Avaya DEFINITY Manual page 294

Sample Customer Configurations
Example 1. Secure LAN with Defaults
DEFINITY
Default host name =
ECS
M
A
P
D
(CV/LAN
Server)
Default IP address =
This sample configuration shows the CV/LAN application over MAPD shipped
from the factory with defaults already administered (default hostname = definity
and default IP address = 192.168.25.10) with the CV/LAN running on the MAPD
and four clients, C1, C2, C3, and C4 on the same subnet.
NOTE:
You should add the MAPD system assembly host name (definity) and IP
address (192.168.25.10) to the address resolution mechanism.
E-2 Issue 3 May 2002
CV/LAN
Windows NT
Client
C1
Ethernet
definity
C3
192.168.25.10
CV/LAN
SPARC
Client
C2
IP address =
192.168.25.100
IP address =
192.168.25.20
UnixWare
Client
CV/LAN
C4
IP address =
192.168.25.40
IP address =
192.168.25.30
Solaris x86
Client
CV/LAN
