MHz/33MHz and slots 9 and 10 are 33 MHz. Slot 7 is an ATI Radeon 7500 Graphics Accelerator running at 66 MHz. Jumpers.
Page 50: Table 2-2 Device Naming Conventions
100 X node ID. Bus node number Bus node ID. Channel number Used for multi-channel devices. Logical slot number IDE that is onboard. • 0 PCI 0 Hose number • 2 PCI 2 2-14 hp AlphaServer TS15 Owner's Guide...
Page 51: Viewing The Memory Configuration
2.4.4 Viewing the Memory Configuration Use the show memory command to view the configuration of main memory. Example 2–7 Show Memory >>> show memory Array Size Base Address Intlv Mode --------- ---------- ---------------- ---------- 1024Mb 0000000000000000 1-Way 1024 MB of System Memory >>>...
Page 52: Setting Srm Environment Variables
To turn off console security for the current console session, use the login command. The environment variables used to set up the boot environment are described in Chapter 3. Chapter 5 covers other environment variables you are likely to use. 2-16 hp AlphaServer TS15 Owner's Guide...
Page 53: Setting Console Security
Setting Console Security You can set the SRM console to secure mode to prevent unauthorized persons from modifying the system parameters or otherwise tampering with the system from the console. When the SRM is set to secure mode, you can use only three console commands: •...
Page 54: Setting The Console Password
The password is not changed if the validation password entered does not match the existing password stored in nonvolatile RAM (NVRAM). The password length must be between 15 and 30 alphanumeric characters. Any characters entered after the 30th character are not stored. 2-18 hp AlphaServer TS15 Owner's Guide...
Page 55: Setting The Console To Secure Mode
2.6.2 Setting the Console to Secure Mode To set the console to secure mode, first set the password. Then enter the set secure command. The system immediately enters secure mode. Example 2–9 Set Secure >>> set secure Console is secure. Please login. >>>...
Page 56: Turning Off Security During A Console Session
A password is set. The login command is entered. After the password is entered, console security is turned off for the current session and the operator can enter commands such as show boot*. 2-20 hp AlphaServer TS15 Owner's Guide...
Page 57 When you enter the login command, you are prompted for the current system password. If a password has not been set, a message is displayed indicating that there is no password in NVRAM. If a password has been set, this prompt is displayed: Please enter the password: If the password entered matches the password in NVRAM, when the prompt is redisplayed the console is no longer in secure mode and all console commands can be performed during...
Page 58: Returning To User Mode
Once you clear the password, the console is no longer secure. To clear the password without knowing the current password, you must use the login command in conjunction with the RMC halt command, as described in Section 2.6.3. 2-22 hp AlphaServer TS15 Owner's Guide...
Page 59: Updating Firmware
Systems Firmware Update Kit comes on a CD-ROM, which is updated quarterly. You can also obtain Alpha firmware updates from the Internet. Quarterly Update Service The Alpha Systems Firmware Update Kit CD-ROM is available by subscription from HP. Alpha Firmware Internet Access You can also obtain Alpha firmware update files from the Internet: http://ftp.digital.com/pub/DEC/Alpha/firmware/...
Page 60 CQ16 kzpsa_fw UPD> update srm Confirm update on: [Y/(N)] y WARNING: updates may take several minutes to complete for each device. DO NOT ABORT! Updating to 6.3-1... Verifying 6.3-1... PASSED. UPD> list UPD> exit 2-24 hp AlphaServer TS15 Owner's Guide...
Page 61: Manually Updating Tig Or Rmc Booter
2.7.2 Manually Updating TIG or RMC Booter If the TIG or RMC booter needs to be updated, you can perform a manual update. 1. Boot the update medium. 2. At the UPD> prompt, enter the exit command and answer y at the prompt: ***** Loadable Firmware Update Utility ***** ------------------------------------------------------------------- Function...
Page 62: Updating From The Cd-Rom
3. Boot the system from the CD, using the drive name determined in step 1 (for example, dqa0). >>> boot dqa0 4. Enter the update command at the UPD> prompt. 5. When the update is complete, exit from the Firmware Update Utility. UPD> exit 2-26 hp AlphaServer TS15 Owner's Guide...
Page 63: Updating From An Openvms System Disk
2.7.4 Updating from an OpenVMS System Disk You can update the firmware from an OpenVMS system disk. 1. Download the firmware update image from the Firmware Updates Web site. 2. Rename the downloaded file to fwupdate.exe. 3. Enter the following commands on the OpenVMS Alpha system: $ set file/attr=(rfm:fix,lrl:512,mrs:512,rat:none) fwupdate.exe $ copy/contiguous fwupdate.exe "system_disk":[sys0.sysexe] NOTE: Insert the name of your system disk in place of "system_disk,"...
Page 64: Updating From The Network
NOTE: Replace “fwupdate.sys” with the name of the firmware image you downloaded. 4. Boot the update file. For example: >>> boot -file fwupdate eia0 –prot mop 5. Enter the update command at the UPD> prompt. 2-28 hp AlphaServer TS15 Owner's Guide...
Page 65: Chapter 3 Booting And Installing An Operating System
Chapter 3 Booting and Installing an Operating System This chapter gives instructions for booting the Tru64 UNIX or OpenVMS operating systems and for starting an operating system installation. It also describes how to switch from one operating system to another. Refer to your operating system documentation for complete instructions on booting or starting an installation.
Page 66: Setting Boot Options
(through the bootp protocol). Set this environment variable if you are booting Tru64 UNIX from a Remote Installation Services (RIS) server. eg*0_protocols Defines a default network boot protocol (bootp or mop). ei*0_protocols ew*0_protocols hp AlphaServer TS15 Owner's Guide...
Page 67: Auto_Action
3.1.1 auto_action The auto_action environment variable specifies the action the console takes any time the system powers up, fails, or resets. The value of auto_action takes effect only after you reset the system by pressing the Reset button (if configured), issuing the reset command from the Remote Management Console (RMC), or issuing the init command from the SRM.
Page 68: Bootdef_Dev
When Tru64 UNIX is shut down and rebooted, the system reboots from the specified device. >>> boot dka100 [Log in to UNIX and shutdown/reboot] #shutdown -r now console will boot from dka100 hp AlphaServer TS15 Owner's Guide...
Page 69: Bootdef_Dev
3.1.2 bootdef_dev The bootdef_dev environment variable specifies one or more devices from which to boot the operating system. When more than one device is specified, the system searches in the order listed, and boots from the first device with operating system software. Enter the show bootdef_dev command to display the current default boot device.
Page 70: Boot_File
The factory default value is null. The syntax is: set boot_file filename Example In this example, the system is set to boot using the file vmunix. >>> set boot_file vmunix hp AlphaServer TS15 Owner's Guide...
Page 71: Boot_Osflags
3.1.4 boot_osflags The boot_osflags environment variable sets the default boot flags and, for OpenVMS, a root number. Boot flags contain information used by the operating system to determine some aspects of a system bootstrap. Under normal circumstances, you can use the default boot flag settings. To change the boot flags for the current boot only, use the –flags option with the boot command.
Page 72: Table 3-1 Openvms Boot Flag Settings
Stop at the bootstrap breakpoints. Omit header from secondary bootstrap image. Prompt for the name of the secondary bootstrap file. Halt before secondary bootstrap. 10000 Display debug messages during booting. 20000 Display user messages during booting. hp AlphaServer TS15 Owner's Guide...
Page 73: Eg*0_Inet_Init, Ei*0_Inet_Init, Ew*0_Inet_Init
Examples In the following OpenVMS example, root_number is set to 2 and boot_flags is set to 1. With this setting, the system will boot from root directory [SYS2.SYSEXE] to the SYSBOOT prompt when you enter the boot command. >>> set boot_osflags 2,1 In the following OpenVMS example, root_number is set to 0 and boot_flags is set to 80.
Page 74: Ex*_Protocols
>>> show device dqa0.0.0.16.0 DQA0 HL-DT-ST GCE-8302B 2.01 dva0.0.1000.0* DVA0 ega0.0.0.5.2 EGA0 00-00-00-00-00-00 eia0.0.0.8.0 EIA0 40-00-04-A5-F8-00 pka0.7.0.1.2 PKA0 SCSI Bus ID 7 pkb0.7.0.101.2 PKB0 SCSI Bus ID 7 >>> * TS15 systems have no floppy drive. 3-10 hp AlphaServer TS15 Owner's Guide...
Page 75: Booting Tru64 Unix
= 2048.00 megabytes. available memory = 1979.00 megabytes. using 7818 buffers containing 61.07 megabytes of memory Firmware revision: 6.6-2698 PALcode: UNIX version 1.92-7 AlphaServer TS15 pci0 (primary bus:0) at nexus isa0 at pci0 gpc0 at isa0 gpc1 not probed...
Page 76 4. Enter the show device command to find the unit number of the drive for your device. 5. Enter the boot command and command-line parameters (if you have not set the associated environment variables). In the preceding example, boot flags have already been set. 3-12 hp AlphaServer TS15 Owner's Guide...
Page 77: Booting Tru64 Unix Over The Network
3.2.1 Booting Tru64 UNIX over the Network To boot your Tru64 UNIX system over the network, make sure the system is registered on a RIS server. See the Tru64 UNIX document entitled Sharing Software on a Local Area Network for registration information. The explanation for the following example appears after the example.
Page 78 In the preceding example, the boot command sets the system to boot automatically from ega0. For complete instructions on booting Tru64 UNIX over the network, see the Tru64 UNIX Installation Guide. 3-14 hp AlphaServer TS15 Owner's Guide...
Page 79: Setting Up The Watchdog Timer
3.2.2 Setting Up the Watchdog Timer An AlphaServer TS15 system running Tru64 UNIX contains a watchdog timer that, when enabled, monitors the running system and takes action should the system become hung. The watchdog timer is functional only after enabling it within both the RMC command-line interface as well as within Tru64 UNIX.
Page 80: Starting A Tru64 Unix Installation
The following options are available: <Press RETURN for more>: The "U.S. English Installation" installs the base operating system software. The "Installation with Worldwide Language Support" (WLS) lets you internationalize your system. This option installs the base operating 3-16 hp AlphaServer TS15 Owner's Guide...
Page 81 system software as well as WLS software. The additional software subsets provide support for various countries and their native languages. The "Exit Installation" option stops the installation and puts your system in single-user mode with superuser privileges. This option is intended for experienced UNIX system administrators who want to perform file system or disk maintenance tasks before the installation.
Page 82: Booting Openvms
HWRPB at 2000 initializing page table at 3ffee000 initializing machine state setting affinity to the primary CPU jumping to bootstrap code OpenVMS (TM) Alpha Operating System, Version V7.3-1 *TS15 systems have no floppy drive. 3-18 hp AlphaServer TS15 Owner's Guide...
Page 83 Explanation Example 3-4 on the preceding page shows a boot from a CD-ROM on a local drive. The example is abbreviated. For complete instructions on booting OpenVMS, see the OpenVMS installation document. 1. Power up the system. The system stops at the SRM console prompt, >>>. 2.
Page 84: Booting Openvms From The Infoserver
= 200000, image_start = 0, image_bytes = 70400 initializing HWRPB at 2000 initializing page table at 3ffee000 initializing machine state setting affinity to the primary CPU jumping to bootstrap code *TS15 systems have no floppy drive. 3-20 hp AlphaServer TS15 Owner's Guide...
Page 85 Network Initial System Load Function Version 1.2 FUNCTION ID FUNCTION Display Menu Help Choose Service Select Options Stop Enter a function ID value: Enter a function ID Value: OPTION OPTION Find Services Enter known Service Name Enter an Option ID value: 2 Enter a Known Service Name: ALPHA_V73-1_SSB OpenVMS (TM) Alpha Operating System, Version V7.3-1 Explanation...
Page 86: Starting An Openvms Installation
Explanation Boot the OpenVMS operating system CD-ROM. Enter date and time at the prompt. 2. Choose option 1 (Upgrade, install, or reconfigure OpenVMS Alpha). To create the system disk, see the OpenVMS installation document. 3-22 hp AlphaServer TS15 Owner's Guide...
Page 87: Installing And Configuring Options
Chapter 4 Installing and Configuring Options This chapter shows how to configure and install user-installable options including the pedestal kit, memory DIMMs, PCI option modules, storage cages, hard drives, and tape drives. Installation of components not covered in this chapter is reserved for service providers and customers who have purchased a self-maintenance contract.
Page 88: Preparing To Install Options
3. Press the Power button on the system unit to the Off position. 4. Unplug the power cords. 5. Attach an antistatic wrist strap. NOTE: Read through each of the following procedures before performing any steps. hp AlphaServer TS15 Owner's Guide...
Page 89: Removing And Replacing The Top Cover
2. Go to the rear of the cabinet, locate the back panel of the AlphaServer TS15 enclosure, and disconnect both power connectors. Also, disconnect the ground cable and all other cables from the enclosure.
Page 90: Figure 4-2 Removing The Enclosure From The Rack
Lift the cover straight up and set it on the tabletop. NOTE: Notice the quick reference labels on the inside of the top cover. The labels provide detailed information about the system. hp AlphaServer TS15 Owner's Guide...
Page 91: Figure 4-3 Removing The Top Cover
Figure 4–3 Removing the Top Cover MR0642 Installing and Configuring Options...
Page 92 . Close the front door and tighten the thumbscrews 4. Go to the rear of the cabinet, locate the back panel of the AlphaServer TS15 enclosure, and connect the ground cable and all other cables to the enclosure. Connect both power connectors.
Page 93: Replacing The Disk In Center Internal Storage Bay
Replacing the Disk in Center Internal Storage Bay The center internal storage bay provides a disk drive as optional storage. Refer to the following figures and procedures when replacing this disk drive. Figure 4–4 Accessing the Center Internal Storage Bay MR0629 Removing the Center Internal Storage Bay 4.
Page 94: Figure 4-5 Replacing The Disk In The Center Internal Storage Bay
9. Install the new disk drive and replace the bottom screws. 10. Referring to preceding Figure 4–4, connect the data cable and power cable to the new disk drive 11. Slide the storage bay forward into the enclosure. hp AlphaServer TS15 Owner's Guide...
Page 95: Status Leds On Front Access Drives
12. Pull the two spring-loaded pull pins and lower the storage bay until the pins snap into place. 13. Replace the top cover and reassemble the system enclosure as explained at the end of Section 4.2. 14. Turn on system power by pressing the power switch on the operator control panel. Boot the operating system.
Page 96: Replacing A Front Access Drive
Verification You must enter the SRM and use the init and show device commands to verify that the system sees the new drive. 4-10 hp AlphaServer TS15 Owner's Guide...
Page 97: Figure 4-8 Replacing A Front Access Tape Drive
Figure 4–8 Replacing a Front Access Tape Drive MR0658 CAUTION: Before removing a drive, make sure that its activity LED is off. Replacing a Front Access Tape Drive 1. Verify that the tape drive is not in use (the activity LED is off). 2.
Page 98: Accessing The Front Access Storage Cage
You must remove this cage to access the bottom disk drive. Refer to the following figure and procedure when removing this cage. Figure 4–9 Accessing the Front Access Storage Cage MR0631 4-12 hp AlphaServer TS15 Owner's Guide...
Page 99 Accessing the Front Access Storage Cage 1. Shut down the system and remove the top cover as explained in Section 4.2. 2. Remove the IDE data cable and power cable from the back of the slimline DVD- CD-RW drive. 3. Pull the two spring-loaded posts inward so that they come out of the receiving holes 4.
Page 100: Replacing Bottom Drive - Front Access Cage
Replacing Bottom Drive – Front Access Cage The bottom disk drive provides optional storage. Refer to the following figure and procedure when replacing a bottom drive. Figure 4–10 Replacing Bottom Drive – Front Access Storage Cage MR0593A 4-14 hp AlphaServer TS15 Owner's Guide...
Page 101 Replacing Bottom Drive – Front Access Storage Cage 1. Shut down the system and remove the top cover as explained in Section 4.2. 2. Remove the front access storage cage and all cables as explained in Section 4.6. 3. Remove the four screws from the sides of the bottom drive and slide the drive from the cage.
Page 102: Accessing The Internal Storage Cage
The internal storage cage is an optional component and the alternative to the front access storage cage. You must remove this cage to access its internal storage devices. Refer to the following figure and procedure when removing this cage. Figure 4–11 Accessing the Internal Storage Cage MR0630 4-16 hp AlphaServer TS15 Owner's Guide...
Page 103 Accessing the Internal Storage Cage 1. Shut down the system and remove the top cover as explained in Section 4.2. 2. Pull the two spring loaded insert posts inward so that the posts come out of the receiving holes 3. Pull the storage cage back, pivot the rear end up, and remove it from the enclosure. Turn the cage over to access the remaining cables.
Page 104: Replacing Bottom Drive - Internal Storage Cage
Replacing Bottom Drive – Internal Storage Cage The bottom disk drive provides optional storage. Refer to the following figure and procedure when replacing a bottom drive. Figure 4–12 Replacing Bottom Drive – Internal Storage Cage MR0592A 4-18 hp AlphaServer TS15 Owner's Guide...
Page 105 Replacing Bottom Drive – Internal Storage Cage 1. Shut down the system and remove the top cover as explained in Section 4.2. 2. Remove the internal storage cage and all cables as explained in Section 4.8. 3. Remove the four screws from the sides of the bottom drive and slide the drive from the cage.
Page 106: Replacing Middle Drive - Internal Storage Cage
4.10 Replacing Middle Drive – Internal Storage Cage The middle drive provides optional storage. Refer to the following figure and procedure when replacing a middle drive. Figure 4–13 Replacing Middle Drive – Internal Storage Cage MR0594A 4-20 hp AlphaServer TS15 Owner's Guide...
Page 107 Replacing Middle Drive – Internal Storage Cage 1. Shut down the system and remove the top cover as explained in Section 4.2. 2. Remove the internal storage cage and all cables as explained in Section 4.8. 3. Remove the four screws from the sides of the storage cage and slide the drive assembly from the storage cage.
Page 108: Replacing Dvd/Cd-Rw Drive - Internal Storage Cage
The top drive is a half-height DVD/CR-RW drive for use with optical media. Refer to the following figure and procedure when replacing a DVD/CD-RW drive. Figure 4–14 Replacing DVD/CD-RW Drive – Internal Storage Cage PK0277A 4-22 hp AlphaServer TS15 Owner's Guide...
Page 109 Replacing DVD/CD-RW Drive – Internal Storage Cage 1. Shut down the system and remove the top cover as explained in Section 4.2. 2. Remove the internal storage cage and all cables as explained in Section 4.8. 3. Remove the four screws that fasten the drive to the storage cage.
Page 110: Memory Configuration And Installation
4 GB of memory. The minimum memory configuration is 512 MB. The AlphaServer TS15 memory subsystem is distributed across four memory DIMM slots of SDRAM with PECL clocks. The system supports DIMM sizes of 256 MB, 512 MB, and 1024 MB.
Page 111: Table 4-1 Memory Configuration
Table 4-1 Memory Configuration Total DIMM0 DIMM2 DIMM1 DIMM3 Remarks Memory 512MB 256MB 256MB Minimum allowed configuration 1024MB 256MB 256MB 256MB 256MB Recommended for performance 1024MB 512MB 512MB 1536MB 256MB 512MB 256MB 512MB 1536MB 512MB 256MB 512MB 256MB 2048MB 512MB 512MB 512MB 512MB Recommended for performance...
Page 112: Installing And Removing Dimms
3. Shut down the system and remove the top cover as explained in Section 4.2. 4. Remove the optional center internal storage bay as explained in Section 4.3. This gives access to the DIMM slots. 4-26 hp AlphaServer TS15 Owner's Guide...
Page 113: Figure 4-16 Installing A Dimm
Figure 4–16 Installing a DIMM 5. To install the DIMM , align the notches on the gold fingers with the connector keys as shown. 6. Secure the DIMM with the clips on the DIMM slot. Verification 1. Turn on power to the system. 2.
Page 114: Pci Configuration And Installation
In general, PCI modules are designed for either 5.0 volts or 3.3 volts, or are universal in design and can plug into either 3.3 volt or 5.0 volt slots. The AlphaServer TS15 system provides only 3.3 volt slots.
Page 115: Pci Configuration Rules For 66 Mhz Modules
4.13.2 PCI Configuration Rules for 66 MHz Modules To run at 66 MHz, the following conditions must be met: • Both slot 3 and 4 must be empty. • A 33 MHz module must not be installed in either slot 1 or 2. •...
Page 116: Installing A Pci Option Module
Some PCI option modules require drivers to be installed and configured. These modules come with a CD-ROM. Refer to the installation document that came with the module and follow the manufacturer's instructions. Figure 4–18 Installing a PCI Option Module MR0633 4-30 hp AlphaServer TS15 Owner's Guide...
Page 117 1. Shut down the system and remove the top cover as explained in Section 4.2. 2. Remove the slot cover screw ; remove the slot cover by sliding it out of the enclosure. 3. Slide the PCI option module into the first available slot and plug it into the PCI riser 4.
Page 118: Installing An Ati Radeon Graphics Card
An optional graphics card is available as a PCI option. The kit (3X-PBXGG-TA) includes the graphics card, a support bracket, and hardware. The card must be installed in PCI slot 1. Figure 4–19 Installing an ATI Radeon Graphics Card 4-32 hp AlphaServer TS15 Owner's Guide...
Page 119 Installing an ATI Radeon Graphics Card 1. Shut down the system and remove the top cover as explained in Section 4.2. 2. If there is no module in PCI slot 1, refer to Figure 4–18. Remove the PCI slot cover screw , then remove the slot cover by sliding it out of the enclosure.
Page 120: External Scsi Expansion
• Ensure that the SCSI bus is properly terminated and that no devices in the middle of the bus are terminated. • For best performance, wide devices should be operated in wide SCSI mode. 4-34 hp AlphaServer TS15 Owner's Guide...
Page 121: Shared Scsi Support
4.15.1 Shared SCSI Support Tru64 UNIX supports shared SCSI busses using the AlphaServer TS15 embedded external SCSI port. When operating on a shared bus, jumper J41 (see Figure 4–20) must be installed on the system board. This will disable the on-board SCSI terminators for that SCSI bus.
Page 122: Figure 4-21 External Scsi Connector
Figure 4–21 External SCSI Connector MR0628 This figure shows the location of the external SCSI connector 4-36 hp AlphaServer TS15 Owner's Guide...
Page 123: Updating Firmware
You can also obtain Alpha firmware updates from the Internet. Quarterly Update Service The Alpha Systems Firmware Update Kit CD-ROM is available by subscription from HP. Alpha Firmware Internet Access You can also obtain Alpha firmware update files from the Internet: http://ftp.digital.com/pub/digital/Alpha/firmware/...
Page 124: Updating Firmware From The Cd-Rom
8. When the update is complete, enter the list command to verify that the images successfully copied and are listed with the correct revisions. 9. Enter the exit command to exit the Firmware Update Utility. 4-38 hp AlphaServer TS15 Owner's Guide...
Page 125: Chapter 5 Using Firmware
Chapter 5 Using Firmware The SRM user interface is the command-line interface that allows you to configure and boot the operating system and verify the configuration of devices. This chapter describes typical functions performed from the SRM console and the commands and environment variables used for these functions.
Page 126: Srm Console Overview
You can also use the * (asterisk) wildcard to show variables matching a pattern. For example, show boot* displays all the variables starting with “boot.” The environment variables are described in Section 5.20. Boot environment variables are described in Chapter 3. hp AlphaServer TS15 Owner's Guide...
Page 127: Invoking The Srm Console
5.1.1 Invoking the SRM Console You can invoke the SRM console at power-up or restart or after a system failure. Once you invoke SRM, you enter commands at the console prompt. Invoking SRM from Tru64 UNIX or OpenVMS The SRM console is invoked automatically at power-up or after a reset or failure. The auto_action environment variable is set by default to halt, which causes the system to stop in the SRM console.
Page 128: Srm Command Summary
Sets or modifies the value of an environment variable. Displays the state of the specified environment variable. show envar stop Halts the processor. (Same as halt.) test Verifies the configuration of the devices in the system. hp AlphaServer TS15 Owner's Guide...
Page 129: Table 5-2 Notation Formats For Srm Console Commands
Table 5–2 Notation Formats for SRM Console Commands Attribute Conditions Length Up to 255 characters, not including the terminating carriage return or any characters deleted as the command is entered. To enter a command longer than 80 characters, use the backslash character for line continuation (see Table 5–3).
Page 130: Table 5-3 Special Characters For Srm Console
Toggles between enable and disable. The output can be re-enabled by other means as well: when the console prompts for a command, issues an error message, or enters program mode, or when Ctrl/P is entered. hp AlphaServer TS15 Owner's Guide...
Page 131 Table 5–3 Special Characters for SRM Console (Continued) Character Function Ctrl/Q Resumes output to the console terminal that was suspended by Ctrl/S. Ctrl/R Redisplays the current line. Deleted characters are omitted. This command is useful for hardcopy terminals. Ctrl/S Suspends output to the console terminal until Ctrl/Q is entered. Cleared by Ctrl/C.
Page 132: Getting Help
Command or topic for which help is requested. The options are: none Displays the complete list of commands for which you can receive help. command_name Displays information about the console command. argument_string Displays information about all commands that (such as “sh”) begin with that string. hp AlphaServer TS15 Owner's Guide...
Page 133: Displaying The Configuration
Use the show config command to display a list of devices found on the system interconnect and I/O buses. This is the configuration at the most recent initialization. Example 5–2 Show Config >>> show config hp AlphaServer TS15 Firmware SRM Console: X6.6-47 PALcode: OpenVMS PALcode V1.98-6, Tru64 UNIX PALcode V1.92-7...
Page 134 Processors. Processors present, processor version and clock speed, and amount of backup cache Core logic. Version numbers of the chips that form the interconnect on the system board Memory. Memory arrays and memory size 5-10 hp AlphaServer TS15 Owner's Guide...
Page 135: Table 5-4 How Physical I/O Slots Map To Logical Slots
This part of the command output shows the PCI buses. The “Slot” column lists the slots (logical IDs) seen by the system. Logical IDs identify both installed PCI cards and onboard chips. In this example, the list shows the onboard controllers and the Acer Labs M1543C IDE. The logical IDs do not correspond directly to the physical slots into which the devices are installed.
Page 136: Displaying The Bootable Devices
PKA0 SCSI Bus ID 7 pkb0.7.0.108.0 PKB0 SCSI Bus ID 7 >>> * AlphaServer TS15 systems have no floppy drives. Table 5–5 Device Naming Conventions Category Description Driver ID Two-letter designator of port or class driver SCSI drive or CD...
Page 137: Displaying The Memory Configuration
Displaying the Memory Configuration Use the show memory command to display information about each memory array: size in megabytes, and the starting address. The display also shows the total amount of memory. It does not indicate the number of DIMMs or their size. Example 5–4 Show Memory >>>...
Page 138: Displaying The Power Status
Displaying the SRM Console Version Use the show version command to display the version of the SRM console that is installed. Example 5–6 Show Version >>> show version version V6.6-47 Nov. 11 3 2003 14:05:03 >>> 5-14 hp AlphaServer TS15 Owner's Guide...
Page 139: Displaying The Cpu Status
Displaying the CPU Status Use the show cpu command to display the status of the CPU. Example 5–7 Show CPU >>> show cpu Primary CPU: Active CPUs: Configured CPUs: The CPU has been brought successfully online and is ready to run an operating system. 5.10 Displaying the PALcode Version Use the show pal command to display the version of Tru64 UNIX or OpenVMS PALcode.
Page 140: Booting An Operating System
Then control passes to the first successfully booted image. In a list, always enter network devices last, because network bootstraps terminate only if a fatal error occurs or when an image is successfully loaded. 5-16 hp AlphaServer TS15 Owner's Guide...
Page 141 The syntax is: boot [-file filename] [-flags [value]] [-halt] [-protocols enet_protocol] [boot_dev] -file filename Specifies the name of a file to load into the system. Use the set boot_file command to set a default boot file. See Chapter 3. NOTE: For booting from Ethernet, the filename is limited by the MOP V3 load protocol to 15 characters.
Page 142: Testing The System
Testing the DQ* Disks (read only) No DF* Disks available for testing No MK* Tapes available for testing No MU* Tapes available for testing No VGA available for testing Testing the EI* Network >>> 5-18 hp AlphaServer TS15 Owner's Guide...
Page 143 Explanation The test command tests the entire system, a subsystem, or a specified device. If no device or subsystem is specified, the entire system is tested. To run a complete diagnostic test using the test command, the system configuration must include a CD ROM and a loopback connector on COM2.
Page 144: Starting And Stopping Cpu
(Jumper J22 pins 13- 14 must not be installed for the halt/reset button to operate as a halt a button.) or, for OpenVMS systems only, by entering Ctrl/P on the console terminal. 5-20 hp AlphaServer TS15 Owner's Guide...
Page 145 The syntax is: continue [&pn] [address] &pn Specifies the assigned designated processor number address The starting address of the program. NOTE: Some console commands, for example, boot, can alter the machine state so that program mode cannot be successfully resumed (unless you include -halt in the boot command).
Page 146: Updating Firmware
Compares loadable and hardware images. ? or Help Scrolls this function table. ---------------------------------------------------------------------------- UPD> UPD> list Device Current Revision Filename Update Revision V6.3-1 srm_fw V6.3-1 V0.6-2 rt_fw V0.6-2 srom V1.3-F srom_fw V1.3-F cipca_fw A420 dfxaa_fw 3.20 fca_2354_fw CS3.81A4 5-22 hp AlphaServer TS15 Owner's Guide...
Page 147 kgpsa_8k_fw DS3.81A4 kzpcc_smor 1.12 kzpcc_fw CQ16 kzpsa_fw UPD> UPD> update srm Confirm update on: [Y/(N)] y WARNING: updates may take several minutes to complete for each device. DO NOT ABORT! Updating to 6.3-1... Verifying 6.3-1... PASSED. UPD> UPD> list . . . UPD>...
Page 148: Forcing A System Crash Dump
RMC halt command. The crash command restarts the operating system and forces a crash dump to the selected device. The syntax is: crash [device] The device is the name of the device to which the crash dump is written. 5-24 hp AlphaServer TS15 Owner's Guide...
Page 149: Initializing The System
---------- ---------------- ---------- 1024Mb 0000000000000000 2-Way 1024Mb 0000000040000000 2-Way 2048 MB of System Memory Testing the System Testing the Disks (read only) Testing the Network AlphaServer TS15 Console V6.6-47, built on Nov 11 2003 at 14:05:03 >>> Using Firmware 5-25...
Page 150 If the auto_action environment variable is set to boot or restart and no halt assertion condition exists, the system autoboots. In all other cases, the system stops in console mode and does not attempt to boot. 5-26 hp AlphaServer TS15 Owner's Guide...
Page 151: Reading A File
5.17 Reading a File The more command displays a file one screen at a time. Example 5–15 More >>> more el starting console on CPU 0 initialized idle PCB initializing semaphores initializing heap initial heap 240c0 memory low limit = 1be000 heap = 240c0, 17fc0 initializing driver structures initializing idle process PID initializing file system...
Page 152 [file...] The file is the name of the file to be displayed. NOTE: If you misspell the word "more" while in graphics mode, the console hangs. Enter Ctrl/X to remove the hang condition. 5-28 hp AlphaServer TS15 Owner's Guide...
Page 153: Creating A Power-Up Script
5.18 Creating a Power-Up Script The system comes with a special nonvolatile file named “nvram” that is stored in electrically erasable read-only memory (EEROM). Nvram is a user-created power-up script (set of commands) that is always invoked during the power-up sequence. Use the SRM edit command to create or alter the nvram script.
Page 154 To correct this error, issue the RMC halt in command, then power up or reset the system. When the >>> prompt is displayed, edit the nvram script to remove the illegal command. 5-30 hp AlphaServer TS15 Owner's Guide...
Page 155: Setting Console Security
5.19 Setting Console Security The SRM console firmware has console security features intended to prevent unauthorized personnel from modifying the system parameters or otherwise tampering with the system from the console. The security features include a secure mode and commands to set console security. 5.19.1 Overview of Secure Mode The SRM console has two modes, user mode and secure mode.
Page 156: Setting The Console Password
The set password command sets the console password for the first time or changes an existing password. It is necessary to set the password only if the system is going to operate in secure mode. The syntax is: set password 5-32 hp AlphaServer TS15 Owner's Guide...
Page 157: Setting The Console To Secure Mode
5.19.3 Setting the Console to Secure Mode To set the console to secure mode, first set the password. Then enter the set secure command. The system immediately enters secure mode. Example 5–19 Set Secure >>> set secure Console is secure. Please login. >>>...
Page 158: Turning Off Security During A Console Session
The login command is entered, but the system is not in secure mode. A password must be set. A password is set. The login command is entered. After the password is entered, console security is turned off for the current session and the operator can enter commands. 5-34 hp AlphaServer TS15 Owner's Guide...
Page 159 When you enter the login command, you are prompted for the current system password. If a password has not been set, a message is displayed indicating that there is no password in NVRAM. If a password has been set, this prompt is displayed: Please enter the password: If the password entered matches the password in NVRAM, when the prompt is redisplayed the console is no longer in secure mode and all console commands can be performed during...
Page 160: Example 5-21 Clearing The Secure Password
Example dialog Explanation >>>login Enter RMC using the escape sequence Please enter the password: ^[^[rmc hp AlphaServer TS15 Remote Management Controller – Revision V1.1-0 Invoke the RMC halt in command RMC>halt in Returning to Com port Clear the password >>>clear password Enter RMC using the escape sequence >>>...
Page 161: Returning To User Mode
5.19.5 Returning to User Mode The clear password command clears the password environment variable, setting it to zero. Once the password is cleared, you are returned to user mode. Example 5–22 Clear Password >>> clear password Please enter the password: Console is secure >>>...
Page 162: Setting And Viewing Environment Variables
1 on each power-up. By default, MOP boots send four MOP V4 requests before defaulting to MOP V3. This user-created environment variable forces the SRM console to bypass MOP V4 requests. This speeds up MOP booting on networks with MOP V3 software. 5-38 hp AlphaServer TS15 Owner's Guide...
Page 163: Set Envar
set envar The set command sets or modifies the value of an environment variable. It can also be used to create a new environment variable if the name used is unique. Environment variables pass configuration information between the console and the operating system. Their settings determine how the system powers up, boots the operating system, and operates.
Page 164: Table 5-6 Environment Variable Summary
Specifies the device on which power-up output is displayed (serial terminal or VGA monitor). eg*0_mode Specifies the connection type of the default Ethernet controller. ei*0_mode ew*0_mode eg*0_protocols Specifies network protocols for booting over the Ethernet controller. ei*0_protocols ew*0_protocols 5-40 hp AlphaServer TS15 Owner's Guide...
Page 165 Table 5–6 Environment Variable Summary (Continued) Environment Variable Function kbd_hardware_type Specifies the default console keyboard type. language Specifies the console keyboard layout. os_type Specifies the operating system and sets the appropriate console interface. password Sets a console password. Required for placing the SRM into secure mode.
Page 166: Com*_Baud
The following example shows the supported baud rate values. >>> set com2_baud 57600 38400 19200 9600 7200 4800 3600 2400 2000 1800 NOTE: SROM power on output will not display correctly unless COM1 is set to 9600. 5-42 hp AlphaServer TS15 Owner's Guide...
Page 167: Console
5.20.2 console The console terminal can be either a VGA monitor or a serial terminal. The console environment variable specifies which type of console is used. The syntax is: set console output_device The options for output_device are: graphics (default) The console terminal is a VGA monitor or a device connected to the VGA port.
Page 168: Eg*0_Mode, Ei*0_Mode, Or Ew*0_Mode
If no Ethernet cable is connected in this mode, the SRM reports a failure: Error (eib0.0.10.0), No link, auto negotiation did not complete. This is applicable for ei*, ew*, and eg* device in auto negotiate. 5-44 hp AlphaServer TS15 Owner's Guide...
Page 169 Example >>> set eia0_mode twisted-pair Changing to selected mode. >>> show eia0_mode eia0_mode Twisted-Pair The options for eg*_mode value are: Auto Auto negotiation* 10mbps 10 Mb half duplex 10mbps_full_duplex 10 Mb full duplex 100mbps 100 Mb half duplex 100mbps_full_duplex 100 Mb full duplex 1000mbps 1000 Mb half duplex 1000mbps_full_duplex...
Page 170: Kbd_Hardware_Type
PCXAL or LK411 and enables the system to interpret the terminal keyboard layout correctly. The syntax is: set kbd_hardware_type keyboard_type The options for keyboard_type are: pcxal (default) Selects the 102-type keyboard layout. lk411 Selects the LK411 keyboard layout. Example >>> set kbd_hardware_type lk411 >>> 5-46 hp AlphaServer TS15 Owner's Guide...
Page 171: Language
5.20.5 language The language environment variable specifies the keyboard layout, which depends on the language. The setting of the language environment variable must match the language of the keyboard variant. The factory keyboard setting is 36 English (American). The value of language takes effect only after you reset the system by pressing the Reset button (if configured) or issuing the init command.
Page 172: Os_Type
Sets the default to Tru64 UNIX. The SRM firmware is started during OSF or power-up or reset. UNIX Example The following command sets the default operating system to Tru64 UNIX. >>> set os_type unix >>> init 5-48 hp AlphaServer TS15 Owner's Guide...
Page 173: Pci_Parity
5.20.7 pci_parity The pci_parity environment variable disables or enables parity checking on the PCI bus. Some PCI devices do not implement PCI parity checking, and some have a parity- generating scheme in which the parity is sometimes incorrect or is not fully compliant with the PCI specification.
Page 174: Pk*0_Fast
The controller is in standard SCSI mode. 1 (default) The controller is in fast SCSI mode. Example >>> set pkb0_fast 1 >>> init >>> show pkb0_fast pkb0_fast 1 NOTE: The PK commands only apply to the KZPBA-CC SCSI controller. 5-50 hp AlphaServer TS15 Owner's Guide...
Page 175: Pk*0_Host_Id
5.20.9 pk*0_host_id The pk*0_host_id environment variable sets the controller host bus node ID to a value between 0 and 7. Each SCSI bus in the system requires a controller. Buses can support up to eight devices; however, the eighth device must be a controller. Each device on the bus, including the controller, must have a unique ID, which is a number between 0 and 7.
Page 176: Pk*0_Soft_Term
Disables termination of all 16 bits. Enables low eight bits and disables high eight bits. Enables high eight bits and disables low eight bits. high on (default) Enables all 16 bits. diff Places the bus in differential mode. 5-52 hp AlphaServer TS15 Owner's Guide...
Page 177 Examples In this example, both terminators are disabled. >>> set pkb0_soft_term off >>> init >>> show pkb0_soft_term pkb0_soft_term In this example, the terminator for the high 8 bits is enabled. >>> set pkb0_soft_term high >>> init >>> show pkb0_soft_term pkb0_soft_term high Using Firmware 5-53...
Page 178: Tt_Allow_Login
COM1 port. Then the set tt_allow_login 0 command is used to disable logins through either the COM2 port or a VGA monitor. >>> set console serial >>> init >>> set tt_allow_login 0 5-54 hp AlphaServer TS15 Owner's Guide...
Page 179: Using The Remote Management Console
Chapter 6 Using the Remote Management Console You can manage the system through the Remote Management Console (RMC). The RMC is implemented through an independent microprocessor that resides on the system board. The RMC also provides configuration and error log functionality. This chapter explains the operation and use of the RMC.
Page 180: Rmc Overview
CLI you can power the system on and off, halt or reset the system, and monitor the system environment. • Passes error log information to shared RAM so that this information can be accessed by the system. hp AlphaServer TS15 Owner’s Guide...
Page 181 The RMC logic is implemented using the QLogic Zircon baseboard management controller. The RMC logic is responsible for monitoring temperature, fan speed, and all voltages. The RMC firmware images (booter and runtime) are stored in flash ROM. If the firmware should ever become corrupted or obsolete, you can update it manually using the Loadable Firmware Update Utility.
Page 182: Operating Modes
COM 1 Port UART (to Acer) System Zircon DUART PC16552D External COM1 External COM 1 Port UART RMC Modem Port (Remote) Modem RMC> RMC> Remote Serial Terminal Local Serial Terminal or Terminal Emulator or Terminal Emulator MR0535 hp AlphaServer TS15 Owner’s Guide...
Page 183 Through Mode Through mode is the default operating mode. The RMC routes every character of data between the internal system COM1 port and the external COM1 port. If a modem is connected, the data goes to the modem. The RMC filters the data for a specific escape sequence.
Page 184: Bypass Modes
COM 1 Port UART (to Acer) System Zircon DUART PC16552D External COM1 DCD,RX External COM1 Port UART RMC Modem Port (Remote) Modem RMC> RMC> Remote Serial Terminal Local Serial Terminal or Terminal Emulator or Terminal Emulator MR0536 hp AlphaServer TS15 Owner’s Guide...
Page 185 Figure 6–2 shows the data flow in the bypass modes. Note that the internal system COM1 port is connected directly to the external COM1 port. NOTE: You can connect a serial terminal to the external COM1 port in any of the bypass modes.
Page 186 RMC remote management features such as remote dial- in and dial-out alert. You can switch to other modes by resetting the com1_mode environment variable from the SRM console, but you must set up the RMC again from the local terminal. hp AlphaServer TS15 Owner’s Guide...
Page 187: Terminal Setup
Terminal Setup Figure 6–3 and Figure 6–4 (not drawn to scale) show the connections for a VT terminal and a VGA monitor to the system. To set up the RMC to monitor a system remotely, refer to Section 6.7. Figure 6–3 Setup for RMC with VT Terminal ENET MR0627 Using the Remote Management Console...
Page 188: Figure 6-4 Setup For Rmc With Vga Monitor
Figure 6–4 Setup for RMC with VGA Monitor ENET MR0626 6-10 hp AlphaServer TS15 Owner’s Guide...
Page 189: Srm Environment Variables For Com1
SRM Environment Variables for COM1 Several SRM environment variables allow you to set up the COM1 serial port for use with the RMC. You may need to set the following environment variables from the SRM console, depending on how you decide to set up the RMC. com1_baud Sets the baud rate of the COM1 serial port.
Page 190: Entering The Rmc
Esc key functions like the Ctrl/left bracket combination. To exit, enter the quit command. This action returns you to whatever you were doing on COM1 before you invoked the RMC. RMC> quit Returning to COM port 6-12 hp AlphaServer TS15 Owner’s Guide...
Page 191 Entering from the Local VGA Monitor (not recommended) To enter the RMC from the local VGA monitor, the console environment variable must be set to graphics and com1_mode must be set to through. Invoke the SRM console on the VGA monitor and enter the rmc command. >>>...
Page 192: Using The Command-Line Interface
• Use the Backspace key to erase input. • If you enter a nonexistent command or a command that does not follow conventions, the following message is displayed: *** ERROR - Unknown command *** 6-14 hp AlphaServer TS15 Owner’s Guide...
Page 193: Displaying The System Status
Table 6–1 explains the status fields. See Section 6.11 for information on the commands used to set the user-defined status fields. RMC> status hp AlphaServer TS15 Platform Status RMC Runtime Firmware Revision: V0.6-5 RMC Booter Firmware Revision: V1.0-0 System Power: ON...
Page 194: Table 6-1 Status Command Fields
Enabled = Dial-out for sending alerts is enabled. Disabled = Dial-out for sending alerts is disabled. Warning Alerts Warning alert status: Enabled = System warnings will generate alerts. Disabled = System warnings will not generate alerts. 6-16 hp AlphaServer TS15 Owner’s Guide...
Page 195 Field Meaning Alert Pending Alert pending status: YES = Alert condition is awaiting delivery. NO = No alert condition is awaiting delivery. Latest Alert Text string that describes the last alert generated on the system. Init String Initialization string that was set for modem. Dial String Dial string that is sent to modem when an alert occurs Alert String...
Page 196 NVRAM (RMC non-volatile storage): OK or FAIL GPIOs (GPIOs/PCF8574 IO Expander): OK or FAIL LM75 (Thermal sensor): OK or FAIL Watchdog timer Timer status: enabled or disabled Reboot status: enabled or disabled (see Section 3.2.2) 6-18 hp AlphaServer TS15 Owner’s Guide...
Page 197: Displaying The System Environment
6.6.2 Displaying the System Environment The RMC env command provides a snapshot of the system environment. RMC> env System Hardware and Environmental Status System Voltages: 1.65V 1.66V 2.5V 2.49V 3.3V Bulk : 3.37V 5V Bulk 5.14V 12V Bulk 12.24V -12V Bulk : -12.19V 3.3Vsb 3.30V...
Page 198: Using Power On And Off, Reset, And Halt Functions
When you issue the power on command, the terminal exits RMC and reconnects to the server’s COM1 port. RMC> power on Returning to COM port hp AlphaServer TS15 Remote Management Controller - Revision V1.1-0 RMC> power off RMC> 6-20 hp AlphaServer TS15 Owner’s Guide...
Page 199 RMC, and reconnects to the server’s COM1 port. Toggling the Power button on the operator control panel overrides the halt in condition. hp AlphaServer TS15 Remote Management Controller - Revision V1.1-0 RMC>halt in Returning to COM port hp AlphaServer TS15 Remote Management Controller - Revision V1.1-0...
Page 200: Configuring Remote Dial-In
RMC> clear alert RMC> disable modemdef RMC> enable remote Modem will be initialized when it is detected RMC> status hp AlphaServer TS15 Platform Status RMC Runtime Firmware Revision: V1.1-0 RMC Booter Firmware Revision: V1.1-0 System Power: ON System Halt: Deasserted...
Page 201 Alert Pending: NO Latest Alert: AC Loss Init String: AT&H2E0&C1&D0S0=2 Dial String: ATD915085554444 Alert String: ,,,,,,,,,,5551234 User String: Com1 Baud:9600 Flow:SOFTWARE Mode:THROUGH Modem:DISABLED Rmc:ENABLED Logout Timer: 20 minutes Voltage Status: OK Thermal Status: OK Thermal Shutdown: Enabled Warning Threshold: 60.00°C Fatal/Power-Down Threshold: 65.00°C Fan Status: OK...
Page 202 CONNECT 9600/ARQ/V34/LAPM RMC Password: ***** Welcome to RMC V1.1-0 >>> >>> hp AlphaServer TS15 Remote Management Controller - Revision V1.1-0 RMC> status hp AlphaServer TS15 Platform Status RMC Runtime Firmware Revision: V1.1-0 RMC Booter Firmware Revision: V1.1-0 System Power: ON...
Page 203: Example 6-2 Unsetting The Password
5. Intentionally type in an incorrect verification password. The following appears: *** ERROR – Password verification failed (Password is NOT set) *** NOTE: You also may reset RMC to use factory defaults. See section 6.10. Example 6–2 Unsetting the Password RMC>...
Page 204: Configuring Dial-Out Alert
Modem will be initialized when it is detected RMC> clear alert RMC> enable alert RMC> send alert RMC> status hp AlphaServer TS15 Platform Status RMC Runtime Firmware Revision: V1.1-0 RMC Booter Firmware Revision: V1.1-0 System Power: ON System Halt: Deasserted...
Page 205 User String: Com1 Baud:9600 Flow:SOFTWARE Mode:THROUGH Modem:DISABLED Rmc:ENABLED Logout Timer: 20 minutes Voltage Status: OK Thermal Status: OK Thermal Shutdown: Enabled Warning Threshold: 60.00°C Fatal/Power-Down Threshold: 65.00°C Fan Status: OK Fan Shutdown: Enabled PCI Riser: Installed POST DPR: OK NVRAM: OK GPIOs: OK LM75: OK Watchdog Timer: Disabled...
Page 206 NOTE: If you do not want dial-out paging enabled at this time, enter the disable alert command after you have tested the dial-out alert function. Alerts continue to be logged, but no paging occurs. 6-28 hp AlphaServer TS15 Owner’s Guide...
Page 207: Table 6-3 Elements Of Dial String And Alert String
Table 6–3 Elements of Dial String and Alert String Dial String The dial string is case sensitive. The RMC automatically converts all alphabetic characters to uppercase. AT = Attention. ATXDT X = Forces the modem to dial “blindly” (not seek the dial tone). Enter this character if the dial-out line modifies its dial tone when used for services such as voice mail.
Page 208: Rmc Firmware Update And Recovery
“No Update Available”. In order to update the booter, the write enable jumper (BOOTER_ENABLE – J22 7-8) must be installed first. If this jumper is not installed, the booter image update is not allowed. 6-30 hp AlphaServer TS15 Owner’s Guide...
Page 209: Example 6-4 Loadable Firmware Update Utility
Example 6–4 Loadable Firmware Update Utility Do you want to do a manual update? [y/(n)] y ***** Loadable Firmware Update Utility ***** ------------------------------------------------------------------- Function Description ------------------------------------------------------------------- Display Displays the system's configuration table. Exit Done exit LFU (reset). List Lists the device, revision, firmware name, and update revision.
Page 210 J22 pins 11-12, all three amber lights flash on and off in unison until the FW update is started. 5. For a complete listing of OCP LED indications, see Table 7-2. 6-32 hp AlphaServer TS15 Owner’s Guide...
Page 211: Resetting The Rmc To Factory Defaults
6.10 Resetting the RMC to Factory Defaults If the non-default RMC escape sequence has been lost or forgotten, RMC must be reset to factory settings to restore the default escape sequence. WARNING: To prevent injury, access is limited to persons who have appropriate technical training and experience.
Page 212 FORCE_DTR Jumper / J28 On – Forces DTR Off – DTR unaffected (default) • Booter_enable Jumper / J22 pins 7-8 On – Allows RMC booter image updates Off – Disables RMC booter image updates (default) 6-34 hp AlphaServer TS15 Owner’s Guide...
Page 213: Figure 6-5 Rmc Jumpers (Default Positions)
Figure 6–5 RMC Jumpers (Default Positions) Using the Remote Management Console 6-35...
Page 214: Rmc Command Reference
(if the dial-out alert feature is enabled). Once the current alert is cleared, the RMC can capture a new alert. The Alert Pending field of the status command becomes NO after the alert is cleared. 6-36 hp AlphaServer TS15 Owner’s Guide...
Page 215: Clear Port
clear log The clear log command clears all events from the system event log. clear port The clear port command clears the UARTs controlled by the RMC in an attempt to clear any ‘stuck’ conditions that might exist. disable alert The disable alert command disables the RMC from paging the system operator in the event that an alert condition is detected.
Page 216 The enable modemdef command instructs the RMC to append additional fixed commands to the user-supplied modem initialization string. These commands were automatically appended to the initialization string on older AlphaServer or AlphaStation models. See Table 6–4, which follows. 6-38 hp AlphaServer TS15 Owner’s Guide...
Page 217: Table 6-4 Initialization Commands With Modemdef Enabled
Table 6–4 Initialization Commands with MODEMDEF Enabled Modem Description Command &C1 Normal Carrier Detect (CD) operations &Kx Select flow control per the current COM1 settings, where x is as follows: 0: No flow control 3: Hardware flow control 4: Software (XON/XOFF) flow control 6: Both hardware and software flow control enable reboot The enable reboot command enables the watchdog timer to reset the system if the timer...
Page 218 The hangup command terminates the current modem session. A modem session automatically terminates after a period of idle time set by the set logout command (default = 20 minutes). help or ? The help or ? command displays the RMC command set. 6-40 hp AlphaServer TS15 Owner’s Guide...
Page 219: Power Off
help or ? command-word Issuing the command help or ? followed by the first word of another command provides additional information on all of the commands that start with the supplied word. The log command prints out a brief summary of the last 10 system events that have been logged.
Page 220 The set com1_mode command specifies the COM1 data flow path so that data either passes through the RMC or bypasses it. The available choices are: through, snoop, soft_bypass, firm_bypass. The set com1_mode command changes the setting of the SRM environment variable COM1_MODE. 6-42 hp AlphaServer TS15 Owner’s Guide...
Page 221 Com1_Mode Setting Description Through All data passes through RMC and is filtered for the escape sequence that is used to enter the RMC CLI. Snoop Data partially bypasses RMC, but RMC taps into data lines listening for the escape sequence that is used to enter the RMC CLI.
Page 222: Set Escape
This string is typically used to make notes about the current status of the system. The string is limited to 63 characters. status The status command displays information about the current status of the system and its RMC settings. (See section 6.6.1.) 6-44 hp AlphaServer TS15 Owner’s Guide...
Page 223: Troubleshooting Tips
6.12 Troubleshooting Tips This section covers possible causes of RMC problems and suggested solutions for them. Table 6–5 RMC Troubleshooting Symptom Possible Cause Suggested Solution You cannot enter the The RMC may be in soft bypass or Issue the show com1_mode RMC from the firm bypass mode.
Page 224 The display of these messages Set com1_mode to through display power on or power varies with the system state and mode or snoop mode. off error messages to the the setting of com1_mode. external RMC/COM1 port. 6-46 hp AlphaServer TS15 Owner’s Guide...
Page 225: Chapter 7 Troubleshooting
Before you begin troubleshooting your system, consult your service agreement to determine how much troubleshooting and repair you should undertake yourself. If you have a self-maintenance contract, use the information in this guide and the AlphaServer TS15 Service Guide to help identify and resolve the problem. Troubleshooting...
Page 226: Diagnostic Leds On Ocp
System Power Switch (On/Off) NOTE: Jumper J22 (pins 13 – 14) must be installed for the halt/reset button to function as a reset button. See the AlphaServer TS15 Service Guide for details on jumper locations and functions. hp AlphaServer TS15 Owner's Guide...
Page 227: Table 7-1 Ocp Switches
Table 7–1 OCP Switches Switch Function Halt/Reset System Power Switch (On/Off) Table 7–2 OCP LED Indications Color LED On Function Green System power is on. Green There is disk activity. Amber There is a fan fault. Amber The system is over temperature. Amber There is a system fault.
Page 228: Error Beep Codes
Check memory and memory configuration. 2-1-2 Configuration error detected Check system configurations. 1-1-4 ROM checksum error detected Replace the system board. 1-2-4 Bcache error detected Possible CPU problem. Figure 7–2 Circuit Breaker on Power Supply MR0667 hp AlphaServer TS15 Owner's Guide...
Page 229: Power Problems
Power Problems Table 7–4 Troubleshooting Power Problems If the power indicator is: Check: • Front-panel power switch • Power at the power distribution unit (PDU) • DC cords • Power cable connectors • Circuit breaker on power supply (see item preceding Figure 7–2.
Page 230: Console-Reported Failures
Enter the RMC and use the poe command to check for poweron errors; use the log or log # command to check the event log for symptoms of failure. Use the SRM test command to verify the problem. hp AlphaServer TS15 Owner's Guide...
Page 231: Boot Problems
Boot Problems Table 7–6 Troubleshooting Boot Problems Problem/Possible Cause Action Operating system (OS) Install the operating system and license key. software is not installed on the hard disk drive. Target boot device is not listed Check the cables. Are the cables oriented properly and in the SRM show device or not cocked? Are there bent pins? Check all the SCSI show config command.
Page 232: Thermal Problems And Environmental Status
Thermal Problems and Environmental Status Overtemperature conditions can cause the system to shut down. The AlphaServer TS15 system operates within an ambient temperature range of 5ºC to 40ºC (41°F to 104°F). An internal sensor monitors the system temperature and shuts down the system if maximum limits are exceeded.
Page 233: Operating System Reported Failures
Refer to the Guide to Kernel Debugging (AA-PS2TD- TE) for information on using the Tru64 UNIX Crash utility. Errors have been logged and the Examine the operating system error log files. operating system is up. Contact HP Services. Troubleshooting...
Page 234: Memory Problems
See Example 7–1. DIMMs may not have ECC bits. Some third-party DIMMs may not be compatible with AlphaServer TS15 systems. Ensure that memory DIMMs are qualified. Noticeable performance This could be a result of hard single-bit ECC errors degradation.
Page 235: Pci Bus Problems
3. Confirm that the PCI option card and any cabling are properly seated. 4. Check for a bad PCI slot by moving the last installed PCI option card to a different slot. 5. Contact HP Service to replace the PCI riser card. PCI Parity Error Some PCI devices do not implement PCI parity, and some have a parity generating scheme that may not comply with the PCI specification.
Page 236: Scsi Problems
Use a separate external controller card. • Ultra-wide SCSI has strict bus length requirements. • SCSI bus itself cannot handle internal plus external cable. • Use a separate card for external devices and terminate properly. 7-12 hp AlphaServer TS15 Owner's Guide...
Page 237: Fail-Safe Booter Utility
7.11 Fail-Safe Booter Utility The fail-safe booter utility (FSB) is another variant of the SRM console. The FSB provides an emergency recovery mechanism if the firmware image contained in flash memory becomes corrupted. You can run the FSB and boot another image from a CD- ROM or network that is capable of reprogramming the flash ROM.
Page 238: Starting The Fsb Manually
2. Insert jumper J8 over pins 1 – 2 on the system motherboard. See Figure 7–3. 3. Reinstall the system cover and reconnect the DC power cords and other cables. Power up the system to the FSB console. Figure 7–3 FSB Switch "On" Setting 7-14 hp AlphaServer TS15 Owner's Guide...
Page 239: Required Firmware
7.11.3 Required Firmware The required firmware for your system is preloaded onto the flash ROM. Copies of the firmware files are included on your distribution CD. You can also download the latest firmware files from the Alpha systems firmware Web site: ftp://ftp.digital.com/pub/Digital/Alpha/firmware/readme.html The utilities that are used to reload or update the firmware expect to find the files on a CD.
Page 240 3. Enter the list command to list devices and revision levels. 4. Enter update srm to update the SRM firmware. 5. Enter update rt to update RMC. 6. Enter exit to return to SRM. 7-16 hp AlphaServer TS15 Owner's Guide...
Page 241: Specifications
Appendix A Specifications This chapter contains the following system specifications and requirements: • Physical Specifications • Environmental Specifications • Electrical Specifications • Acoustics Specifications • Regulatory Approvals These specifications include data regarding compliance with Network Equipment Building System (NEBS) requirements. Specifications...
Page 242: A.1 Physical Specifications
A.1 Physical Specifications Table A–1 Physical Characteristics – AlphaServer TS15 Dimensions Height 13 cm (5.1 in.) Width 45 cm (17.6 in.) Depth 48 cm (19 in.) Weight Max: 18.6 kg (41 lb.) Shipping Container Height 82.4 cm (32.2 in.) Width 60.2 cm (24.0 in.)
Page 243: A.2 Environmental Specifications
A.2 Environmental Specifications Table A–3 Environmental Characteristics – All System Variants Temperature Operating 5° to 40° C (41° to 104° F) Short-term -5° to 50° C (23° to 122°F) Note: Max operating temp. at sea level. Reduce by 1.8° C/1000 m (1°...
Page 244: A.3 Electrical Specifications
Maximum inrush current (amps) According to ETS 30-132-2 A.4 Acoustics Table A–5 gives the acoustic noise declaration for an AlphaServer TS15 system with one to four hard disk drives (HDD). Table A–5 Acoustics Acoustics — Declared Values per ISO 9296 and ISO 7779...
Page 245: A.5 Regulatory Approvals
A.5 Regulatory Approvals Table A–6 Regulatory Approvals Agency approvals Bellcore NEBS GR-63-CORE Bellcore NEBS GR-1274 Bellcore SR-3580 Bellcore GR 1089-CORE, EMC requirements ETS 300 019 series, ETSI environmental conditions and test ETS 300 119-2, ETSI requirements for racks and cabinets ETS 300 132-2, DC system voltage requirements ETS 300 253, Earthling system requirements UL: Listed to UL1950 (3rd edition)
Page 246: A.6 References
A.6 References The following is a list of the references for the requirements met by the AlphaServer TS15 system. • Telcordia NEBS GR-63-CORE • Telcordia NEBS GR-1274 • Telcordia SR-3580 • Telcordia GR 1089-CORE, EMC requirements • CISPR 22, EMC emission requirements •...
Page 247 Index RMC, 6-36 Common components, 1-5 Alert string, 6-29 Components APB program, 3-21 common, 1-5 ATI Radeon card, installing, 4-32 Configuration auto_action environment variable, 3-3 front access storage cage, 1-16 Autoboot, 3-3 internal storage cage, 1-15 memory, 4-24 system, 1-2 Console devices, 5-54 Baud rate, setting, 5-42 Console password, 2-18...
Page 248 overview, 1-13 updating manually, 2-25 removing, 4-27 updating RMC, 6-30 disable wdt, 6-38 updating using BOOTP, 2-28 Disk drive status LEDs, 4-9 updating using MOP, 2-28 Diskettes, preparing for FSB, 7-15 Firmware update utility, 2-23 Display device Firmware updates selecting, 2-8 from floppy, 5-22 verifying, 2-8 sources, 4-37...
Page 249 Installing PCI modules, 4-28 Network connections, 1-9 Installing PCI options, 4-30 nvram script, 5-29 Installing Tru64 UNIX, 3-16 Internal storage cage, 1-15 Internet database, initializing, 3-9 OCP, 1-10 ISL boot program, 3-21 functions, 2-2 OCP messages, 2-3 OpenVMS Jumper J22, 1-10, 5-3, 5-51, 7-2 booting from InfoServer, 3-20 Jumper J41 booting from local CD-ROM, 3-18...
Page 250 Power-up display snoop mode, 6-7 SRM, 2-5 soft bypass mode, 6-7 SROM, 2-4 status command, 6-15 Power-up script, 5-29 terminal setup, 6-9 Through mode, 6-5 troubleshooting, 6-45 updating firmware, 6-30 QLogic controller, 5-52 RMC commands, 1-11 RMC halt in/out commands, 2-21 RMC quit command, 5-3 Rackmount configuration, 1-2 Reading a file, 5-27...
Page 251 SRM clear password command, 5-31, 5-36, Storage cage options, 1-15 5-37 System access lock, 1-20 SRM command notation, 5-5 System configuration, 1-2 SRM console, 2-7, 5-3 device naming, 2-14 overview, 5-2 Thermal problems, 7-8 power-up display, 2-5 Through mode, RMC, 6-5 SRM console commands, 5-4 Tools for installation, 4-1 SRM console prompt, 2-7, 5-2...

HP AlphaServer TS15 Owner's Manual

Preface

Chapter 1 System Overview

Chapter 2 Operating the System

Chapter 3 Booting and Installing an Operating System

Chapter 4 Installing and Configuring Options

Chapter 5 Using Firmware

Chapter 6 Using the Remote Management Console

Chapter 7 Troubleshooting

Specifications

Quick Links

Troubleshooting

Related Manuals for HP AlphaServer TS15

Summary of Contents for HP AlphaServer TS15
