Overview of the MAPD
TN801B
Board
Pentium
Processor
Card
(Pentium
Processor Card)
Reset Cable
2.5" Disk Drive
8 Character LCD
Boot/Shut Button
Board Status LED (red)
Slot for PCMCIA Disk
PCMCIA Disk
In Use LED (yellow)
Latch
Figure 1-1. MAPD System Assembly
1-4
Issue 3 May 2002
