CVLAN and DLG System Administration
Field Name
The DEFINITY
system Port State
(continued)
Number of Client
Connections
CV/LAN Service
State
Messages to the
DEFINITY system
Messages from
the DEFINITY
system
Message Period
Use this screen as follows:
To change the port's CV/LAN service state:
1. Press
2. Press
3. The following prompt appears: Are you sure? (Y/N). Type Y
4-78 Issue 3 May 2002
Description
BUSIEDOUT — The BRI Port is administered on the
DEFINITY system but has been busied out in the BRI
driver on the MAPD.
SW INTF DN — The DEFINITY system interface
(angel) is down.
SW INTF DN BSY — The DEFINITY system
interface (angel) is down and the BRI Port has been
busied out in the BRI driver on the MAPD.
Read-only. Number of currently connected clients.
Either in service or out of service.
Read-only. The number of messages sent to the
DEFINITY system in the last message collection period.
Read-only. The number of messages sent by the
DEFINITY system in the last message collection period.
The time period (in minutes) during which messages are
sent and received. This is a per port number. Default =
30.
or use the arrow keys to move to the desired port.
TAB
to toggle the Service State.
STATE
NOTE:
Busying a port out causes that port's TCP connection (if one
exists) to be closed. No new connections are permitted on that
port until the port is placed back in service.
and press . The CV/LAN Port Status/Control screen
RETURN
reappears showing the changed state.
If you type N and press
screen immediately reappears.
, the CV/LAN Port Status/Control
RETURN
