Sample Customer Configurations

3. Administer the CV/LAN as follows. On the Main Menu, select
4. Reboot the system as follows. On the Main Menu, select
5. After the reboot, from the Main Menu, choose TCP/IP
6. If the Network Routing Daemon is On, press
E-4 Issue 3 May 2002
c. Access the Add Host screen again and do the same for
clients 2 and 3 (C2 and C3).
d. You will be on the Local Host Table screen when done. Exit
the screen to return to the TCP/IP Administration Main Menu.
CV/LAN Administration.
a. Delete the default entry.
b. Press to access the Add Client Link screen. Add an
ADD
entry for client 1 on the appropriate port and client link.
c. Access the Add Client Link screen again and do the same for
clients 2 and 3 (C2 and C3).
d. You will be on the CV/LAN Administration screen when done.
Exit the screen to return to the Main Menu.
Maintenance. Then select Reset System. When the Reset System
screen appears, select Reboot System.
Administration. Next choose Network Routing Information, and then
choose Network Routing Daemon.
— Turn the routing daemon On if there is a router on the same
network as lgateserver, which is broadcasting routes to all
networks where clients reside.
— Turn the routing daemon Off if there is no router or if manual
routes are preferred.
screen. Exit twice more to return to the Main Menu.
If the Network Routing Daemon is Off, do the following:
a. Administer the default gateway. Press
Network Routing Daemon screen to access the Network
Routing Information Main Menu. Select Default Gateway. On
this screen, enter the IP address of the default gateway (for
this example, enter 135.20.1.100) and press
Network Routing Information Main Menu reappears.
b. Select Network Routing Table and then press
the Add Routes screen. Administer gateway 2 on this screen.
For this example, you would enter:
DESTINATION
135.20.3
When you press
reappears. Exit until you reach the Main Menu.
CANCEL
CANCEL
TYPE
NETWORK
, the Network Routing Table screen
ENTER
to exit from the
on the
. The
ENTER
to access
ADD
GATEWAY
135.20.1.200
