CM7 Master Guide
Introduction
Thank you!
For selecting a Firstech remote start security system as your product of choice. The following manual is a
complete Master guide to the CM7 universal Control Module and is intended for experienced and
authorized Firstech technicians only. If you need any further technical support, please call us at 888-820-
3690 ext. 203 or visit our website at
Caution: The Manufacturer's warranty will be void if this product is installed by anyone other
than an authorized Firstech dealer. Firstech provides installation support services to authorized
dealers only.
This manual may change frequently. Please check www.firstechdata.com for updates.
Kit Contents
All Firstech CM7 controller kits include the following:
• CM7000 or CM7200 main control module
• Wiring diagram sheet
• High Current ignition harness with one external relay
• Low current ignition harness
• Wiring harnesses
• Hood pin
• Mountable bright blue LED (CM7000 only)
• FT-DAS or FT-DAS II Firstech Digital Adjustable Sensor (Required for Manual Transmissions) (CM7000 only)
RF Kits with remote(s), Antenna, and Antenna Cable are not included with the CM7 controller kit.
The following sensors are available but
• Auto lock and unlock system (FT-EZGO)
• Remote pager sensor (FT-RPS TOUCH) or (FT-RPS-2)
• Temperature sensor (FT-TEMP SENSOR) (Drone and 2 Way remote LCD systems)
• Shock sensor (FT-SHOCK)
The remote(s) and antenna are modular and are not specific to the control modules. You can pair almost any
Firstech remote(s) and antenna receiver to the CM7 control module. This includes all 4 and 6 pin antennas.
Any questions on contents please contact your distributor or us directly at 1.888.820.3690, Monday
through Friday, 7AM to 5PM Pacific Time.
Copyright 2016 Fi rstech ,
LLC.
www.firstechdata.com
with every system:
not included
Alarm and Starter System
www.firstechdata.com
Page 4
