Others
31: 3D Auto
The 3D Auto effect rotates the location of the sound.
L
3D Auto
R
Azimuth
Set the location at which the sound will stop when
rotation is stopped.
A setting of 0 positions the sound in the center.
+Speed
Set the speed of rotation.
Clockwise
Set the direction of rotation. A setting of "-" is
counter-clockwise, and "+" is clockwise.
#Turn
This stops or starts the rotation. When this is turned
On, the sound will rotate. When turned Off, rotation
will stop at the location specified by Azimuth.
Out (Output mode)
Specify the method that will be used to hear the
sound which is output to the OUTPUT jacks. The
optimal 3D effect will be achieved if you select
Speaker when using speakers, or Phones when
using headphones (p.91).
Level (Output level )
Adjust the output level.
32: 3D Manual
This places the 3D effect at a desired location.
L
3D Locate
R
+Azimuth
Specify the location.
A setting of 0 positions the sound in the center.
Out (Output mode)
Specify the method that will be used to hear the
sound which is output to the OUTPUT jacks. The
optimal 3D effect will be achieved if you select
Speaker when using speakers, or Phones when
using headphones (p.91).
#Level (Output level )
Adjust the output level.
70
[01H, 70H]
180/L168 - 0 - R168 [1]
0.05 - 10.0 [2]
-/+ [3]
Off/On [4]
Speaker/Phones [15]
0 - 127 [20]
[01H, 71H]
180/L168 - 0 - R168 [1]
Speaker/Phones [15]
0 - 127 [20]
Chapter 4. Insertion Effects
33: Lo-Fi 1
Lo-Fi 1 is an effect that intentionally degrades the
sound quality.
L
Lo-Fi
R
Pre Filter (Pre Filter Type)
Specify the type of filter that will be applied before
the sound passes through the Lo-Fi effect.
Lo-Fi Type
Degrade the sound quality. The sound quality will
become poorer as this value is increased.
Post Filter (Post Filter Type)
Specify the type of filter that will be applied after the
sound passes through the Lo-Fi effect.
+Balance (Effect Balance)
Adjust the volume balance between the direct and
the processed sound.
"D" or "E" on the display respectively means
D(direct sound) or E(effect sound) values of 100.
Low Gain
Adjust the gain of the low frequency range.
Hi Gain (High gain)
Adjust the gain of the high frequency range.
#Pan (Output pan)
Adjust the stereo location of the output sound. L63
is far left, 0 is center, and R63 is far right.
Level (Output level)
Adjust the output level.
34: Lo-Fi 2
Lo-Fi 2 is an effect that intentionally degrades the
sound quality and allows a variety of noise to be
added
* If the R.Detune (Radio Detune), W/P Level (White/Pink
Noise Level), Disc Nz Lev (Disc Noise Level), or Hum
Level settings are raised, there will be noise even when
the input sound is silent.
Radio
L
Lo-Fi
Lo-Fi
R
Noise
Generator
Lo-Fi Type
Degrade the sound quality. The sound quality will
become poorer as this value is increased.
Fil Type (Filter Type)
Specify the type of filter that is applied after the
sound passes through the Lo-Fi effect.
[01H, 72H]
EQ
Pan
1 - 6 [1]
1 - 9 [2]
1 - 6 [3]
D > 0E - D 0<E [16]
-12 - +12 [17]
-12 - +12 [18]
L63 - 0 - R63 [19]
0 - 127 [20]
[01H, 73H]
EQ
Balance
EQ
1 - 6 [1]
Off/LPF/HPF [2]
