Programming
(On units with hydronic heat)
Actuator Setup
Min Voltage
Factory Presets: 2.0 VDC
Possible Values:
1. Pressing the NEXT key will display the following screen.
(On units with hydronic heat)
Actuator Setup
Max Voltage
Factory Presets: 10.0 VDC
Possible Values:
1. Pressing the NEXT key will display the following screen.
(On units with hydronic heat)
Actuator Setup
Direct/Reverse Act
Factory Presets: Direct Acting
Possible Values:
1. Pressing the NEXT key will display the following screen.
(On air-cooled units with low ambient damper)
Actuator Setup
Max Stroke Time
Factory Presets: 60 Sec
Possible Values:
1. Pressing the NEXT key will display the following screen.
(On air-cooled units with low ambient damper)
Actuator Setup
Min Voltage
Factory Presets: 2.0 VDC
Possible Values:
1. Pressing the NEXT key will display the following screen.
(On air-cooled units with low ambient damper)
Actuator Setup
Max Voltage
Factory Presets: 10.0 VDC
Possible Values:
1. Pressing the NEXT key will display the following screen.
SETUP
Hydronic
2.0 VDC
0.0-9.9 VDC
Hydronic
10.0 VDC
0.1-10.0 VDC
Hydronic
DIRECT ACTING
Direct Acting, Reverse Acting
Num 1 Low Ambient
60 Sec
1-255 Sec
Num 1 Low Ambient
2.0 VDC
0.0-9.9 VDC
Num 1 Low Ambient
10.0 VDC
0.1-10.0 VDC
PKG-SVP01B-EN
