PKG-SVP01B-EN
Programming
(On air-cooled units with low ambient damper)
Actuator Setup
Direct/Reverse Act
Factory Presets: Direct Acting
Possible Values:
Direct Acting, Reverse Acting
1. Pressing the NEXT key will display the following screen.
(On air-cooled units with low ambient damper)
Actuator Setup
Max Stroke Time
Factory Presets: 60 Sec
Possible Values:
1-255 Sec
1. Pressing the NEXT key will display the following screen.
(On air-cooled units with low ambient damper)
Actuator Setup
Min Voltage
Factory Presets: 2.0 VDC
Possible Values:
0.0-9.9 VDC
1. Pressing the NEXT key will display the following screen.
(On air-cooled units with low ambient damper)
Actuator Setup
Max Voltage
Factory Presets: 10.0 VDC
Possible Values:
0.1-10.0 VDC
1. Pressing the NEXT key will display the following screen.
(On air-cooled units with low ambient damper)
Actuator Setup
Direct/Reverse Act
Factory Presets: Direct Acting
Possible Values:
Direct Acting, Reverse Acting
1. Pressing the NEXT key will display the following screen.
End of Submenu (NEXT) to Enter SETUP
1. Pressing the NEXT key will display the following screen.
SETUP
Num 1 Low Ambient
DIRECT ACTING
Num 2 Low Ambient
60 Sec
Num 2 Low Ambient
2.0 VDC
Num 2 Low Ambient
10.0 VDC
Num 2 Low Ambient
DIRECT ACTING
55
