Specification Clarifications

Specification Clarifications
The Specification Clarifications listed in this section apply to the following documents:
• Pentium® III Processor for the SC242 at 450MHz to 1.13GHz datasheet
• Pentium® III Processor for the PGA370 Socket at 500MHz to 1.13 GHz datasheet
• Pentium® III Processor on 0.13 micron process Up to 1.40 GHz datasheet
• Pentium® III Processor with 512KB L2 Cache datasheet
• Intel® 64 and IA-32 Architectures Software Developer's Manual Volume 1, 2a,
2b, 3a and 3b: System Programming Guide
All Specification Clarifications will be incorporated into a future version of the
appropriate Pentium III processor documentation.
Specification Clarification with respect to Time Stamp Counter
E1.
In the "Debugging and Performance Monitoring" chapter (Sections 15.8, 15.10.9 and
15.10.9.3) of the IA-32 Intel® Architecture Software Developer's Manual Volume 3:
System Programming Guide, the Time Stamp Counter definition has been updated to
include support for the future processors. This change will be incorporated in the next
revision of the IA-32 Intel® Architecture Software Developer's Manual.
15.8
The IA-32 architecture (beginning with the Pentium processor) defines a time-stamp
counter mechanism that can be used to monitor and identify the relative time
occurrence of processor events. The counter's architecture includes the following
components:
TSC flag — A feature bit that indicates the availability of the time-stamp counter.
•
The counter is available in an IA-32 processor implementation if the function
CPUID.1:EDX.TSC[bit 4] = 1.
IA32_TIME_STAMP_COUNTER MSR (called TSC MSR in P6 family and Pentium
•
processors) — The MSR used as the counter.
• RDTSC instruction — An instruction used to read the time-stamp counter.
• TSD flag — A control register flag is used to enable or disable the time-stamp
counter (enabled if CR4.TSD[bit 2] = 1).
The time-stamp counter (as implemented in the P6 family, Pentium, Pentium M,
Pentium 4, and Intel Xeon processors) is a 64-bit counter that is set to 0 following a
RESET of the processor. Following a RESET, the counter will increment even when the
