The System can be taken out of Valet mode by one of the following procedures:
1. No Remote: If there are no remotes or there are no remotes available you can exit Valet Mode by turning
the key to the ignition on or 'Run' position then press and release the foot brake pedal 10 times within 10
seconds. This procedure will only deactivate Valet Mode it will not activate Valet Mode. The vehicles
parking lights should flash 2 times to indicate the system has exited valet mode
2. With Remote: While within remote range of the vehicle, using a 4-button remote, press and release the lock
and trunk button together simultaneously for a half second. The vehicle's parking lights will flash 2 times to
indicate the system has exited Valet Mode.

Placement and Use of Components

IMPORTANT: The placement and use of components are critical to the performance of this system.
Antenna and Cable
Firstech antennas are calibrated for horizontal installation at the top of the windshield. The cable that connects
the antenna to the control module must be free from any pinches or kinks. Installing the antenna in areas other
than the windshield may adversely affect the effective transmitting distance of the remotes.
LED (external)
There will be an external mountable Blue LED for theft deterrent included. It is important to discuss mounting
locations with the end user, trying to make it visible and bright when recommending locations. The LED will
light up solid blue when armed for approx. 25 seconds allowing the impact sensor to set up. Once the LED is
flashing the sensors are ready. The LED will also provide security diagnostics:
RPS Touch and RPS (Remote Paging Sensor)
The RPS is an optional feature. The car call/RPS feature uses a small sensor that is mounted on the inside of
your windshield.
Copyright 2016 Fi rstech ,
LLC.
2 Flash Door Input
3 Flash Shock stage 1
4 Flash Shock stage 2
5 Flash Tilt
Ignition on
6 Flash
7 Flash Hood Input
8 Flash Trunk Input
9 Flash AUX sensor stage 1
10 Flash AUX sensor stage 2
