Expand Attack
Attack defines the duration between the input signal reaching the thresh-
old and processing being applied by the expander/gate. Attack time is
normally auto-sensing and program dependent. When Fast Attack is en-
abled, attack time is 1ms.
Fast Attack is active when the "F.ATT" LED is illuminated. To toggle Fast At-
tack, click the LED or its label text.
Dynamics Enable
and the expander/gate modules; neither module will function when DYN IN
is disabled. The dynamics modules are enabled when the green LED is illumi-
nated.
DYN IN is useful for quickly comparing the original signal dynamics to the dy-
namically processed signal.
Important:
expander/gate processing.
Expander In (EXP IN)
The EXP IN button enables the expander/gate module. The module is enabled
when the amber LED is illuminated. This button has no effect when DYN IN is
disabled.
Compressor In (CMP IN)
The CMP IN button enables the compressor/limiter module. The module is en-
abled when the red LED is illuminated. This button has no effect when DYN IN
is disabled.
The Expansion Meter uses green LED's (left column) to display the
Dynamics
Meters
amount of downward expansion occurring in the expander/gate
module. Higher values indicate more gain reduction.
The Compression Meter uses amber LED's (right column) to display
the amount of gain attenuation occurring in the compressor/limiter
module. Higher values indicate more dynamics compression.
UAD Powered Plug-Ins Manual
These three buttons determine the status of the dynamics
processors.
Dynamics In (DYN IN)
The DYN IN button enables both the compressor/limiter
DYN IN must be engaged to enable compressor/limiter and/or
- 529 -
Chapter 53: SSL E Channel Strip
