<OD (Overdrive/Distortion)>
OD Sel (OD Select)
Select either Overdrive or Distortion.
+OD Drive (OD Drive)
Adjust the depth of overdrive or distortion. The vol-
ume will change together with the depth of distor-
tion.
OD Amp (OD Amp Simulator Type)
Select the type of guitar amp for overdrive or distor-
tion.
Small : small amp
BltIn : single-unit type amp
2-Stk : large double stack amp
3-Stk : large triple stack amp
OD Amp Sw (OD Amp Switch)
Turn the OD Amp parameter on/off.
OD Pan (OD Output Pan)
Set the stereo location of the overdrive or distortion
sound. L63 is far left, 0 is center, and R63 is far
right.
OD Level (OD Level)
Adjust the volume of the overdrive or distortion
sound.
<AW (Auto-wah)>
AW Filter (Auto-wah Filter Type)
Select the type of filter for the auto-wah.
LPF : The wah effect will be produced over
a broad frequency range.
BPF : The wah effect will be produced over
a narrow frequency range.
AW Sens (Auto-wah Sensitivity)
Adjust the sensitivity with which the auto-wah filter
will be controlled.
#AW Man (Auto-wah Manual)
Set the center frequency at which the auto-wah
effect will be produced.
AW Peak (Auto-wah Peak)
Adjust the way in which the wah effect will be
applied to the region of the center frequency. Lower
settings will produce a wah effect in a broad area
around the center frequency, and higher settings
will produce a wah effect in a narrower area around
the center frequency.
AW Rate (Auto-wah Rate)
Adjust the modulation speed of the auto-wah.
Odrv/Dist [1]
0 - 127 [2]
Small/BltIn/2-Stk/3-Stk [3]
Off/On [4]
L63 - 0 - R63 [16]
0 - 127 [17]
LPF/BPF [6]
0 - 127 [7]
0 - 127 [8]
0 - 127 [9]
0.05 - 10.0 [10]
Chapter 4. Insertion Effects
AW Depth (Auto-wah Depth)
Adjust the modulation depth of the auto-wah.
AW Pol (Auto-wah Polarity)
Set the direction in which the frequency will change
when the auto-wah filter is modulated. With a set-
ting of Up, the filter will change toward a higher fre-
quency. With a setting of Down, it will change
toward a lower frequency.
AW Pan (Auto-wah Output Pan)
Adjust the stereo position of the auto-wah sound.
L63 is far left, 0 is center, and R63 is far right.
AW Level (Auto-wah Level)
Adjust the volume of the auto-wah sound.
Level (Output level )
Adjust the output level.
63: PH / Rotary (Phaser, Rotary)
This connects a Phaser effect in parallel with a Rotary
effect.
L Phaser
R
Rotary
<PH (Phaser)>
PH Man (Phaser Manual)
Adjust the center frequency at which the sound will
be modulated.
+PH Rate (Phaser Rate)
Adjust the modulation speed of the phaser.
PH Depth (Phaser Depth)
Adjust the modulation depth of the phaser.
PH Reso (Phaser Resonance)
Adjust the emphasis for the region around the cen-
ter frequency specified by the PH Man parameter.
PH Mix (Phaser Mix Level)
Adjust the proportion of the phase-shifted sound
that will be mixed with the direct sound.
PH Pan (Phaser Output Pan)
Set the stereo location of the phaser sound. L63 is
far left, 0 is center, and R63 is far right.
PH Level (Phaser Level)
Adjust the volume of the phaser sound.
0 - 127 [11]
Down/Up [12]
L63 - 0 - R63 [18]
0 - 127 [19]
0 - 127 [20]
[11H, 07H]
Pan
Pan
100 - 8.0k [1]
0.05 - 10.0 [2]
0 - 127 [3]
0 - 127 [4]
0 - 127 [5]
L63 - 0 - R63 [16]
0 - 127 [17]
89
