What do I do with the thick blue wire on Connector 1?
A: It is used to power a (+) 2nd Ignition. You can also change the output via jumper within the control module. It can be
changed to power a (+) 2nd Accessory or (+) Parking light wire.
I need a ground when armed wire, does the control module have one?
A: You can use pin 1-blue/white wire on the Grey Connector 5. You must cut this wire and place a diode in
line so that when the ignition on the other side of the relay goes to ground and it doesn't back feed to your
accessory. Install the stripe side of the diode facing the control module.
What do I do with the 6 Pin harness on Connector 3?
A: The 6 Pin harness on Connector 3 is used for low current ignition harnesses. DO NOT use this harness
with the Connector 1 Harness (the high current power harness) this is ONLY to be used in LOW current
applications where High current is not needed for any reason.
Does the CM7 series have tachless mode?
A: Yes. The CM7000 and CM7200 are tachless. For details, review the "Common Procedures" section of this
manual.
All my connections are made and remotes programmed, how do I program the tach?
A: Review the "Common Procedures" section of this manual. You must have your remotes programmed, start
your vehicle, then hold the remote start button. Vehicle should chirp and/or flash once if it programs, three
times if it does not like the tach source.
The vehicle will lock and unlock, but will not remote start or flash the parking lights.
A: The system is in Valet Mode. Tap the Lock and Trunk Buttons for a half second to exit Valet Mode. You
can also turn the ignition 'On 'and press the foot brake 10 times within 10 seconds.
Whenever I try to arm the vehicle, it chirps the siren 3 times and will not arm.
A: Check the hood and trunk trigger inputs.
Do the door locks flip flop in polarity?
A: No. You can use the FT-DM700 relay pack for high current positive (+) locks, or the FT-DM600 harness
used for low current 600mA positive (+) locks.
What are Firmware Version Diagnostics?
A: When you turn the Ignition on and hold buttons 1 and 4 or Lock and Start for 2.5 seconds then the
parking lights will flash 1 time on the CM7 series showing V.1.
What is this cartridge slot on the CM7000, CM7200, and CM6300?
A: This is the slot for the Blade cartridge system. This slot is for the Idatalink Blade remote start bypass
modules. For more information on the compatibility and install information please visit www.compustar.
idatalink.com. Using this system eliminates many connections between your standard control module and
bypass module. IMPORTANT: If you are not using the Blade then you will not have or use the black 20 pin
connector on the control module.
