Omron DEVICENET#05-2003 Operation Manual page 161

GT1-TS04T and GT1-TS04P Temperature Input Units
Terminal Arrangement
Wiring
GT1TS04P
Number
0 (factory-set) Pt100
1 JPt100
2 Pt100
3 JPt100
4 to 9 Cannot be set
GT1-TS04T
GT1-TS04P
IN 0
A
Internal Power Supply
Internal power supply
Input type
–200.0 to 650.0
–200.0 to 650.0
–200.0 to 200.0
–200.0 to 200.0
IN 0 IN 1 IN 2
+ + +
IN 0 IN 1 IN 2
-
IN 0 IN 1 IN 1 IN 2
B A B A
IN 0 IN 1 IN 2
B B B
GT1-TS04T
Thermocouple
input
Section 5-3
Range ( C) Range ( F)
–300.0 to 1200.0
–300.0 to 1200.0
–300.0 to 380.0
–300.0 to 380.0
IN 3
+
IN 3
IN 2 IN 3 IN 3
B A B
IN 3
B
GT1-TS04P
Platinum resistance
thermometer input
151
