Device parameter
Output 1 level
Output 1 signal
Output 1 action
Connector monitoring
Response when
connector removed
Response to circuit
breaker OFF
M200D AS-Interface Standard
Manual, 08/2014, A5E02548958A/RS-AA/004
Default setting
Non-inverted
Non-inverted
•
Inverted
•
Continuous signal
Continuous signal
•
Flashing
•
Control source Control by means of external control
PIO-DO-1.0 source
Control source PIO-DO-1.0
•
Control source PIO-DO-1.1
•
Control source PIO-DO-0.2
•
Control source input 1
•
Control source input 2
•
Control source input 3
•
Control source input 4
•
Control by means of external control
source
Run-up
•
Operation/shunting
•
Coasting down
•
On time motor (RUN)
•
Control command motor ON
•
Brake output
•
Device ON
•
Control by means of messages from the
motor starter
Group prewarning
•
Group warning
•
Group fault
•
Bus error
•
Device error
•
Maintenance required
•
Maintenance requested
•
Ready for motor ON
•
Line side
Deactivated
•
Line side
•
Group fault
Group fault
•
Group fault only after ON command
•
Group warning
•
Group fault
Group fault
•
Group fault only after ON command
•
Group warning
•
Setting range
Configuring/assigning parameters
5.4 Assigning parameters
Ext. PI DS 203
— ✓
— ✓
— ✓
✓ ✓
✓ ✓
✓ ✓
Motor
Starter
ES
✓
✓
✓
✓
✓
✓
