Omron DEVICENET#05-2003 Operation Manual page 219

Slave Device Profiles
Item
Object instance 2 Attribute
Item
Object instance 2 Service
Note The values for produced connection size and consumed connection size will be the respective totals for
all the I/O Units connected to the Communications Unit. The following table lists the values for each I/O
Unit.
Model
DRT1-COM
GT1-ID16(-1)
GT1-ID16MX(-1)
GT1-ID16ML(-1)
GT1-ID16DS(-1)
GT1-ID32ML(-1)
GT1-OD16(-1)
GT1-OD16MX(-1)
GT1-OD16ML(-1)
GT1-OD16DS(-1)
GT1-OD32ML(-1)
GT1-ROS16
GT1-ROP08
GT1-AD04
GT1-AD08MX (set for 4 inputs)
GT1-AD08MX (set for 8 inputs)
GT1-DA04
GT1-DA04MX
GT1-TS04T/P (Normal Mode)
GT1-TS04T/P (2-decimal-place
Mode)
GT1-CT01
212
ID content
1 State
2 Instance type
3 Transport class trigger
4 Produced connection ID
5 Consumed connection ID
6 Initial comm. characteristics
7 Produced connection size
8 Consumed connection size
9 Expected packet rate
12 Watchdog time-out action
13 Produced connection path length
14 Produced connection path
15 Consumed connection path length
16 Consumed connection path
17 Production inhibit time
DeviceNet service
0E Get_Attribute_Single
10 Set_Attribute_Single
Produced connection size
0400 Hex
0200 Hex
0200 Hex
0200 Hex
0200 Hex
0400 Hex
0000 Hex
0000 Hex
0000 Hex
0000 Hex
0000 Hex
0000 Hex
0000 Hex
0800 Hex
0800 Hex
1000 Hex
0000 Hex
0000 Hex
0800 Hex
1000 Hex
0600 Hex
Get Set
(read) (write)
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes Yes
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Parameter option
No
No
Consumed connection size
0000 Hex
0000 Hex
0000 Hex
0000 Hex
0000 Hex
0000 Hex
0200 Hex
0200 Hex
0200 Hex
0200 Hex
0400 Hex
0200 Hex
0200 Hex
0000 Hex
0000 Hex
0000 Hex
0800 Hex
0800 Hex
0000 Hex
0000 Hex
0600 Hex
Appendix A
Value
---
0100 Hex
8200 Hex
---
---
0100 Hex
See note.
See note.
---
0000 Hex
0000 Hex
No
0000 Hex
No
0000 Hex
