Roland SoundCanvas SC-88 Pro Owner's Manual page 96

< Modifying values >
Since the Speed parameter has only two values, Slow
and Fast, the lower half of the range (00H -- 3FH) will
select Slow, and the upper half (40H--7FH) will select
Fast.
B0 10 00 Speed
: :
B0 10 3F Speed
B0 10 40 Speed
: :
B0 10 7F Speed
Using Control Change 16 to modify the
Wah Man value of 50:GTR Multi3
< Settings >
1. Turn EFX on for Part 1.
F0 41 10 42 12 40 41 22 01 5C F7
2. Set the effect type to 50: GTR Multi 3 (value: 04H
02H)
F0 41 10 42 12 40 03 00 04 02 37 F7
3. Set Wah Man (address: 40H 03H 04H) to 0.
F0 41 10 42 12 40 03 04 00 39 F7
4. Set Effect Control Source 1 (address: 40H 03H 1BH)
to CC16 (10H).
F0 41 10 42 12 40 03 1B 10 12 F7
5. Set Effect Control Depth 1 (address: 40H 03H 1CH)
to +100% (7FH).
F0 41 10 42 12 40 03 1C 7F 22 F7
< Modifying the value >
B0 10 00 Wah Man
B0 10 01 Wah Man
: :
B0 10 7E Wah Man
B0 10 7F Wah Man
* For the correspondence between the hexadecimal val-
ues and the parameter values, refer to p.183.
Using Control Change 17 to modify the
Feedback value of 10: Stereo Flanger
Example 1: When Effect Control Depth is set to
+100
< Settings >
1. Turn EFX on for Part 1.
F0 41 10 42 12 40 41 22 01 5C F7
2. Set the effect type to 10: Stereo Flanger (value: 01H
23H)
F0 41 10 42 12 40 03 00 01 23 19 F7
3. Set Feedback (address: 40H 03H 08H) to -98%.
F0 41 10 42 12 40 03 08 00 35 F7
4. Set Effect Control Source 2 (address: 40H 03H 1DH)
to CC17 (11H).
F0 41 10 42 12 40 03 1D 11 0F F7
5. Set Effect Control Depth 2 (address: 40H 03H 1EH)
to +100% (7FH).
F0 41 10 42 12 40 03 1E 7F 20 F7
94
Slow
Slow
Fast
Fast
0
1
126
127
Chapter 4. Insertion Effects
< Modifying the value >
The Feedback parameter changes in 2% steps, with 40H
as the center. (For the correspondence between hexa-
decimal values and parameter values, refer to the table
on p.183.)
B0 11 00 Feedback
: :
B0 11 0F Feedback
B0 11 10 Feedback
: :
B0 11 3E Feedback
B0 11 3F Feedback
B0 11 40 Feedback
B0 11 41 Feedback
B0 11 42 Feedback
: :
B0 11 70 Feedback
B0 11 71 Feedback
: :
B0 11 7F Feedback
Using Control Change 17 to modify the
Feedback value of 10: Stereo Flanger
Example 2: When Effect Control Depth is set to -
100
< Settings >
1. Turn EFX on for Part 1.
F0 41 10 42 12 40 41 22 01 5C F7
2. Set the effect type to 10: Stereo Flanger (value: 01H
23H)
F0 41 10 42 12 40 03 00 01 23 19 F7
3. Set Feedback (address: 40H 03H 08H) to +98% (7FH).
F0 41 10 42 12 40 03 08 7F 36 F7
4. Set Effect Control Source 2 (address: 40H 03H 1DH)
to CC17 (11H).
F0 41 10 42 12 40 03 1D 11 0F F7
5. Set Effect Control Depth 2 (address: 40H 03H 1EH)
to -100% (00H).
F0 41 10 42 12 40 03 1E 00 1F F7
< Modifying the value >
The Feedback parameter changes in 2% steps, with 40H
as the center. (For the correspondence between hexa-
decimal values and parameter values, refer to the table
on p.183.) Since Effect Control Depth is set to -100%,
increasing control change values will cause the value of
the Feedback parameter to decrease.
B0 11 00 Feedback
: :
B0 11 0F Feedback
B0 11 10 Feedback
: :
B0 11 3E Feedback
B0 11 3F Feedback
B0 11 40 Feedback
B0 11 41 Feedback
B0 11 42 Feedback
: :
B0 11 70 Feedback
B0 11 71 Feedback
: :
B0 11 7F Feedback
-98%
-98%
-96%
-4%
-2%
+/-0%
+2%
+4%
+96%
+98%
+98%
+98%
+98%
+96%
+4%
+2%
+/-0%
-2%
-4%
-96%
-98%
-98%
