Summary of Contents for Omron Programmable Terminals NT31 NT31C

Page 1 Cat. No. V062-E1-02 NT31 and NT31C Programmable Terminals Setup Manual...
Page 2 NT31and NT31C Programmable Terminals Setup Manual Revised January 2003...
Page 4 OMRON. No patent liability is assumed with respect to the use of the information contained herein. Moreover, because OMRON is constantly striving to improve its high-quality products, the information contained in this manual is subject to change without notice.
Page 6: Table Of Contents
TABLE OF CONTENTS PRECAUTIONS ....... . . 1 Intended Audience .
Page 7 SECTION 7 Troubleshooting and Maintenance Troubleshooting ............Responding to Displayed Error Messages Maintenance of the NT31/NT31C Inspection and Cleaning...
Page 8: About This Manual
About this Manual: This manual describes connecting the NT-series NT31 and NT31C Programmable Terminals to a PC (Programmable Controller) or other host and peripheral devices and the settings required for communica- tions and applications. It includes the sections described below. Please read this manual carefully and be sure you understand the information provided before attempting to install and operate the Programmable Terminal.
Page 9 Connecting and Setting Up the Programmable Terminal Programmable Terminal Functions and Operation Creating and Transferring Screen Data, and Installing the System Program Connecting to Controllers Not Made by OMRON TABLE OF CONTENTS Related manuals are listed below. The j symbol at the end of the catalog number is the revision number.
Page 10: Precautions
This section provides general precautions for using the Programmable Terminal. The information contained in this section is important for the safe and reliable application of the Programmable Ter- minal. You must read this section and understand the information contained before attempting to set up or operate a Programmable Terminal.
Page 11: Intended Audience
It is extremely important that Programmable Terminals and related devices be used for the specified purpose and under the specified conditions, especially in applications that can directly or indirectly affect human life. You must consult with your OMRON representative before applying Programmable Terminals to the above-mentioned applications. WARNING...
Page 12 Safety Precautions WARNING Do not attempt to take the unit apart and do not touch any internal parts while the power is being supplied. Doing either of these may result in electrical shock. WARNING Switch OFF the NT31/NT31C power before replacing the backlight.
Page 13: General
This section provides fundamental information about the functions and features of the PTs, types of connection, communica- tion methods, etc. This information will enable you to understand the applications of the PTs. Role and Operation of the NT31/NT31C 1-1-1 Operation of an NT31/NT31C at an FA Production Site 1-1-2 Operations of the NT31/NT31C Functions of the NT31/NT31C...
Page 14: Role And Operation Of The Nt31/Nt31C
Role and Operation of the NT31/NT31C Role and Operation of the NT31/NT31C The NT31/NT31C is a sophisticated display unit (programmable terminal) which automatically displays information and can also be used for operations when necessary. The following gives a general description of the role and operation of the NT31/NT31C for those using a programmable terminal (PT) for the first time.
Page 15: Role And Operation Of The Nt31/Nt31C
Role and Operation of the NT31/NT31C 1-1-2 Operations of the NT31/NT31C Displays Screens The information to be displayed (screen data) can be created on a computer us- ing the Support Tool and stored in the NT31/NT31C. The screen data can be displayed on the NT31/NT31C in response to instructions from the host or touch switch operation.
Page 16: Functions Of The Nt31/Nt31C
Functions of the NT31/NT31C Functions of the NT31/NT31C The NT31/NT31C has the following features. 1-2-1 Features Downsized Body • Slim body (50 mm or less in the panel*). • The communication cable connectors are housed in the unit so that they do not Construction Best Suited to the FA Environment •...
Page 17: Comparison Between Nt31 And Nt31C
Functions of the NT31/NT31C Screen Data Check Screen data can be checked simply by operations at the NT31/NT31C system Function menu, without connecting up to the Support Tool. Increased Screen Data The data capacity of 1 MB is twice that of the NT30/NT30C, enabling storage of a Capacity larger quantity of screen data.
Page 18: Additional Functions Of The V2 Versions
Functions of the NT31/NT31C 1-2-3 Additional Functions of the V2 Versions The V2 versions of NT31/NT31C are supplemented and enhanced by the fol- lowing functions. High-speed 1:N NT Link The V2 versions are compatible with the high-speed 1:N NT Link as well as the earlier standard 1:N NT Link.
Page 19: Comparison Between Nt30/Nt30C And Nt31/Nt31C
Terminal block NT30-CFL01/NT30C-CFL01 NT-ZS3AT-EV1 (including system installer) Not possible Exclusive use by Memory Link Shared with OMRON connection By a control on the rear of the unit Not possible Maximum of 2000 512 KB Maximum of 1000 Maximum of 1000...
Page 20 Functions of the NT31/NT31C Item Recipe function Accessible CS1 PC data areas *1: These functions are available only in V2 versions of the NT31/NT31C. *2: This is the capacity of the flash memory that stores screen data. *3: The values are the same as the NT30/NT30C when the PT is in NT30/620 compatible mode. *4: The window control area can be used only in the Vj versions of the NT31/NT31C.
Page 21: Principal Functions Of Nt31/Nt31C
Functions of the NT31/NT31C 1-2-5 Principal Functions of NT31/NT31C The following are the principal functions of the NT31/NT31C. Functions relating to data display Character display Characters of various sizes can be displayed. Characters can be flashed and displayed in reverse video.
Page 22: Recipe Function
Functions relating to data input Input by touch switches Data can be input by simply touching touch switches displayed on the screen. The possible functions of touch switches include sending data to the host and changing the screen display. Inputs can be enabled and disabled from the host when interlock bits have been allocated. Pop-up window function A window overlaying the currently displayed screen can be alternately opened and closed by pressing a touch switch.
Page 23: Displays
1-2-6 Displays The NT31/NT31C can display various kinds of elements such as characters, nu- meric values, graphs, lamps, and touch switches, on a screen. The screen data displayed by the NT31/NT31C are created by using the Support Tool at a per- sonal computer.
Page 24 Library data are combinations of fixed display graphics registered as a single graphic. They are registered in advance and as many as required can be dis- played at any position on the screen. Since it is generated by combining graphics, library data has a small data size. Lamps These are graphics whose display status changes in accordance with the states of bits at the host.
Page 25 Touch switches can be made to light or flash in accordance with the status of a host bit in the same way as lamps. The following 8 types of display graphic can be used for touch switches: Stan- dard, shadow, 3-dimension, no display frame, rectangle, circle, polygon, sector When rectangle, circle, polygon, or sector is selected as the shape, the area within which pressing of the touch switch is sensed (the touch switch area) can be set independently of the position where the display graphic is set.
Page 26 Thumbwheel Switches Numeric values can be input by incrementing or decrementing each digit with the corresponding touch switch (+, –). The input numeric values can also be stored in a numeral memory table and notified to the host. Thumbwheel switch inputs can be enabled and disabled from the host when an interlock bit has been allocated.
Page 27 Alarm List/History The alarm list/history function displays messages in list form, or graphics (image/library data), in accordance with changes in bit memory table statuses. For the alarm list, a series of bit memory tables are monitored, and messages (contents of character string memory tables) set for bit memory tables that come ON are displayed.
Page 28: System Configuration
EPSON control standards: ESC/P 24-J83C (color), or ESC/P 24-J82 (monochrome). NT-MF261 (made by OMRON) NT-series Support Tool Version 4.0 for Windows (Made by OMRON) • NT-ZJCAT1-EV4 (CD-ROM version) System installer (made by OMRON) The system installer is supplied as a standard accessory with the Support Tool (NTZJCAT1-EV4).
Page 29: Communications With The Host
Communications with the Host The NT31/NT31C is connected to the host by one of the following communica- tion methods. The following communications can be used to connect an OMRON PC: • Host link • 1:1 NT Link • 1:N NT Link (standard or high-speed) The following communications can be used to connect another companies’...
Page 30: Host Link
Communications with the Host The NT31/NT31C can directly write to and read from such allocated bits and words to change the display status of the elements on the PT screen, control the PT operating status, and notify statuses to the host. This function, which directly reads and writes the statuses of words and bits with- out using a PC program is called the direct connection function.
Page 31 PCs that can be connected with the 1:N connection NT Link method are as fol- lows: CQM1H, C200HX/HG/HE (-Z)E, CS1G/CS1H-E(V1). The NT31/NT31C also supports OMRON’s high-speed 1:N NT Link that pro- vides faster 1:N communications. The only PCs that support the high-speed 1:N NT Link are the -EV1 and higher versions of the CS1G/CS1H PCs.
Page 32: Communications Using Memory Links
Communications Using Memory Links 1-4-4 Connecting to other Companies’ PCs Installing a system program for multi-venders by using a specific system installer enables the NT31/NT31C to be connected to the PCs of other models in direct connection. This system installer is supplied with the Support Tool (NT- ZJCAT1-EV4).
Page 33: Comparison Between Direct Connection And Memory Link
Communications Using Memory Links • The usable area for allocation is the PT memory only. 1-5-2 Comparison between Direct Connection and Memory Link The major differences between the direct connection and the memory link are as follows: • In the memory link method, the communication with the host should be carried •...
Page 34: Before Operating
Before Operating Before Operating Follow the procedure given below to start the system of the NT31/NT31C. Host Set the host settings. • For the host link, refer to pages 54 and 101, and the manuals for the host link unit and peripheral tools.
Page 35 Before Operating Device or Software SYSMAC CPM1 Operation Manual SYSMAC CPM1A Operation Manual SYSMAC CPM2A Operation Manual SYSMAC CPM2C Operation Manual SYSMAC C200H Operation Manual (for CPU01/03/11) (programming) SYSMAC C200H Operation Manual (for CPU21/23/31) (programming) SYSMAC C200HS Installation Guide SYSMAC C200HS Operation Manual (programming) SYSMAC C200HX/HG/HE (-Z) Installation Guide SYSMAC C200HX/HG/HE Programming Manual SYSMAC C200HX/HG/HE-Z Programming Manual...
Page 36: Preparing For Connection
This section describes the connection methods that are possible with the PTs, and the functions of the parts of PTs, as the required knowledge before connecting to the host and to the peripheral devices. Method for Connection to the Host Names and Functions of Parts Preparing for Connection .
Page 37: Method For Connection To The Host
RS-232C Port and Section 5 Connecting to the Host from the RS-422A/485 Port. Converting the Communication Type with an RS-232C/RS-422A Convertor Unit The following communication type conversions are possible by using an RS-232C/RS-422A convertor unit (NT-AL001-E, made by OMRON). • RS-232C ⇔ RS-422A • RS-232C ⇔ RS-485 Communication...
Page 38 Method for Connection to the Host Combinations of Communication Method and Connection Method The connection methods that can be used depending on the communication method used and the communication type for communication between the NT31/NT31C and the host are indicated in the table below. Communica Communica- Communica-...
Page 39 Method for Connection to the Host Communica- Communica Communica Communica- tion Type at tion Type at Host 1:1 connection via a convertor unit 1:N connection via a convertor unit RS-232C RS 485 RS-485 Direct 1:1 connection 1:N connection RS-485 • The RS-232C/RS-422A convertor unit (NT-AL001) requires +5 V, 150 mA at •...
Page 40: Names And Functions Of Parts
Names and Functions of Parts Names and Functions of Parts Before starting operation, the names and functions of the parts of the NT31/NT31C are described here as a confirmation. A method of hardware set- tings is also described. Front View Reference: The NT31/NT31C comes in two body colors.
Page 41 Names and Functions of Parts Rear View GR terminal Grounding terminal to prevent malfunction due to noise. Power input terminals Connect the power to the NT31/NT31C at these terminals. Backlight unit (inside the cover) Open the cover to reveal the backlight. The backlight is off while the cover is removed.
Page 42: Hardware Settings And Connections
This section describes the settings of the PTs and methods for connection to peripheral devices. For details on connecting to the host, refer Section 4 Connecting to the Host from the RS-232C Port or Section 5 Connecting to the Host from the RS-422A/485 Port. Installation .
Page 43: Installation
Installation Note On unpacking the NT31/NT31C and peripheral devices, check their external ap- pearance and confirm that there is no damage. Also confirm that there is no ab- normal noise on shaking the unit lightly. Installation Install the NT31/NT31C in the operation panel and connect the power to the NT31/NT31C as described below.
Page 44: Power Supply Connection
Installation Note 3-1-3 Power Supply Connection Connect a 24 VDC power supply to the power input terminals. Note Power Supply The applicable power supply specifications are as follows. Parts Used for Connection Note For the connection to the power supply terminal block, twisted wires of 2 mm greater cross sectional area and M3.5 size crimp terminals must be used.
Page 45: Grounding
Installation 3-1-4 Grounding The NT31/NT31C has a functional ground terminal ( Carry out wiring under the following conditions. 1, 2, 3... Note Carry out grounding correctly in order to prevent operating errors due to noise. 1. In cases where the distance between the NT31/NT31C is small and it is as- sumed that there is no potential difference between grounds, ground as shown in Fig.
Page 46: Connecting To The Support Tool
Support Tool are started. Recommended Connector Cable Use the cable indicated below. • CV500-CN228 (length: 2 m), made by OMRON • XW2Z-S001 (conversion cable), made by OMRON • XW2Z-S002 (length: 2 m), made by OMRON For details on making a connector cable, refer to Appendix F Making the Cable for Connecting a PC (page 269).
Page 47: Connecting A Printer
NT31/NT31C may malfunction. Always turn off the power to the printer before connecting or disconnecting the cable. Recommended Connector Cable The following connection cables are recommended. • NT-CNT121 (1.5 m, 20-pin to 36-pin), made by OMRON Recommended Printers the printer status in the NT31/NT31C/NT631/NT631C Programmable Termi- nal Reference Manual.)
Page 48: Connecting A Bar Code Reader
Connecting a Bar Code Reader Connecting a Bar Code Reader Connecting a bar code reader to the NT31/NT31C enables bar code data to read as character strings into character string input fields, and set in character string memory tables. In order to use a bar code reader, the Comm. A Method memory switch must be set to Bar-Code Reader.
Page 49: Connecting A Bar Code Reader
Connecting a Bar Code Reader Settings at the Bar Code Make the settings shown in the table below at the bar code reader. Make sure Reader that the communications speed, parity, stop bit, and data bit settings match the communication settings made at the NT31/NT31C. For details on the setting method, refer to the instruction manual for the bar code reader used.
Page 50: Using A Memory Unit (-Vj Versions)
Using a Memory Unit (-Vj Versions) Using a Memory Unit (-Vj Versions) This section discusses the use of a memory unit with a V1 or V2 version of an NT31/NT31C PT (NT31-ST121j-EVj or NT31C-ST141j-EVj). Reference: Depending on the PT model and the system program which is installed, the func- tion and using method of memory unit varies as follows.
Page 51: Installation Method
Using a Memory Unit (-Vj Versions) S When a memory unit is mounted, the NT31/NT31C cannot be set to the oper- Reference: S Memory units (NT-MF261) can be used in common for the following PT mod- S One memory unit can store a system program for up to two PTs of different S The statuses of memory switch settings and system settings can be recorded 3-5-1 Installation Method Install the memory unit (NT-MF261) at the expansion interface connector at the...
Page 52 Using a Memory Unit (-Vj Versions) DIP Switch Functions The functions of the DIP switches on the memory unit are indicated in the table below. • SW1 • SW2 S The DIP switch function of the memory unit is supplemented to NT31/NT31C Reference: S In the following cases, a mode setting error occurs.
Page 53 Using a Memory Unit (-Vj Versions) Writing Screen Data to a In this mode, system program or the screen data in the NT31/NT31C is forcibly Memory Unit Using written to the memory unit irrespective of the setting status of the NT31/NT31C. Automatic Transmission This mode is convenient if the touch panel is broken and touch switch operation (PT to Memory Unit)
Page 54 Using a Memory Unit (-Vj Versions) Writing Screen Data to In this mode, the system program or screen data in the memory unit is forcibly the PT Using Automatic written to NT31/NT31C irrespective of the setting status of the NT31/NT31C. Transmission (Memory Since data transmission by this method is faster than when the Support Tool or Unit to PT)
Page 55 Using a Memory Unit (-Vj Versions) Reading and Writing Data In this method, the direction of transmission and area of the memory unit used by Manual Transmission are set by touch switch operations at the NT31/NT31C. Transmission can be executed while checking the settings. Reference: When data is written to the NT31/NT31C or memory unit, the data that has been stored up until that point is lost.
Page 56 Using a Memory Unit (-Vj Versions) The available transmitting destinations are altered depending on the settings of the origin of transmitting as described in the table below. S When transmitting the system program and screen data simultaneously from Reference: S When writing the system program into the NT31/NT31C, the type of system Errors When Using a If an error occurs when using the memory unit, the NT31/NT31C operates as Memory Unit...
Page 57 Using a Memory Unit (-Vj Versions) • The continuous buzzer sounds. • The RUN LED flashes. If a protect setting error occurs when executing manual transmission, it is pos- sible to return to the memory unit manual transmission screen by pressing the OK touch switch, but in the case of other errors, the status described above re- mains in effect until the NT31/NT31C power is turned OFF or reset.
Page 58: Using A Memory Unit (Versions Without The -Vj Suffix)
Using a Memory Unit (Versions without the -Vj Suffix) Using a Memory Unit (Versions without the -Vj Suffix) This section discusses the use of a memory unit with the basic versions of the NT31/NT31C PTs (NT31-ST121j-E or NT31C-ST141j-E). Reference: In this case, the function and use of the memory unit are the same as ones for the NT31/NT31C without the Vj suffix.
Page 59: Installation Method
Using a Memory Unit (Versions without the -Vj Suffix) 3-6-1 Installation Method Install the memory unit (NT-MF261) at the expansion interface connector at the rear of the NT31/NT31C as shown in the figure below. (The expansion interface connector is located underneath the note label.) 3-6-2 Method of Use As shown in the figure below, a memory unit has two sets of four DIP switches, and the operation is determined by the DIP switches that are set at startup.
Page 60 Using a Memory Unit (Versions without the -Vj Suffix) S In the following cases, a mode setting error occurs. Reference: S In the following case, a protect setting error occurs. S For details on mode setting errors and protect setting errors, refer to Errors Writing Screen Data to a In this mode, the screen data in the NT31/NT31C is forcibly written to the Memory Unit Using...
Page 61 Using a Memory Unit (Versions without the -Vj Suffix) Reference: When data is written to the NT31/NT31C, the data that has been stored up until that point is lost. Method of Execution Use the following procedure to write the screen data in the memory unit to the NT31/NT31C by automatic transmission.
Page 62 Using a Memory Unit (Versions without the -Vj Suffix) Current PT Screen Data The comment for the screen data in the NT31/NT31C is displayed here. Current Memory Unit Screen Data The comments for the screen data in each area are displayed here. Pressing the Trans.
Page 63 Using a Memory Unit (Versions without the -Vj Suffix) Flash memory error Verify error Error Probable Cause An error occurred during initialization of the NT31/NT31C or memory unit flash memory, or during write processing. An error occurred during verification processing at the flash memory of the NT31/NT31C or the memory unit.
Page 64: Connecting To The Host From The Rs-232C Port
Connecting to the Host from the RS-232C Port This section describes the method for connecting to the host using the RS-232C port of the PT. Connecting to the RS-232C Port at the Host 4-1-1 Host Types and Settings 4-1-2 Connecting Directly between RS-232C Ports .
Page 65: Connecting To The Rs-232C Port At The Host
This is the easiest connection method. Depending on the host to which the con- nection is to be made, it may be possible to use OMRON cables with connectors. Reference: The CS1 series CPU cannot be connected with the 1:1 connection NT link meth- od.
Page 66 Connecting to the RS-232C Port at the Host The host units that can be connected to the NT31/NT31C by the host link method using the RS-232C ports of both units are indicated in the table below. PC Se- Units with Built-in Host Link ries Function CS1 Se-...
Page 67 Connecting to the RS-232C Port at the Host Settings at the Host When using the host link method, the settings shown below must be made at the host (depending on the unit, some of these settings may not be necessary, or settings not shown here may be necessary).
Page 68 Connecting to the RS-232C Port at the Host C1000H(F)/C2000H Backplane mounted type: 3G2A5-LK201-EV1 Setting the Front Switches Setting the Rear Switches I/O port RS-422A RS-232C Synchronization Internal External Terminator External Local Host Mode control (key switch) Set this to host link. @ I/O port selection (selector switch) Set this to RS-232C.
Page 69 Connecting to the RS-232C Port at the Host C1000H/C2000H Backplane mounted type: C500-LK203 Setting the Rear Switches 5V supply I/O port RS-422A RS-232C Synchronization Internal External Terminator External Section @ I/O port selection (selector switch) Set this to RS-232C. @ Unit #, parity, and transfer code (DIP SW1-1 to SW1-7) Set SW1-1 to SW1-7 to OFF (0).
Page 70 Connecting to the RS-232C Port at the Host C200H/C1000H/C2000H CPU mounting type: 3G2A6-LK201-EV1 Setting the Rear Switches Connecting to a CVM1/CV Series Host Link Unit CVM1/CV series backplane mounted type: CV500-LK201 A CVM1/CV series host link unit (CV500-LK201) has two connectors (commu- nication ports 1 and 2).
Page 71 Connecting to the RS-232C Port at the Host Set the CPU bus unit settings directly from a Programming Device (e.g. SYS- MAC support software). For details on the CPU bus unit settings, refer to the SYSMAC CVM1/CV-series Host Link Unit Operation Manual (W205-E1-j). Setting the Front Switches Connecting to a CS1-series Serial Communication Unit CS1 series Backplane mounted type: CS1W-SCU21...
Page 72 Connecting to the RS-232C Port at the Host Allocation DM Area Settings for CPU Settings are written from the Programming Device (a Programming Console or CX-Programmer) directly into the allocation DM area (system setting area) of the CPU. After the settings are written, they become effective by turning the power ON, restarting the unit, restarting the communication port, or execution of the STUP command.
Page 73 Connecting to the RS-232C Port at the Host Setting the Front Switches C-series C200HS, C200HX/HG/HE(-Z)E, CPM1, CPM2A, CPM2C, CQM1, CQM1H CPUs, SRM1 The connection method depends upon the model of PC being used, as shown in the following table. I/O port selector switch RS-232C RS-422A PC model...
Page 74 Connecting to the RS-232C Port at the Host PC Setup Area Settings When connecting to a C200HS, C200HX/HG/HE(-Z)E, CPM1, CPM2A, CPM2C, CQM1, or CQM1H CPU, or SRM1, set the following communication conditions for the PC Setup area. Communication mode Communications speed Stop bit Parity Data length...
Page 75 Connecting to the RS-232C Port at the Host C200HX/HG/HE(-Z)E: Serial Communications Board port B CPM1: Peripheral port connection through a CPM1-CIF01 RS-232C Adapter Connecting to a CPM2C The CPM2C PCs do not have the same kind of port connectors found on CS1-series PCs.
Page 76 Connecting to the RS-232C Port at the Host When using the CQM1H’s built-in peripheral port, turn ON SW7. Setting the Switches of a CPM2A When using a CPM2A, the switches on the front panel must be set as shown below in order to make the PC Setup settings effective. Setting the Switches of a CPM2C When using a CPM2C, the switches on the front panel must be set as shown below in order to make the PC Setup settings effective.
Page 77 Connecting to the RS-232C Port at the Host CS1 series CPU type : CS1G/H-CPUjj-E (-V1) Connect to the built-in RS-232C port of the CPU, or the RS-232C port of the communication board. Note that the connection to a peripheral port must be made via an RS-232C adapter (CS1W-CN118) specially designed for connect- ing to a peripheral port.
Page 78 When Using the NT Link (1:1) Method Compatible Host Units Some models and series of OMRON PCs have the NT link (1:1) function built in. With CQM1H PCs, a Serial Communications Board can be added to provide 1:1 NT Link communications. Some C200HX/HG/HE(-Z)E CPUs can be connected by the NT link (1:1) method by installing a Communication Board.
Page 79 Connecting to the RS-232C Port at the Host The host units that can be connected to the NT31/NT31C by the NT link (1:1) method using the RS-232C ports of both units are indicated in the table below. Reference: CS1 series CPU cannot be connected with the 1:1 connection NT link method. Use the 1:N connection NT link method (standard or high-speed) instead to make the 1:1 connection.
Page 80 Connecting to the RS-232C Port at the Host Settings at The Host The setting methods for each unit are as follows: Connecting to a C-series C200HS, C200HX/HG/HE(-Z)E, CPM1, CPM2A, CPM2C, CQM1, CQM1H, or SRM1 PC Setup Area Settings Write the PC Setup area (data memory) settings directly from a Programming Device (e.g.
Page 81 Connecting to the RS-232C Port at the Host the front panel must be set as shown below in order to make the settings in the PC Setup area (data memory) effective. Setting the Switches of a CPM2A When using a CPM2A, the switches on the front panel must be set as shown below in order to make the PC Setup settings effective.
Page 82 Connecting to the RS-232C Port at the Host Connecting to CVM1/CV Series (-EVj) Set the DIP switches on the front panel as follows. When using the CVM1/CV series, CPU execution processing (execution control 2) in the PC Setup must be set to Simultaneous processing. Section I/O port selection (selector switch) Set this to RS-232C.
Page 83 Using the NT Link (1:N) Method Compatible Host Units The OMRON PCs that can be connected using the NT link (1:N) method are the CS1-series CS1G/H and the C-series C200HX/HG/HE(-Z)E, CQM1H, and SRM1 only. With the CS1-series PCs, it is possible to connect a 1:N NT Link us- ing a CS1W-SCU21 Serial Communications Unit.
Page 84 Connecting to the RS-232C Port at the Host Device (e.g. SYSMAC support software) in accordance with the host model and port. C200HX/HG/HE(-Z)E, SRM1 Built-in RS-232C port C200HX/HG/HE(-Z)E Communication Board port A CQM1H port 1 C200HX/HG/HE(-Z)E Communication Board port B Refer to the PC’s operation manual for details on changing PC Setup settings. Setting the DIP Switches of a C200HX/HG/HE(-Z)E When using a C200HX/HG/HE(-Z)E, the DIP switches on the front panel must be set as shown below in order to make the settings in the PC Setup area (data...
Page 85 Connecting to the RS-232C Port at the Host When connecting PT with its model number 0, 2-5 to the built-in RS-232C port, for example, set the value 8200 Hex to 160 CH, and 0005 Hex to 166CH. Either set PC Setup directly from a Programming Device (Programming Con- sole), or transmit the PC Setup made at a Programming Device (CX-Program- mer) to the CPU.
Page 86 Using the High-speed NT Link (1:N) Method Compatible Host Units Only the -V1 versions of OMRON’s CS1H and CS1G PCs support the high- speed 1:N NT Link directly. Other CS1-series PCs can use the high-speed 1:N NT Link indirectly through a CS1W-SCU21 Serial Communications Unit. (If a Serial Communications Unit is used, even CS1-series Units without the “-V1”...
Page 87 Connecting to the RS-232C Port at the Host Settings at the Host The Settings required for each Unit are described below. • Connecting CS1-series CPU Units CS1 series CPU type : CS1G/H-CPUjj-EV1 PC Setup When connecting to a CS1 series CPU, set the following communication condi- tions for the PC Setup area, in accordance with the communication port to be used.
Page 88 Connecting to the RS-232C Port at the Host Setting the Front Switches Set the CPU DIP switch to 4 or 5 in accordance with the port NT31/NT31C is connected to. Peripheral port This is used mainly for connection to the Programming Device.
Page 89 Connecting to the RS-232C Port at the Host Setting the Front Switches Set the unit number of the serial communication unit by using the rotary switch located on the front panel. Set each switch with a flat blade screwdriver so that the values or symbols in the setting value window agree with the following.
Page 90: Connecting Directly Between Rs-232C Ports
Note After connecting a communication cable, always secure it with the screws. Host link unit/CPU Serial port A (RS-232C, 9-pin type) Serial port B (RS-232C, 25-pin type) Cable with RS-232C connectors Name Model 9-pin XM2A-0901 Made by OMRON Connector Connector 25-pin XM24-2501 Made by OMRON 25-pin DB-25P Made by JAE...
Page 91 OMRON cables with connectors shown below are available. When a connection is made to a personal computer at serial port A in the memory link method, OMRON cable with connectors shown below are avail- able. When a connection is made at serial port B in other than the memory link meth- od, OMRON cables with connectors shown are available.
Page 92 Connecting to the RS-232C Port at the Host Serial Port A RS-232C interface Serial Port B NT31/NT31C RS-232C/ 422A/485 interface Wiring for Other Applicable units : Connections NT31/NT31C PC (host link unit) Abbreviation Abbreviation Shielding wire number number Connector hood –...
Page 93 Connecting to the RS-232C Port at the Host Cables with connectors that can be used at serial port A: Cables with connectors that can be used at serial port B: CPUs of CVM1/CV-series PCs without the suffix -EVj cannot be connected by any connection method.
Page 94 Connecting to the RS-232C Port at the Host Serial Port B Wiring for a Memory Link Cables with connectors that can be used at serial port A: Connection Serial Port A Prepare the adapter cable while referring to the following diagram. NT31/NT31C PC (Host link unit) Shielding wire...
Page 95 Connecting to the RS-232C Port at the Host Serial Port B Prepare the adapter cable while referring to the following diagram. NT31/NT31C Abbreviation Pin number Connector – RS-232C /422A/485 connector – – RDB (+) SDB (+) – – – SDA (–) RDA (–) –...
Page 96: Connecting To The Host From The Rs-422A/485 Port
Connecting to the Host from the RS-422A/485 Port This section describes the method for connecting to the host using the RS-422A/485 port of the PT. Connecting to the Host’s RS-232C Port 5-1-1 The Type of Host and Settings 5-1-2 1:1 Connection between RS-422A/485 at the PT and RS-232C at the Host 5-1-3 1:N Connection between RS-422A/485 at the PT and RS-232C at the Host 5-1-4...
Page 97: Connecting To The Host's Rs-232C Port
(By using the memory link method, a connection can be made to any arbitrary RS-232 unit). When making a connection to a host other than OMRON PCs, re- fer to the PC Connection Manual (V042-E1-j) or NT31/631 Multi Vendor Con- nection Manual (V060-E1-j).
Page 98: The Type Of Host And Settings
Connecting to the Host’s RS-232C Port Note One end of the wire must always be connected to the host (PC), and there must be no branching. Branching will cause problems such as transmission delays and communication failures. (At termination) Relay terminal block Max.
Page 99: 1:1 Connection Between Rs-422A/485 At The Pt And Rs-232C At The Host
Connecting to the Host’s RS-232C Port Settings at the When making a connection between RS-232C and RS-422A/485 ports using an RS-232C/RS-422A RS-232C/RS-422A convertor unit, set the DIP switches on the NT-AL001 as fol- Convertor Unit lows. (NT-AL001) Note Read the manual supplied with the NT-AL001 carefully before using the unit. 5-1-2 1:1 Connection between RS-422A/485 at the PT and RS-232C at the Host The connection method in which the RS-422A/485 port of an NT31/NT31C and...
Page 100 Connecting to the Host’s RS-232C Port Connecting an NT31/NT31C and NT-AL001 (RS-422A) NT31/NT31C In order to avoid an FG ground loop, do not make the connection between the functional ground of the NT-AL001 and the shielding. Connecting an NT31/NT31C and NT-AL001 (RS-485) NT31/NT31C In order to avoid an FG ground loop, do not make the connection between the functional ground of the NT-AL001 and the shielding.
Page 101 Connecting to the Host’s RS-232C Port Connecting an NT-AL001 and Host Wiring When Connecting a Host Link Unit (25-pin) Applicable units: Cables with connectors that can be used: CVM1/CV-series host link unit (CV500-LK201) has two types of connector: a 25-pin connector (communication port 1), and a 9-pin connector (communica- tion port 2).
Page 102 Connecting to the Host’s RS-232C Port Usable Cables with Attached Connectors: • For host link and 1:1 NT Link only (+5 V power wire attached) • For host link, 1:1 NT Link, or 1:N NT Link (+5 V power supplied from PC) CVM1/CV-series CPUs whose model names do not have the suffix -EVj can- not be connected by any connection method.
Page 103: 1:N Connection Between Rs-422A/485 At The Pt And Rs-232C At The Host
Connecting to the Host’s RS-232C Port Wiring for a Memory Link Connection Prepare the adapter cable while referring to the diagram shown below. Since it is necessary to input a voltage of +5 V to the number 6 pin of NT-AL001, supplying a voltage of 5 V from the host or an external voltage supply for NT- AL001 is required.
Page 104 Connecting to the Host’s RS-232C Port Connecting an The relay terminal board is not included in the figure below. Insert a relay termi- NT31/NT31C and nal board so as to achieve the wiring configuration indicated below. NT-AL001 (RS-422A) NT31/NT31C In order to avoid an FG ground loop, do not make the connections between the functional ground of the NT-AL001 and the shielding.
Page 105 Connecting to the Host’s RS-232C Port Connecting an The relay terminal board is not included in the figure below. Insert a relay termi- NT31/NT31C and nal board so as to achieve the wiring configuration indicated below. NT-AL001 (RS-485) NT31/NT31C In order to avoid an FG ground loop, do not make the connections between the functional ground of the NT-AL001 and the shielding.
Page 106 Connecting to the Host’s RS-232C Port Connection between The relay terminal board is not included in the figure below. Insert a relay termi- NT31/NT31C Units nal board so as to achieve the wiring configuration indicated below. (RS-422A) NT31/NT31C NT31/NT31C side RS-232C/ 422A/485 connector...
Page 107 Connecting to the Host’s RS-232C Port Connection between The relay terminal board is not included in the figure below. Insert a relay termi- NT31/NT31C Units nal board so as to achieve the wiring configuration indicated below. (RS-485) NT31/NT31C In order to avoid an FG ground loop, make the connection between the connec- tor hood and the shielding at the one side only.
Page 108: Recommended Connectors, Cables, And Crimp Terminals
(9-pin type) Since the CS1G/H, CQM1H, and C200HX/HG/HE(-Z)E have a +5 V output, no external power supply is required for the NT-AL001. Name Model 9-pin type XM2A-0901 Made by OMRON Connector 25-pin type XM2A-2501 Made by OMRON 25-pin type DB-25P...
Page 109 Connecting to the Host’s RS-232C Port Cables with Connectors Made by OMRON When connecting an NT-AL001 and a PC, use the OMRON cables with connec- tors indicated in the table below. Note The maximum tensile load of the recommended cable is 30 N. Do not exceed this load.
Page 110: Setting The Terminal Resistance For Rs-422A/485 Communications
When not using RS-422A/485 communications, the terminal resistance setting is ineffective. Name Model Maker 25-pin type XM2A-2501 Made by OMRON Connector 25-pin type DB-25P F-N Made by JAE 25-pin type XM2S-2511 Made by OMRON Connector...
Page 111: Connecting To The Host's Rs-422A/485 Port
The following discussion is focused on the connection method to OMRON PCs (By using the memory link method, a connection can be made to any arbitrary RS-422 unit). When making a connection to a host other than OMRON PCs, re- fer to the PC Connection Manual (V042-E1-j) or Multi Vendor Connection Manual (V060-E1-j).
Page 112: Host Types And Settings
When Using the Host Link Method Compatible Host Units Some models and series of OMRON PCs have the RS-422A/485 type host link This connection method can be used only with the NT link (1:N) method (standard or high-speed) of type RS-485.
Page 113 Connecting to the Host’s RS-422A/485 Port function built in. With the CS1-series and CQM1H, the host link method can be used by installing a serial communication board. In addition, some C200HX/HG/ HE(-Z)E devices have an integral CPU that can be connected in the host link method by installing a communication board.
Page 114 Connecting to the Host’s RS-422A/485 Port Settings at the Host When using the RS-422A type host link method, the settings shown below must be made at the host (depending on the unit, some of these settings may not be necessary, or settings not shown here may be necessary). The setting methods for each type of unit are described in the following.
Page 115 Connecting to the Host’s RS-422A/485 Port C1000H/C2000H rack-mounting type: 3G2A5-LK201-EV1 Setting the Front Switches Setting the Rear Switches Mode selector Host Local I/O port RS-422A RS-232C Synchronization Internal External Terminator External Section @ Mode selector (key switch) Set this to Host link. @ I/O port selection (selector switch) Set this to RS-422A.
Page 116 Connecting to the Host’s RS-422A/485 Port C1000H/C2000H rack-mounting type: C500-LK203 Setting the Rear Switches C200H/C1000H/C2000H CPU mounting type: 3G2A6-LK202-EV1 Setting the Rear Switches 5V supply I/O port RS-422A RS-232C Synchronization Internal External Terminator External @ Unit #, parity, and transfer code (DIP SW1-1 to SW1-5) Set SW1-1 to SW1-5 to OFF (0).
Page 117 Connecting to the Host’s RS-422A/485 Port Connecting to a CVM1/CV Series Host Link Unit CVM1/CV series rack-mounting type: CV500-LK201 A CVM1/CV series host link unit (CV500-LK201) has two connectors (commu- nication ports 1 and 2). To use the RS-422A type host link method, set commu- nication port 2 to RS-422A.
Page 118 Connecting to the Host’s RS-422A/485 Port Setting the Front Switches Connecting to a CPU Unit CVM1/CV-series (-EVj) CPUs • CV500-CPU01-EV1/CV1000-CPU01-EV1/CV2000-CPU01-EV1 • CVM1-CPU01-EV2/CVM1-CPU11-EV2/CVM1-CPU21-EV2 PC Setup When connecting to a CVM1/CV series CPU, set the following communication conditions for the PC Setup. Either set PC Setup directly from a Programming Device (e.g.
Page 119 Connecting to the Host’s RS-422A/485 Port Setting the Front Switches C200HX/HG/HE(-Z)E, CPM1, CPM2A, CPM2C, CQM1H, or SRM1 The connection method depends upon the model of PC being used, as shown in the following table. S There are no Communication Boards for the C200HX/HG/HE(-Z)E in which Reference: S There are no Serial Communication Boards for the CQM1H in which port 1 is PC Setup Area Settings...
Page 120 Connecting to the Host’s RS-422A/485 Port CQM1H CPUs or SRM1, set the following communication conditions for the PC Setup area. I/O port Communication mode Communications speed Stop bit Parity Data length Unit # Set the PC Setup area settings directly from a Programming Device (e.g. CX- Programmer).
Page 121 Connecting to the Host’s RS-422A/485 Port Connecting to a CPM2C The CPM2C PCs do not have the same kind of port connectors found on CS1-series PCs. The CPM2C’s communication port handles both RS-232C and peripheral port connections which are divided internally. Therefore, when using the CPM2C, it is necessary to select RS-232C or peripheral port connections, according to the kind of cable and port (on the cable) used, as shown in the fol- lowing table.
Page 122 Connecting to the Host’s RS-422A/485 Port Using the NT Link (1:1) Method Compatible Host Units Some models and series of OMRON PCs have the RS-422A type NT link (1:1) function built in. • The C200HX/HG/HE(-Z)E CPUs can be connected by the RS-422A type NT •...
Page 123 Connecting to the Host’s RS-422A/485 Port • Connecting to a CVM1/CV-series (-EVj) CPUs PC Setup When connecting to the CVM1/CV series CPU by the NT link (1:1) method, no particular settings are required at the PC Setup. Setting the Front Switches Connecting to a C-series C200HX/HG/HE(-Z)E or CQM1H PC Setup Area Settings Write the PC Setup area (data memory) settings directly from a Programming...
Page 124 Using the NT Link (1:N) Method Compatible Host Units The OMRON PCs that can be connected using the RS-422A/485 type NT link (1:N) method are the CS1G/H, C200HX/HG/HE(-Z)E, and CQM1H models only. A Serial Communications Board or a communications board must be installed to make the connection.
Page 125 Connecting to the Host’s RS-422A/485 Port For details on setting the PC Setup area settings, refer to the PC’s operation manual. S There are no Serial Communication Boards for the C200HX/HG/HE(-Z)E in Reference: S There are no Serial Communication Boards for the CQM1H in which port 1 is Setting the DIP Switches on a C200HX/HG/HE(-Z)E Communication Board Set the switches on a C200HX/HG/HE(-Z)E communication board as follows.
Page 126 Using the High-speed NT Link (1:N) Method Compatible Host Units Only OMRON’s CS1H and CS1G PCs support the high-speed 1:N NT Link through RS-422A/RS-485. The high-speed 1:N NT Link must be established through a CS1W-SCB41-E Serial Communications Board. (If a Serial Commu- nications Board is used, even CS1-series Units without the “-V1”...
Page 127 Connecting to the Host’s RS-422A/485 Port Settings at the Host Connecting to a CS1 Series Serial Communications Board Serial Communications Board equipped with an RS-422A/485 port for CS1-se- ries CPU Units: CS1W-SCB41 (Port 2 is an RS-422A/485 port.) Reference: Serial Communications Boards and Serial Communications Units with lot num- ber 991220 (12/20/99) and later support the high-speed 1:N NT Link.
Page 128: Direct Connection Between Rs-422A Ports At Both Units
Connecting to the Host’s RS-422A/485 Port When connecting to the host with the memory link method, it is necessary to create a program for the memory link at the host side. The following are the communication conditions that can be used with the memory link method.
Page 129 Connecting to the Host’s RS-422A/485 Port RS-232C/ 422A/485 connector In order to avoid an FG ground loop, do not connect the functional ground of the NT31/NT31C to the shielding of the RS-422A cable. Wiring When Connecting CPM1, CPM2A, CPM2C, or SRM1 Applicable units: Connect to the PC through a CPM1-CIF11 RS-422A Adapter.
Page 130 Connecting to the Host’s RS-422A/485 Port Wiring When Connecting a CS1-series CS1G/H Serial Communications Board, C series C200HX/HG/HE(-Z)E Communication Board, CQM1H Seri- al Communications Board, or CVM1/CV-series Host Link Unit Applicable units: RS-232C/ 422A/485 interface Wiring When Connecting a CVM1/CV-series CPU Applicable units: CS1G-CPU42-E(V1) CS1G-CPU44-E(V1)
Page 131 Connecting to the Host’s RS-422A/485 Port CVM1/CV-series CPUs whose model names do not have the suffix -EVj can- not be connected by any connection method. RS-232C/ 422A/485 connector In order to avoid an FG ground loop, do not connect the functional ground of the NT31/NT31C to the shielding of the RS-422A cable.
Page 132: Direct Connection Between Rs-485 Ports At Both Units
Connecting to the Host’s RS-422A/485 Port 5-2-3 Direct Connection between RS-485 Ports at Both Units The connection method in which the RS-485 ports of an NT31/NT31C and a host are connected is described here. Reference: When RS-485 is used at the PT side, only the NT link (1:N) method (standard or high-speed) can be used.
Page 133: 1:N Connection Among Rs-422A Ports
Connecting to the Host’s RS-422A/485 Port RS-232C/ 422A/485 connector In order to avoid an FG ground loop, do not connect the functional ground of the NT31/NT31C to the shielding of the RS-422A cable. 5-2-4 1:N Connection among RS-422A Ports The connection method in which the RS-422A ports of multiple NT31/NT31Cs and one host are connected in a 1:N connection is described here.
Page 134 Connecting to the Host’s RS-422A/485 Port S Communication using the RS-422A type standard NT link (1:N) method is Reference: S Communication using the RS-422A type high-speed NT link (1:N) method is Connecting between The relay terminal block is not included in this figure. Insert the relay terminal NT31/NT31C Units block so as to achieve the wiring configuration shown below.
Page 135 Connecting to the Host’s RS-422A/485 Port Wiring When Connecting a CS1-series CS1G/H Serial Communication Board, C Series C200HX/HG/HE(-Z)E Communication Board, or CQM1H Serial Communications Board Applicable units: RS-232C/ 422A/485 interface In order to avoid an FG ground loop, do not connect the functional ground of the NT31/NT31C to the shielding of the RS-422A cable.
Page 136: 1:N Connection Among Rs-485 Ports
Connecting to the Host’s RS-422A/485 Port 5-2-5 1:N Connection among RS-485 Ports The connection method in which the RS-485 ports of multiple NT31/NT31Cs and one host are connected in a 1:N connection is described here. S Communication using the RS-485 type standard NT link (1:N) method is pos- Reference: S Communication using the RS-485 type high-speed NT link (1:N) method is NT31/NT31C...
Page 137 Connecting to the Host’s RS-422A/485 Port Connecting between NT31/NT31C Units NT31/NT31C In order to avoid an FG ground loop, do not connect the functional ground of the NT31/NT31C to the shielding of the RS-422A cable. Connecting an The relay terminal block is not included in this figure. Insert the relay terminal NT31/NT31C and a Host block so as to achieve the wiring configuration shown below.
Page 138 − (9-pin type) − − RSB (+) RSA (−) − (25-pin type) Next PT Name Model Maker 25-pin type XM2A-2501 Made by OMRON Connector 25-pin type DB-25P F-N Made by JAE Section CS1H-CPU66-E(V1) C200HE-CPU42-(Z)E C200HG-CPU43-(Z)E C200HG-CPU63-(Z)E C200HX-CPU44-(Z)E C200HX-CPU64-(Z)E C200HX-CPU85-ZE CQM1H-CPU61 Abbreviation SDA (−)
Page 139 In order to set the terminal resistance, wiring work is required at the cable’s con- nector: carry out the wiring correctly by referring to APPENDIX E Making the Cable, page 267. Name Model Maker 25-pin type XM2S-2511 Made by OMRON Connector Connector hood 25-pin type DB-C2-J9 Made by JAE Tachii Electric...
Page 140 Connecting to the Host’s RS-422A/485 Port Shorted Open Note Before connecting or disconnecting cables between devices, make sure that the power supply to all of the connected devices (NT31/NT31C, PC, etc.) is OFF. S The internal circuit of the NT31/NT31C is shown below. Reference: S For details on setting the terminal resistance of the host unit, refer to setting Pin Nos.
Page 141: System Menu Operation
This section describes the operation of the System Menu, focusing on the procedure to start the PT. Functions that are conve- nient when using the PT and those that are useful for system maintenance are also explained here. System Menu Operation Flow Starting the NT31/NT31C 6-2-1 Operation at Startup...
Page 142 6-11 System Maintenance 6-11-1 I/O Settings 6-11-2 Displaying/Setting the Calendar and Clock 6-11-3 Checking the PT Setting Status 6-11-4 Displaying and Printing the Display History Record 6-11-5 Displaying and Printing the Alarm History Record 6-11-6 Checking Screen Data 6-11-7 Device Check 6-11-8 Checking Interfaces 6-12 Programming Console Function 6-12-1 Usable Systems...
Page 143: System Menu Operation Flow
System Menu Operation Flow System Menu Operation Flow Follow the procedure below when using the NT31/NT31C for the first time or changing the system program. Create the Screen Data Create the data to be displayed on the NT31/NT31C by using the Support Tool. For details on creating screen data, refer to the NT-series Support Tool Ver.
Page 144: Starting The Nt31/Nt31C
Starting the NT31/NT31C Starting the NT31/NT31C After checking that the hardware has been connected correctly, switch on the power to the NT31/NT31C to start it up. This section describes the operation of the NT31/NT31C when it is started up. 6-2-1 Operation at Startup The NT31/NT31C operates as follows when the power is switched ON, or when it is reset.
Page 145: Operation Modes And The System Menu
Operation Modes and the System Menu Operation Modes and the System Menu The NT31/NT31C operates in four modes: the RUN, Transmit, Maintenance, and Expansion modes. These modes are selected from the System Menu. In addition, the NT31/NT31C also features the System Installer mode which is used specifically for installing the system program.
Page 146 Operation Modes and the System Menu Items in the System The items displayed in the system menu and their functions are as follows. Menu Functions of the System The following functions can be executed in the System Installer mode. Installer Mode •...
Page 147: Menu Tree
Operation Modes and the System Menu 6-3-2 Menu Tree The System Menu allows the various functions of the NT31/NT31C to be executed by using touch switches displayed on the touch panel. The menu tree, starting from the System Menu, is shown below. For details on System Menu operations, refer to 6-3-3 Operations with the Sys- tem Menu (page 138).
Page 148: Operations With The System Menu
Operation Modes and the System Menu 6-3-3 Operations with the System Menu This section describes how to use the menus, including how to call the System Menu, how to call the System Installer mode, and how to select menu items. Calling the System Menu The System Menu can be displayed by either of the following two methods.
Page 149 Operation Modes and the System Menu NT31/NT31C, while pressing the touch switch at the top left corner of the touch panel (size: 7.2 mm Selecting Menu Items The menu items in the System Menu are displayed on the NT31/NT31C screen as touch switches.
Page 150: Memory Initialization
Memory Initialization Memory Initialization The NT31/NT31C has the following initialization functions. Use them as neces- sary. • Clearing screen data • Initializing memory tables • Initializing memory switches • Initializing display history record data • Initializing alarm history record data •...
Page 151 Memory Initialization Clear the screen data by following the menu operation from the System Menu shown below. If No is selected, the NT31/NT31C returns to the MEMORY INIT. MENU screen without clearing the screen data. On completion of screen data clearance, the NT31/NT31C returns to the MEMORY INIT.
Page 152: Memory Initialization
Memory Initialization 6-4-2 Initializing Display History Record Data The display history record function keeps a record of the order of display of the screens displayed during operation, and the number of times each screen is dis- played. These records are kept only for screens for which the History attribute has been set.
Page 153 Memory Initialization Initialize the display history record data by following the menu operation from the System Menu shown below. If No is selected, the NT31/NT31C returns to the MEMORY INIT. MENU screen without initializing the display history record data. On completion of display history record data initialization, the message Finished is displayed and the NT31/NT31C returns to the MEMORY INIT.
Page 154: Initializing Alarm History Record Data
Memory Initialization 6-4-3 Initializing Alarm History Record Data The alarm history record function continually checks the status of host bits that have been designated in advance with a bit memory table, and records the time when any of the bits is set to 1 (comes ON), and the number of times that each bit comes ON.
Page 155: Initializing The Recipe Tables
Memory Initialization Initialize the alarm history record data by following the menu operation from the System Menu shown below. If No is selected, the NT31/NT31C returns to the MEMORY INIT. MENU screen without initializing the alarm history record data. On completion of alarm history record data initialization, the message Finished is displayed and the NT31/NT31C returns to the MEMORY INIT.
Page 156 Memory Initialization Initialize the recipe tables by following the menu operation from the System Menu shown below. If No is selected, the NT31/NT31C returns to the MEMORY INIT. MENU screen without initializing the recipe tables. On completion of memory table initialization, the message Finished is displayed and the NT31/NT31C returns to the MEMORY INIT.
Page 157: Initializing The Memory Tables
Memory Initialization 6-4-5 Initializing the Memory Tables It is possible to initialize the numeral memory tables and character string memory tables in the NT31/NT31C. When these tables are initialized, the values are returned to those set by the Support Tool (they are not cleared). When the memory tables are initialized, they are returned to their initial values regardless of the setting made for the resume function (page 181).
Page 158 Memory Initialization Initialize the memory tables by following the menu operation from the System Menu shown below. If No is selected, the NT31/NT31C returns to the MEMORY INIT. MENU screen without initializing the memory tables. On completion of memory table initialization, the message Finished is displayed and the NT31/NT31C returns to the MEMORY INIT.
Page 159: Initializing The Memory Switches
Memory Initialization 6-4-6 Initializing the Memory Switches Initialization returns all the memory switches of the NT31/NT31C to their status on shipment. Initialize the memory switches by following the menu operation from the System Menu shown below. If No is selected, the NT31/NT31C returns to the MEMORY INIT. MENU screen without initializing the memory switches.
Page 160: Operations In The System Installer Mode
Operations in the System Installer Mode After initialization, the memory switch statuses are as follows. Start-up Wait Time Key Press Sound Buzzer Sound Printer Controller Print Method Screen Saver Movement Screen Saver Start up Time Hist. Disp. Method Resume Function Comm.
Page 161: Setting The Display Language In The System Installer Mode
Operations in the System Installer Mode 6-5-1 Setting the Display Language in the System Installer Mode The first setting made in the System Installer mode is to select whether the dis- play language is to be English or Japanese. 6-5-2 Clearing/Installing the System Program Use this function when the system program of the NT31/NT31C has been cor- rupted, or when installing a new system program.
Page 162: Operations In The System Installer Mode
Operations in the System Installer Mode Clearing the System Program • If Return to Menu is selected, the NT31/NT31C returns to the System Installer • If clearance fails, a screen asking whether you wish to try again is displayed. On completion of system program clearance, the NT31/NT31C enters the standby status for downloading of the system program.
Page 163: Changing The System Settings
Operations in the System Installer Mode 6-5-3 Changing the System Settings The NT31/NT31C allows the following settings to be made to prevent the screen data and memory switch settings from being changed or deleted by operating errors. Disabling/enabling System Menu Display When System Menu display is disabled by this setting, the System Menu cannot be displayed by touch panel operations or by using the touch switches.
Page 164: Clearing Screen Data
Operations in the System Installer Mode • If writing of the settings fails, a screen asking whether you wish to try again is After the settings have been written, the System Installer mode menu screen is redisplayed. 6-5-4 Clearing Screen Data If the screen data has been corrupted and the NT31/NT31C cannot be started normally, use this function to clear the screen data.
Page 165: Transmitting The Screen Data
Transmitting the Screen Data Transmitting the Screen Data The screen data is created with the Support Tool and then transmitted to the NT31/NT31C. This section explains how to transmit the screen data. For details on how to create the screen data and the operation of the Support Tool, refer to the Reference Manual and the NT-series Support Tool Ver.
Page 166 Transmitting the Screen Data If the screen data cannot be successfully transmitted from the Support Tool, use the communication check functions of the NT31/NT31C to check if communica- tion between the NT31/NT31C is normal or not (page 215). Precautions to Be If any of the following, or a system error, occurs during transmission of screen Observed When data, the transmitted screen data will not be registered correctly in the...
Page 167: Setting Conditions For Communications With Host By Using Memory Switches
Setting Conditions for Communications with Host by Using Memory Switches • Screen data transmission is stopped by operation at the Support Tool. Note When transferring the data in units of screens, if there are changes in memory table and/or direct access, transfer such data along with the screen data. Setting Conditions for Communications with Host by Using Memory Switches The NT31/NT31C can be connected to the host by the following 7 types of com-...
Page 168 (when using a system for multi-venders, refer to the PC Connection Manual (V042-E1-j) or NT31/631 Multi Vendor Connection Manual (V060-E1-j). Function A system program for OMRON model. None/Host Link/NT Link (1:1)/ NT Link (1:N) (standard or high-...
Page 169 Setting Conditions for Communications with Host by Using Memory Switches Serial port B None None Host Link NT Link (1:1) NT Link (1:N) (Standard or high-speed) Memory Link Combinations other than those indicated above cannot be set. Reference: When using serial port B for communication with the host, and serial port A for the transmission of screen data from the Support Tool, set the settings of serial port A to None.
Page 170: Setting The Host Link Method
Setting Conditions for Communications with Host by Using Memory Switches 6-7-2 Setting the Host Link Method Set the communication conditions for the host link method at serial port A or seri- al port B by following the operation from the System Menu shown below. Ver 3.10 Select Maintenance Mode.
Page 171 Setting Conditions for Communications with Host by Using Memory Switches • To quit the communications speed setting screen without setting the commu- On completion of communications speed setting, the NT31/NT31C returns to the memory switch setting screen (4/4). To set other memory switches, select the relevant screen using the [ ] (next screen) or [ ] (previous screen) touch switch, then make the setting.
Page 172: Setting The Nt Link (1:1) Method
Setting Conditions for Communications with Host by Using Memory Switches 6-7-3 Setting the NT Link (1:1) Method Set the communication conditions for the NT link (1:1) method at serial port A or serial port B by following the operation from the System Menu shown below. The setting option changes each time the touch switch is pressed.
Page 173: Setting The Nt Link (1:N) Method (Standard/High-Speed)
Setting Conditions for Communications with Host by Using Memory Switches 6-7-4 Setting the NT Link (1:N) Method (Standard/High-speed) Set the communication conditions for the NT link (1:N) method at serial port A or serial port B by following the operation from the System Menu shown below. The communications speed determines whether the 1:N NT Link is standard or high-speed.
Page 174 Setting Conditions for Communications with Host by Using Memory Switches • To quit the unit number/communications speed setting screen without confirm- Reference: Unit numbers are numbers assigned to each PT when multiple PTs are con- nected to one host, so that the host can identify the individual PTs. The units num- bers that can be set differ according to the host model, as follows.
Page 175: Setting The Memory Link Method
Setting Conditions for Communications with Host by Using Memory Switches 6-7-5 Setting the Memory Link Method Set the communication conditions for the host link method at serial port A or seri- al port B by following the operation from the System Menu shown below. Check the communication settings of the host to be used.
Page 176 Setting Conditions for Communications with Host by Using Memory Switches • To quit the communications speed setting screen without setting the commu- On completion of communications speed setting, the NT31/NT31C returns to the memory switch setting screen (4/4). To set other memory switches, select the relevant screen using the [ ] (next screen) or [ ] (previous screen) touch switch, then make the setting.
Page 177: Setting The Communication Type For Serial Port B
Setting Conditions for Communications with Host by Using Memory Switches 6-7-6 Setting the Communication Type for Serial Port B Set the communication type (RS-232C or RS-422A) for serial port B by following the operation from the System Menu shown below. Reference: f serial port B is used for RS-485 communications, RS-422A must be set as its communication type.
Page 178: Starting Operation
System Settings Starting Operation After completing screen data transmission and setting the communication conditions, connect the NT31/NT31C to the host and start operation. Note Check the operation of all screen data and host programs carefully before using them. If incorrect, the system may operate unpredictably. Switching to the RUN Press the Quit touch switch on the System Menu screen or other screen.
Page 179: Setting The Start-Up Wait Time
System Settings The four memory switch setting screens are shown below. [ ] (next screen) [ ] (previous screen) Memory Switch Settings A list of the memory switch settings is presented below. • Start-up Wait Time • Key Press Sound •...
Page 180: Setting The Key Press Sound
System Settings Set the system start-up wait time by following the menu operation from the Sys- tem Menu shown below. To set other memory switches, select the relevant screen using the [ ] (next screen) or [ ] (previous screen) touch switch, then make the setting. •...
Page 181: Setting The Buzzer Sound
System Settings Set the key press sound by following the menu operation from the System Menu shown below. To set other memory switches, select the relevant screen using the [ ] (next screen) or [ ] (previous screen) touch switch, then make the setting. •...
Page 182: Setting The Printer Controller
System Settings S There are other instructions and settings relating to the buzzer, but this Reference: S For details on the buzzer, refer to 2-15-5 Buzzer Function in the Reference Set the buzzer sound by following the menu operation from the System Menu shown below.
Page 183 System Settings • PC-PR201H: • PCL 5: Note that the NT31 can only be used with the monochrome Tone setting and does not support color printing. For the NT31, the Print Method is fixed as Tone. The default (factory) setting is ESC/P. S In addition to this setting, NT31C has the Print Method setting (page 174).
Page 184: Setting The Print Method (Nt31C Only)
System Settings 6-9-6 Setting the Print Method (NT31C Only) The NT31/NT31C has a function for printing out data at a printer connected to it in response to an instruction from the host or operation at the NT31/NT31C. When using the NT31C, the currently displayed screen image or other data can be printed out in color.
Page 185: Setting Screen Saver Movement
System Settings • To quit the memory switch setting screen without confirming the settings, press 6-9-7 Setting Screen Saver Movement The NT31/NT31C has a function to prevent the formation of an afterimage by turning off the screen display if no operation is performed for a certain period of time, and then displaying character strings at random positions and in random colors (the colors only change for the NT31C).
Page 186 System Settings Set the screen saver operation by following the menu operation from the System Menu shown below. To set other memory switches, select the relevant screen using the [ ] (next screen) or [ ] (previous screen) touch switch, then make the setting. •...
Page 187: Setting The Screen Saver Start-Up Time
System Settings 6-9-8 Setting the Screen Saver Start-up Time The NT31/NT31C has a function to maximize the service life of the backlight and prevent the formation of an afterimage by turning off the screen display and the backlight if no operation is performed for a certain period of time. The Screen Saver Start up Time setting determines the time interval before the screen saver function operates.
Page 188 System Settings Set the screen saver start-up time by following the menu operation from the Sys- tem Menu shown below. To set other memory switches, select the relevant screen using the [ ] (next screen) or [ ] (previous screen) touch switch, then make the setting. •...
Page 189: Setting The History Display Method
System Settings 6-9-9 Setting the History Display Method The NT31/NT31C features the display history record function, which records the time at which screens are displayed during operation and the number of times they are displayed, and the alarm history record function, which continually monitors bit statuses at the host and records the time when bits come ON and the number of times they come ON.
Page 190 System Settings Set the history display method by following the menu operation from the System Menu shown below. To set other memory switches, select the relevant screen using the [ ] (next screen) or [ ] (previous screen) touch switch, then make the setting. •...
Page 191: Setting The Resume Function
System Settings 6-9-10 Setting the Resume Function The NT31/NT31C has a function to keep the contents of the memory tables even when the power to the NT31/NT31C is OFF and write back them to the host when the power is turned ON. If the resume function is OFF, the memory tables are initialized to these initial values on switching to the RUN mode.
Page 192 System Settings Set the resume function by following the menu operation from the System Menu shown below. To set other memory switches, select the relevant screen using the [ ] (next screen) or [ ] (previous screen) touch switch, then make the setting. •...
Page 193: Setting The Automatic Reset Function
System Settings 6-9-11 Setting the Automatic Reset Function The NT31/NT31C has a function for ignoring communication errors and auto- matically returning to the RUN mode when they occur. The Comm. Auto-return setting determines whether the automatic reset func- tion is effective or not. •...
Page 194 System Settings Set the automatic reset function by following the menu operation from the Sys- tem Menu shown below. To set other memory switches, select the relevant screen using the [ ] (next screen) or [ ] (previous screen) touch switch, then make the setting. •...
Page 195: Setting The Time-Out Interval
System Settings 6-9-12 Setting the Time-out Interval The NT31/NT31C goes into the time-out error status if no response is received from the host within a fixed time. The Time-out Interval setting specifies the time lapse at which time-out is judged to have occurred. The setting range is 1 to 10 seconds.
Page 196: Setting The Retry Count
System Settings • To quit the memory switch setting screen without confirming the settings, press 6-9-13 Setting the Retry Count The NT31/NT31C does not immediately display an error screen when a commu- nication error occurs, but tries to re-establish communication. The Retry Counts setting specifies the number of attempts to be made to re-establish communica- tion.
Page 197 System Settings Set the retry count by following the menu operation from the System Menu shown below. To set other memory switches, select the relevant screen using the [ ] (next screen) or [ ] (previous screen) touch switch, then make the setting. •...
Page 198: Setting The Bar Code Reader Input Function
Setting the Bar Code Reader Input Function 6-10 Setting the Bar Code Reader Input Function The NT31/NT31C has a bar code reader input function which allows a bar code reader to be connected and bar code data to read as character strings into char- acter string input fields.
Page 199 Setting the Bar Code Reader Input Function Pressing Abort on the communication condition/confirmation method setting screen causes the NT31/NT31C to return to the memory switch setting screen (4/4) without executing setting (with the previous settings still effective). On completion of communication condition/confirmation method setting, the NT31/NT31C returns to the memory switch setting screen (4/4).
Page 200: Setting The Bar Code Reader Input Function
Setting the Bar Code Reader Input Function To set other memory switches, select the relevant screen using the [ ] (next screen) or [ ] (previous screen) touch switch, then make the setting. • To confirm the settings and quit the memory switch setting screen, press the •...
Page 201: System Maintenance
System Maintenance 6-11 System Maintenance The NT31/NT31C has the following maintenance and check functions. Item I/O Settings Adjustment of display panel contrast and brightness of the backlight. Calendar Check Display and setting of the time data of the NT31/NT31C clock function. Direct connection setting of the screen data in the NT31/NT31C and display of the PT Settings setting statuses of the serial ports.
Page 202 System Maintenance Setting from the System Menu Adjust the contrast of the display panel by following the menu operation from the System Menu shown below. Ver 3.10 Select Maintenance Mode. Select I/O Settings. Select Contrast Adjust. Adjust the contrast with the touch switches in the left half of the screen.
Page 203: System Maintenance
System Maintenance Setting Using Brightness and Contrast Adjustment Screen Display screen number 9030 using either a touch switch with switch screen func- tion, or by specifying the display screen in the PT status control area. Backlight Brightness The NT31/NT31C allows the brightness of the backlight to be adjusted in 3 Adjustment steps.
Page 204 System Maintenance Setting from the System Menu Adjust the backlight brightness by following the menu operation from the System Menu shown below. Ver 3.10 Select Maintenance Mode. Select I/O Settings. Select Brightness Adjust. Adjust the contrast with the High, Middle, and Low touch switches in the left half of the screen.
Page 205: Displaying/Setting The Calendar And Clock
System Maintenance Setting Using Brightness and Contrast Adjustment Screen Display screen number 9030 using either a touch switch with switch screen func- tion, or by specifying the display screen in the PT status control area. 6-11-2 Displaying/Setting the Calendar and Clock The NT31/NT31C has a clock function for setting and displaying the date and time.
Page 206 System Maintenance Display/set clock data by following the menu operation from the System Menu shown below. • Pressing Abort causes the NT31/NT31C to return to the date and time display Ver 3.10 Select Maintenance Mode. Select Calendar Check. Press Set. If you are just checking the display, press Quit at this point;...
Page 207: Checking The Pt Setting Status
System Maintenance 6-11-3 Checking the PT Setting Status The direct connection settings of the NT31/NT31C screen data, and the settings for serial port A and serial port B, can be checked. Screen Configuration and Display Contents There are the following three PT setting status screens. [ ] (next screen) [ ] (previous screen) Display Contents of The First Screen...
Page 208: Displaying And Printing The Display History Record
System Maintenance Display Method Display the PT setting statuses by following the menu operation from the System Menu shown below. 6-11-4 Displaying and Printing the Display History Record The display history record function is a function that records the order of display of each screen during operation, and the number of times each screen is dis- played.
Page 209 System Maintenance S With the NT31/NT31C, the record data can also be displayed by calling screen Reference: S For details on the display history record function, refer to 2-15-1 Display Histo- S The order of display for sort by occurrence display (from oldest record or from S The printing method and other information must be set in advance with the Display and print the display history record data by following the menu operation from the System Menu shown below.
Page 210: Displaying And Printing The Alarm History Record
System Maintenance Example Print-out All of the recorded data is printed out in the same order as on the currently dis- played screen. Example: Sort by occurrence, from oldest record 6-11-5 Displaying and Printing the Alarm History Record The alarm history record function is a function that continually monitors, during operation, the status of bits at the host designated in advance with a bit memory table, and records the time when these bits come ON, and the number of times they come ON.
Page 211 System Maintenance Display and print the alarm history record data by following the menu operation from the System Menu shown below. Ver 3.10 Select Maintenance Mode. Select Alarm History. Select Sort by Occurrence or Sort by Fre- quency. If necessary, select the next or previous screen by pressing [↓] (next screen) or [↑] (previous screen).
Page 212: Checking Screen Data
System Maintenance Example Print-out All of the recorded data is printed out in the same order as on the currently dis- played screen. Example: Sort by occurrence method, from oldest record 6-11-6 Checking Screen Data The NT31/NT31C allows the registered screens (Nos. 1 to 3999) to be displayed and checked by operation from the System Menu.
Page 213 System Maintenance Operations On The SCREEN DATA CHECK Screen The function shown below can be set on the SCREEN DATA CHECK screen. Use this function as required when displaying complex screens on which multi- ple display elements have been registered overlapping each other. a) Equivalent to 2 touch switches (14.4 mm) b) Equivalent to 2 touch switches (14.4 mm) a) Display the previous display element on the upper most portion of the...
Page 214 System Maintenance Displaying the SCREEN Display the SCREEN DATA CHECK screen by following the menu operation DATA CHECK Screen from the System Menu shown below. Ver 3.10 Select Maintenance Mode. Select Screen Data Disp. Specify the screen to be displayed in the input field in the middle of the screen.
Page 215: Device Check
System Maintenance If you wish to continue by checking another screen, repeat the operation, start- ing by specifying the screen number. To end the operation, press Quit on the screen number selection screen. The NT31/NT31C returns to the MAINTENANCE MODE MENU screen. 6-11-7 Device Check The NT31/NT31C provides checks on the functions of the following items.
Page 216 System Maintenance Reference: The buzzer will sound in this check regardless of the setting made with the Buzz- er Sound memory switch. Check the buzzer by following the menu operation from the System Menu shown below. • If the buzzer functions correctly, it will sound continuously. At this time, the •...
Page 217 System Maintenance Check the RUN LED by following the menu operation from the System Menu shown below. • If the RUN LED is functioning normally, it will operate as follows. At this time the • To end the LED check, press the LED Check touch switch on the DEVICE Ver 3.10 Select Maintenance Mode.
Page 218 System Maintenance Checking the LCD Check if the LCD (screen display) functions normally by following the menu op- (Screen Display) eration from the System Menu shown below. • The check screen displays all the dots on the screen: either press anywhere on •...
Page 219 System Maintenance Checking the Backlight Check if the backlight functions normally by following the menu operation from the System Menu shown below. • If the backlight is normal, it flashes. At this time, the Backlight Check touch • To end the backlight check, press the Backlight Check touch switch again. Screen Data Memory Check if the screen data memory is functioning normally.
Page 220 System Maintenance S Once a screen data check has been started, it cannot be stopped. Check the screen data memory by following the menu operation from the Sys- tem Menu shown below. • During the check, the message Checking Now... is displayed. Ver 3.10 Select Maintenance Mode.
Page 221 System Maintenance • On normal completion of the check, the message Memory Check OK is dis- • If an error is discovered in the check, the message Memory Check NG is dis- After confirming the result of the check, press Quit. The NT31/NT31C returns to the DEVICE CHECK MENU screen.
Page 222 System Maintenance Checking Touch Check whether or not the touch switches function normally by following the Switches menu operation from the System Menu shown below. To end the check, press the touch switch at the top right corner (NT31: displayed in reverse video;...
Page 223 System Maintenance S The functions of touch switches pressed during the I/O check are not notified Reference: S The check cannot be performed until the touch switch at the top right corner is to the host. displayed in reverse video (for NT31) or displayed in yellow (NT31C). Start the check after the status of the touch switch at the top right corner has changed.
Page 224 System Maintenance Checking the Battery Check the voltage of the NT31/NT31C’s built-in battery by following the menu Voltage operation from the System Menu shown below. After confirming the result of the check, press Quit. The NT31/NT31C returns to the DEVICE CHECK MENU screen. Ver 3.10 Select Maintenance Mode.
Page 225: Checking Interfaces
System Maintenance Note When The voltage is lowered is displayed, replace the built-in battery immedi- ately. For details on the replacement method, refer to 7-3-1 Replacing the Bat- tery (page 244). 6-11-8 Checking Interfaces The NT31/NT31C allows the following communication functions to be checked. •...
Page 226 System Maintenance Checking Check communication with the Support Tool by following the menu operation Communication with the from the System Menu shown below. Support Tool • If communication with the Support Tool is normal, data transmitted from the Ver 3.10 Select Maintenance Mode.
Page 227 System Maintenance After confirming the result of the test, press Quit. The NT31/NT31C returns to the I/F CHECK MENU screen. Checking Check communication at the serial ports (A, B). Communication at Serial Check Screen Ports The check screen and check method differ according to the communication method set for the port to be checked.
Page 228 System Maintenance For Memory Link Example: Serial port A while using the memory link The check is started as soon as the check screen is displayed. Send the com- mand from the host. • If communication with the host is normal, the data received from the host is dis- •...
Page 229 System Maintenance Check Method Check communication with the serial ports by following the menu operation from the System Menu shown below. After confirming the result of the check, press Quit. The NT31/NT31C returns to the I/F CHECK MENU screen. Ver 3.10 Select Maintenance Mode.
Page 230 System Maintenance Checking Check communication with a printer by following the menu operation from the Communication with a System Menu shown below. Printer • While data is being sent to the printer, the message Checking Now... is dis- • When the sending of data to the printer is completed, Finished Normal by Print- Ver 3.10 Select Maintenance Mode.
Page 231: Programming Console Function
Programming Console Function • If data does not reach the printer within 60 seconds after sending starts, the After confirming the result of the check, press Quit. The NT31/NT31C returns to the I/F CHECK MENU screen. 6-12 Programming Console Function The NT31/NT31C features has been equipped with the Programming Console function, which allows it to be used like a C200H-PRO27-E Programming Con- sole for CPM1, CPM2A, CPM2C, CQM1, CQM1H, C200HX/HG/HE (-Z)E,...
Page 232 Programming Console Function NT Link (1:1) NT Link (1:N) Reference: Note that the Programming Console function cannot be used with CPM1, CQM1, and C200HX/HG/HE PCs of the following lot numbers. CPM1: jjj5, jj*6 CQM1: jjj3, jjj4, jjj5, jj*6 C200HX/HG/HE: jjj5 jj*6 Commu- Commu- nication...
Page 233: Connection Method
Programming Console Function 6-12-2 Connection Method CQM1, CQM1H, The connection method is exactly the same as for the NT Link (1:1). Refer to C200HX/HG/HE(-ZE), or Section 4 Connecting to the Host from the RS-232C Port or Section 5 Connect- SRM1 ing to the Host from the RS-422A/485 Port for details on connecting to the PC.
Page 234: Method Of Use
Programming Console Function 6-12-3 Method of Use The Programming Console screen is displayed by operating the system menu as described below. Reference: When an error screen is displayed, the system menu can be displayed by press- ing two of the four corners of the touch panel simultaneously. The Check touch switch on the screen can also be used to display the system menu, but it will not work unless the cause of the error has been removed.
Page 235 Programming Console Function Key Operations Mode Selection Keys, Mode Lock Key The display element on the Programming Console screen shown below com- prises the mode selection keys, which change the operation mode of the PC, and the mode lock key, which prevents unintended mode changes. The RUN, MONITOR, and PROGRAM mode selection key elements are touch switches and pressing them causes the PC operation mode to change (unlike an actual Programming Console, it is possible to switch directly between the RUN...
Page 236 Programming Console Function Standard Programming Console Key Sheet Programming Console Key Sheet for CS1 Series Differences with Respect to Programming Consoles • Programs cannot be stored (recorded) or read (replayed). If it is necessary to • It is not possible to adjust the volume of the key press sound. Whether or not •...
Page 237: Device Monitor Function
Device Monitor Function 6-13 Device Monitor Function The NT31/NT31C has been equipped with the Device Monitor function which can be used to change the PC’s operating mode, read/change words in the PC’s data areas, and display the PC’s error log of a CS1G/CS1H, CPM1, CPM2A, CPM2C, CQM1, CQM1H, C200HX/HG/HE(-Z)E, or SRM1.
Page 238: Connection Method
Device Monitor Function 6-13-1 Compatible Systems The following table shows the combinations of communications methods and PCs that can support the PT’s Device Monitor function. 6-13-2 Connection Method The 1:1 NT Link or 1:N NT Link can be used. The connection method is exactly CQM1H or C200HX/HG/HE(-ZE) the same as for the 1:1 NT Link or 1:N NT Link.
Page 239: Method Of Use
Device Monitor Function CN111 or CS1W-CN114/118 Connecting Cable, a CPM1-CIF01 RS-232C Adapter, or a CPM1-CIF11 RS-422A Adapter. Refer to Section 4 Connecting to the Host from the RS-232C Port or Section 5 Connecting to the Host from the RS-422A/485 Port for details on connecting to the PC.
Page 240: Version Display
Version Display 6-14 Version Display Use the Version Display function to check the version of the NT31/NT31C’s sys- tem program. The Version Display screen shows the model, creation date, and version of the system program installed in the NT31/31C. 6-14-1 Method of Use The Version Display screen is displayed by operating the system menu as de- scribed below.
Page 241 This section describes the action to take when errors occur in the PT, and how to carry out maintenance and inspection to prevent the occurrence of errors. Troubleshooting ............Responding to Displayed Error Messages 7-2-1 Errors Occurring at Start of Operation and Their Remedies...
Page 242: Troubleshooting
Check the connections and make sure that power is supplied correctly. (3-1-3 Power Supply Connection, page 33) Contact your OMRON service center. This is not an error. Change the screen number from screen number 0. (Setting the screen number to 0 turns the screen off.) This is not an error.
Page 243 Check the model of PC you are using. (6-12 Programming Console Function, page 221) The Programming Console function can be used only when the system program for OMRON PCs is installed. Install the correct system program. Set the communication method as follows when using the Device Monitor function.
Page 244: Troubleshooting
Troubleshooting NT31/NT31C Symptoms Updating of numeric Malfunction due to external noise values and text is delayed. There are too many numeral/text displays on the displayed screen. The cycle time is extended due to heavy processing at the host. In an RS-422A/485 connection, there is illegal branching or an erroneous terminator setting.
Page 245: Responding To Displayed Error Messages
Clearing Screen Data, page 140) - Transmission of screen data If the problem persists, contact your was interrupted. OMRON service center. - Illegal data has been written to the screen data memory. No screen data is registered. Transmit screen data from the Support Tool.
Page 246 Or the screen number which Configuration at the Support Tool. does not exist are registered. The touch panel cable (film Contact your OMRON service center. cable) inside the NT31/NT31C is disconnected. The memory switches have been Set the memory switches again using the...
Page 247: Responding To Displayed Error Messages
Responding to Displayed Error Messages 7-2-2 Errors Occurring during Operation and Their Remedies The table below shows the errors that can occur during operation of the NT31/NT31C and their remedies. Message [Address Setting Error] The host side allocated words and bits set with the Support Tool Addressing Error exists in the are incorrect.
Page 248: Errors Occurring On Screen Data Initialization And Transmission
Cause If the same message is displayed even after clearing the screen data or transmitting screen data several times, contact your OMRON service center. Set the calendar clock again from the System Menu. If the problem recurs, delete the program in the System Installer mode, then re-install the program.
Page 249: Errors In The System Installer Mode And Their Remedies
(memory for storing the system selection of Download System Program and program) has reached its life. attempting to delete the system program several times, contact your OMRON service center (6-5-2 Clearing/Installing the System Program, page 151). - A communication error...
Page 250 Responding to Displayed Error Messages Example: Parity error at serial port A Receive Errors The following errors can occur when receiving data. • Parity error • Framing error • Overrun error • FCS (sum value) error • Time out error •...
Page 251: Maintenance Of The Nt31/Nt31C
Maintenance of the NT31/NT31C Error Details Displayed Probable Cause Time-out Error The connecting cables are not connected correctly. (Send/Receive) The communication service of the host is stopped. (Send/Receive) Time-out Interval is too short. (Send) Time-out Interval is too short. (Receive) PC Unit No.
Page 252 Maintenance of the NT31/NT31C Replaceable Backlight Model NT31C-CFL01 (for both NT31 and NT31C) Guide to Backlight Replacement Under normal conditions it can be assumed that the backlight will need to be re- placed after about 25,000 hours when used at medium brightness (the figure is about 10,000 hours when used at the high brightness setting).
Page 253 Maintenance of the NT31/NT31C c) When the cover has opened far enough, remove it. 4. Remove the CFL unit by following the procedure described below. a) Disengage the connector. b) Sufficiently loosen the screw that secures the CFL unit. The screw is designed so that it cannot be removed, but if it does come out for some reason and falls inside the NT31/NT31C, it must be extri- cated without fail.
Page 254: Replacing The Battery
Maintenance of the NT31/NT31C 7-3-1 Replacing the Battery The NT31/NT31C uses a lithium battery to back up the memory contents. The battery life is about 5 years if the NT31/NT31C is used in a location where the ambient temperature is 25_C. If the temperature at the location of use is higher than this, the battery life will be shorter.
Page 255: Inspection And Cleaning
Inspection and Cleaning Inspection and Cleaning Clean and inspect the NT31/NT31C regularly to ensure that it is always used in its optimum condition. Cleaning Method If the display is dirty the screen is difficult to see. Clean the screen from time to time as follows.
Page 256 OMRON ad- dress indicated on the back cover of this book. Section Inspection...
Page 257: A Specifications
General Specifications Item Rated power supply voltage Allowable power supply voltage range Allowable power interruption time Power consumption Operating ambient temperature Storage ambient temperature Operating ambient humidity Operating environment Noise resistance Vibration resistance (operating) Shock resistance (operating) Dimensions Weight Panel cutout dimensions Enclosure ratings Grounding * The NT31/NT31C may not be used at a location where it is exposed to splashing oil for a long period.
Page 258: Performance Specifications
Specifications Performance Specifications Display Specifications Item Display device Number of dots (resolution) Size of a standard character Effective display area Display panel View angle Display color Life expectancy (until brightness reduced by half) Contrast adjustment Contrast adjustment t dj Life expectancy Backlight Backlight Replacement...
Page 259: Special Features
No. 6. The +5 V output of the unit delivers +5 V " 5% and 250 mA maximum. Programming Environment Item Programming System Programming support software Programming Tool Programming support software: NT-series Support Tool for Windows (Ver. 4.0), by OMRON Special Features Item Three kinds of buzzer sound (continuous, short intermittent, and long intermittent) OFF: Buzzer Setting: The buzzer sounds three times in response to prohibited input.
Page 260 Specifications Item Functions: - Prints a hard copy of the screen display Setting: Screen print function - Displays the current time in accordance with the built-in clock Calendar and clock function - Displayed and set with “Calendar Check” in the “MAINTENANCE MODE” menu Executes functions equivalent to those of al C200H-PRO27-E Programming Console for CPM1, CPM1A, CPM2A, CPM2C, CQM1 (-EV1 only), CQM1H, Programming Console function...
Page 261: Communications Specifications
Specifications Communications Specifications For a Host Link , RS-232C Type Item Communications standard EIA RS-232C Start-stop synchronization Communications speed: Communications settings Data length: Stop bit: Parity: 9-pin D-SUB connector (female) (serial port A) Connector 25-pin D-SUB connector (female) (serial port B) Number of units connected Transmission distance Max.
Page 262 Specifications For an NT Link , 1:1, RS-422A Type Item Communications standard EIA RS-422A Connector 25-pin D-SUB connector (female) (serial port B) Number of units connected Transmission distance Max. 500 m For an NT Link , 1:N, RS-232C Type Item Communications standard EIA RS-232C 9-pin D-SUB connector (female) (serial port A)
Page 263 Specifications For a Memory Link , RS-232C Type Item Communications standard EIA RS-232C Start-stop synchronization Communications speed: Data length: Communications settings Stop bit: Parity: Flow control: Response: Connector 9-pin D-SUB connector (female) (serial port A) 25-pin D-SUB connector (female) (serial port B) Number of units connected Transmission distance Max.
Page 264: B Dimensions
Appendix B Dimensions Body 183.5 (7.22) POWER 142 (5.59) 130.5 (5.14) 5 (0.20) 195 (7.68) 54 (2.13) With memory unit installed Units: mm (inch) (NT-MF261) 74 (2.91)
Page 265: Mounting Dimensions
Dimensions Mounting Dimensions POWER 25 (0.98) 15.5 (0.61) 145 (5.71) 206 (8.11) Appendix B Mounting panel Mounting fixture 153 (6.02) 5 (0.2) 34 (1.34) (min.) 38 (1.5) (max.) Units: mm (inch)
Page 266 Dimensions Appendix B Cable Connection Dimensions (with NT-MF261) 96 (3.78) 10.2 (0.47) 91 (3.58) 26.7 (1.05) PRINTER PORT B PORT A 5 (0.20) 50 (1.97) 60 (2.36) Units: mm (inch)
Page 267: C Using An Rs-232C/Rs-422A Convertor Unit
Using an RS-232C/RS-422A Convertor Unit This section outlines the external dimensions, procedure for mounting and removal, and specifications of an RS-232C/RS-422A convertor unit (NT-AL001-E). Refer to this information when designing the control panel. For details, refer to the instruction manual supplied with the NT-AL001-E. Dimensions 30 (W) 114 (H)
Page 268 Using an RS-232C/RS-422A Convertor Unit Removal from a DIN Rail Remove the end plates at right and left of the convertor unit and, as shown in the figure below, insert a flat blade screwdriver into the rail stopper at the bottom face of the convertor unit and prize it free. Mounting to an Operation Panel Drill two mounting screw holes in an operation panel with a thickness of at least 2 mm (0.08 inch) and secure the convertor unit with screws.
Page 269: Specifications
Using an RS-232C/RS-422A Convertor Unit Specifications The general specifications and communications specifications of the convertor unit are shown below. General Specifications Item Dimensions Weight Operating ambient temperature Operating ambient humidity Rated power supply voltage Rated power supply current Rush current Insulation resistance Dielectric strength Operating environment...
Page 270: Dip Switch Settings
If the power is turned on while there is a wiring fault, the internal circuits of the convertor unit or the RS-232C device may be damaged. 4. When the convertor unit is connected to a C200HX/HG/HE (-ZE), CQM1H, CS1G/H model of OMRON PC as an RS-422A device, set DIP switches SW1-5 and SW1-6 as indicated below.
Page 271: Pin Arrangement
Using an RS-232C/RS-422A Convertor Unit Pin Arrangement The convertor unit has a terminal block for an RS-422A/485 interface connection and a connector for an RS-232C interface connection. The pin arrangements for the RS-422A/485 terminal block and the RS-232C connector are as follows. RS-422A/485 Terminal Block Terminal block pin...
Page 272 Using an RS-232C/RS-422A Convertor Unit Block Diagram A diagram showing the internal blocks of the convertor unit is shown below. Refer to this diagram when making cables yourself, or when connecting devices with special interfaces. RS-232C side D-SUB 9P CASE POWER Fuse +5 V...
Page 273: Transporting And Storing The Nt31/Nt31C
Transporting and Storing the NT31/NT31C • When transporting the NT31/NT31C, use the packaging intended for it. • When storing the NT31/NT31C, observe the following conditions. Storage ambient temperature: Storage ambient humidity: Appendix D –20 to +60_C 35% to 85%...
Page 274: E Making The Cable
The procedure for making up the cable is described below. Also refer to this procedure for making a connecting cable for use with RS-422A/485 type connections. Cable Preparation The preparation of the cable differs according to whether or not the shielding wire is to be connected to the FG. Cable with Shielding Wire Connected to FG 1, 2, 3...
Page 275 Making the Cable 5. Wrap vinyl tape over the cut off end of the shielding wire. Soldering 1, 2, 3... 1. Slide heat-shrink tube over each wire. 2. Pre-solder each wire and connector terminal. 3. Solder each wire to each connector terminal. 4.
Page 276: F Making The Cable For Connecting A Pc
Appendix F Shielding wire Connector hood Model 25-pin, made by OMRON, for personal computer side 9-pin, made by OMRON, for PT side 25-pin, made by OMRON, for personal computer side 9-pin, made by OMRON, for PT side Multi-core shielded cable, made by Fujikura Ltd.
Page 277: G Making The Cable For Connection To A Bar Code Reader
Abbr. Pin No. RS-232C interface +5 V Model 9-pin type, made by OMRON, PT side 9-pin, made by OMRON Multi-core shielded cable, made by Fujikura Ltd. Multi-core shielded cable, made by Hitachi Cable, Ltd. Bar code reader side Abbr. +5 V...
Page 278: H Making The Cable For Connection To A Printer
Making the Cable for Connection to a Printer The following product is recommended as the cable for connecting a printer. NT-CNT121 (made by OMRON, cable length 1.5 m, 20-pin – 36-pin) Refer to the following when making a cable for connection to a printer.
Page 279 Relationship between System Program and Here, relationship between system program and hardware is described. NT31/NT31C have following models. NT31-ST121j-E Conventional product NT31C-ST141j-E NT31-ST121j-EV1 Version upgrade model of the products above (12/98) (12/98) NT31C-ST141j-EV1 NT31-ST121j-EV2 Version upgrade model of the products above (12/99) (12/99) NT31C-ST141j-EV2...
Page 280: Relationship Between System Program And Hardware
Relationship between System Program and Hardware Combining a -V1 Version and -V2 Version System program Ver. 2.0j or Ver. 2.1j The following functions (new functions supported by the -V2) cannot be used: S Additional data areas accessible in CS1-series PCs S The CS1-series high-speed 1:N NT Link S Interlock function that controls touch switches, numeral inputs, and character string inputs S Mathematical function...
Page 281: Model List
Model NT31-ST121-EV2 STN monochrome display, ivory NT31-ST121B-EV2 STN monochrome display, black NT31C-ST141-EV2 STN color display, ivory NT31C-ST141B-EV2 STN color display, black Host Link Units Model 3G2A6-LK201-EV1 CPU-mounted type with RS-232C connector 3G2A6-LK202-EV1 CPU-mounted type with RS-422A connector C200H-LK201-V1 Rack-mounting unit with RS-232C connector for C200H C200H-LK202-V1 Rack-mounting unit with RS-422A connector for C200H 3G2A5-LK201-EV1...
Page 282 Model List Model CPM2C-10jjjjjj-j The PC’s communications connector can be split into CPM2C-20jjjjjj-j an RS-232C port and peripheral port with a CPM2C-CN111 Connecting Cable. (The CS1W-CN114/118 Connecting Cables convert the connector to a single RS-232C or peripheral port.) CQM1-CPU21-E Features a 9-pin connector for RS-232C connections CQM1-CPU41-EV1 CQM1-CPU42-EV1 CQM1-CPU43-EV1...
Page 283 Model List Model CPM2C-10jjjjjj-j Connect to the RS-232C port of a CPM2C-CN111 CPM2C-20jjjjjj-j Connecting Cable. CQM1-CPU41-EV1 Features a 9-pin connector for RS-232C connections CQM1-CPU42-EV1 CQM1-CPU43-EV1 CQM1-CPU44-EV1 CQM1-CPU45-EV1 CQM1H-CPU21 Features a 9-pin connector for RS-232C connections CQM1H-CPU51 CQM1H-CPU61 C200HS-CPU21-E Features a connector for RS-232C connections C200HS-CPU23-E (selectable/9-pin) C200HS-CPU31-E...
Page 284: Rs-232C/Rs-422A Convertor Unit
Model List Model CS1G-CPU42-E(V1) Features a connector for RS-232C connections (9-pin) CS1G-CPU43-E(V1) CS1G-CPU44-E(V1) CS1G-CPU45-E(V1) CS1H-CPU63-E(V1) Features a connector for RS-232C connections (9-pin) CS1H-CPU64-E(V1) CS1H-CPU65-E(V1) CS1H-CPU66-E(V1) CS1H-CPU67-E(V1) *1: A CQM1H-SCB41 Serial Communications Board is required. *2: Either of the communication boards C200HW-COM02/COM04/COM05/COM06-EV1 is required. CPU Units for Connection via a High-speed NT Link (1:N)) Model CS1G-CPU42-E(V1)
Page 285: Connection Cable
Cable Length 15 cm Specification 25-pin type (male), made by OMRON 25-pin type (female), made by OMRON (for personal computers) 9-pin type (male), made by OMRON 9-pin type (female), made by OMRON (for personal computers) 25-pin type (male), made by JAE...
Page 286: Printer Cable
Cable for Peripheral Port of CS1-series PC Model Made by OMRON (CS1-series peripheral port ↔ D-Sub, 9-pin, female) CS1W-CN118 Connecting Cable for the CPM2C Communications Connector Model Made by OMRON (CPM2C communications port ↔ D-Sub, 9-pin, female, C-series CPM2C-CN111 peripheral port) Appendix J Specification Specification...
Page 287: K Option List
Appendix K Option List Replaceable Backlight ... NT31C-CFL01 (Used for Both NT31/NT31C) This is a backlight (CFL unit) for replacement purposes. Protective Sheet ... NT30-KBA04 (Used for Both NT31/NT31C) Stuck to the display to prevent irregular reflection or contamination. The entire sheet is colorless and transparent. The five sheets make a set.
Page 288 Option List The sheet offers protection against the following chemical agents. Protects against Boric acid Sulfuric acid Nitrogen Ammonia gas Carbonic acid gas Phenol Glycerin Ammonia water Calcium chloride Developing fluid (hypo) Acetaldehyde Lard For information on chemical agents not listed in the table above, please inquire whether or not protection is offered (if the chemical agent is one against which silicone rubber is recognized as offering protection, please use this product even if the agent is not listed in the “Protects against”...
Page 289: Index
Numbers 1:N connection among RS-422A ports, 122 1:N connection among RS-485 ports, 125 1:N connection between RS-422A/485 at the NT31/NT31C and RS-232C at the host, 92 Allowable power supply voltage range, 247 Applicable connectors, 281 Automatic transmission (memory unit), 42, 49 Backlight, 241 Backlight brightness adjustment, 193 Backlight unit, 30...
Page 290 Disabling/enabling writing to the screen data memory, 153 Display, 29 Display color, 248 Display device, 248 Display specifications, 248 Displaying and printing the display history record, 198 Displaying/setting the calendar and clock, 195 Downloading the system program, 152 Effective display area, 248 Enclosure ratings, 247 Error messages, 235 Errors in the system installer mode and their remedies, 239...
Page 291 Peripheral devices that can be connected, 16 Power consumption, 247 Power input terminals, 30 POWER LED, 29 Power supply connection, 33 precautions, xi Precautions to be observed when transmitting screen data, 156 Principal functions of NT31/NT31C, 9 Printer cable, 282 Printer connector, 30 Programming console function, 221 Programming environment, 249...
Page 292 Vibration resistance (operating), 247 View angle, 248 Index Warning label, 30 Waterproofed, 4 Weight, 247...
Page 293: Revision History
A manual revision code appears as a suffix to the catalog number on the front cover of the manual. Cat. No. V062-E1-02 The following table outlines the changes made to the manual during each revision. Page numbers refer to the previous version.
Page 294 Wegalaan 67-69, NL-2132 JD Hoofddorp The Netherlands Tel: (31)2356-81-300/Fax: (31)2356-81-388 OMRON ELECTRONICS, INC. 1 East Commerce Drive, Schaumburg, IL 60173 U.S.A. Tel: (1)847-843-7900/Fax: (1)847-843-8568 OMRON ASIA PACIFIC PTE. LTD. 83 Clemenceau Avenue, #11-01, UE Square, Singapore 239920 Tel: (65)6835-3011/Fax: (65)6835-2711...
Page 295 Authorized Distributor: Cat. No. V062-E1-02 Note: Specifications subject to change without notice. Printed in Japan...

This manual is also suitable for:

Nt31 Nt31c

Omron Programmable Terminals NT31 NT31C Setup Manual

Table of Contents

Precautions

1 Intended Audience

2 General Precautions

3 Safety Precautions

Section 1 General

General

Preparing for Connection

Section 3 Hardware Settings and Connections

Hardware Settings and Connections

Section 4

Connecting to the Host from the RS-232C Port

Section 5

Section 6 System Menu Operation

Section 7 Troubleshooting and Maintenance

Index

Revision History

Quick Links

Chapters

Troubleshooting

Related Manuals for Omron Programmable Terminals NT31 NT31C

Summary of Contents for Omron Programmable Terminals NT31 NT31C
