Appendix
A.2 Data formats and data sets
Byte.Bit
4.0
4.1
4.2
4.3
4.4
4.5
4.6
4.7
5.0
5.1
5.2
5.3
5.4
5.5
5.6
5.7
6.0
6.1
6.2
6.3
6.4
6.5
6.6
6.7
7.0
7.1
7.2
7.3
7.4
7.5
7.6
7.7
174
Code Meaning
Bit (1 = active) Asymmetry detected
Asymmetry tripping
I limit value overshot
e
I limit value undershot
e
I limit value tripping
e
Residual current detected
Residual current tripping
Tripping due to motor blocking
Bit (1 = active) Input 1
Input 2
Input 3
Input 4
Input tripping
Input tripping limit position CW rotation
Input warning
Input tripping limit position CCW rotation
Bit (1 = active) Input controls
Output 1 active
Output 1 overloaded
Quick stop active
Sensor supply overload
Trip reset executed
Trip reset not possible
Electronics supply voltage too low
Communication
Bit (1 = active) Bus error
CPU/Master STOP
Automatic mode
Manual mode local (local control)
Manual local - HMI controls
Manual local - input controls
Connection abort in manual mode
Process image error
