Worksheet A-3: Port Slot Locations
for the MAPD System Assembly
Date
Prepared By
Contact Telephone Number
On the table below, specify the locations of the three contiguous slots into which
the MAPD system assembly is to be installed.
Slot occupied by MAPD
first
second
third
The three contiguous slots are administered with codes or left blank as shown
below.
Switch
R5 and higher
(provisioned with R6.3 or
later software in V5 or V6
mode)
A-4 Issue 3 May 2002
___________________________
___________________________
___________________________
Digital Port Equipment Location
Slot 1 Slot 2
Reserved Reserved
Slot 3
TN801B
