Transistor Output Units
Connector Pin Arrangement
Wiring
Dimensions
84
Pin number
Function
Attach a 25-pin D-sub connector to the Transistor Output Unit and connect it
to external devices.
Applicable Connectors
When creating your own cables, use one of the following connectors.
Manufacturer
OMRON
Note V terminals and G terminals are internally connected. When the I/O power is
being supplied, the power can be supplied to the output devices from the V
and G connectors. Current supplied in this way, however, must be less than
2.5 A.
Note The vertical center of the Unit is 4.9 mm lower than the center of the DIN
track. The Unit therefore extends downward 41.4 mm (including the mounting
hook) from the DIN track center.
13 12 11 10 9
G
NC NC NC V
Pin number 25 24 23 22 21
NC NC V G OUT
Function
15
Model number
XW2S-2513
XW2A-2501
Approx. 59
8 7 6 5 4 3
OUT OUT OUT OUT OUT OUT OUT OUT
07 06 05 04 03 02 01
20 19 18 17 16 15
OUT OUT OUT OUT OUT OUT OUT
14 13 12 11 10 09
Remarks
Hood
Plug
(Unit: mm)
Section 4-4
2 1
00
14
08
