Wah Peak
Adjust the way in which the wah effect will be
applied to the region of the center frequency. Lower
settings will produce a wah effect in a broad area
around the center frequency, and higher settings
will produce a wah effect in a narrower area around
the center frequency.
Wah Sw (Wah Switch)
Turn Wah on/off.
<OD (Overdrive/Distortion)>
OD Sel (OD Select)
Select either Overdrive or Distortion.
#OD Drive
Adjust the depth of distortion. The volume will
change together with the depth of distortion.
OD Amp (OD Amp Simulator Type)
Select the type of guitar amp
Small : small amp
BltIn : single-unit type amp
2-Stk : large double stack amp
3-Stk : large triple stack amp
OD Amp Sw (OD Amp Switch)
Turn OD Amp on/off.
OD L Gain (OD Low Gain)
Adjust the low-range gain for the overdrive (or dis-
tortion) sound.
OD H Gain (OD High Gain)
Adjust the high-range gain for the overdrive (or dis-
tortion) sound.
OD Sw (OD Switch)
Turn overdrive or distortion on/off.
<CF (Chorus/Flanger)>
CF Sel (CF Select)
Select either Chorus or Flanger.
CF Rate
Adjust the modulation speed for the chorus or
flanger.
CF Depth
Adjust the modulation depth for the chorus or
flanger.
CF Fb (CF Feedback)
Adjust the amount (%) of the flanger sound that is
returned to the input. Negative (-) values will invert
the phase.
In the case of Chorus, this will have no effect.
CF Mix
Adjust the volume of the chorus or flanger sound.
80
0 - 127 [3]
Off/On [4]
Odrv/Dist [5]
0 - 127 [6]
Small/BltIn/2-Stk/3-Stk [7]
Off/On [8]
-12 - +12 [9]
-12 - +12 [10]
Off/On [11]
Chorus/Flangr [12]
0.05 - 6.40 [13]
0 - 127 [14]
-98% - +98% [15]
0 - 127 [16]
Chapter 4. Insertion Effects
<Dly (Delay)>
Dly Time (Delay Time)
Adjust the time from the original sound until when
the delay sound is heard.
Dly Fb (Delay Feedback Level)
Adjust the amount of the delay sound that is
returned to the input.
Dly Mix (Delay Mix)
Adjust the volume of the delay sound.
Level (Output level )
Adjust the output level.
51: Clean Gt Multi1 (Clean Guitar Multi1)
Clean Guitar Multi 1 connects Compressor (Cmp),
Equalizer (EQ), Chorus or Flanger (CF), and Delay
(Dly) effects in series.
L
Cmp
EQ
R
<Cmp (Compressor)>
Cmp Atck (Compressor Attack)
Adjust the time over which the sound will rise after it
is input.
Cmp Sus (Compressor Sustain)
Adjust the time over which low-level sounds are
boosted until they reach a specified volume.
Increasing the value will shorten the time. When the
value is modified, the level will also change.
Cmp Level (Compressor Level)
Adjust the volume of the compressor sound.
Cmp Sw (Compressor Switch)
Turn the compressor on/off.
<EQ (Equalizer)>
EQ L Gain (EQ Low Gain)
Adjust the low-range gain of the equalizer.
EQ M Fq (EQ Mid Frequency)
Set the center frequency for the equalizer mid-
range.
EQ M Q (EQ Mid Q)
Adjust the width of the area centered at the EQ M
Fq setting in which the gain will be affected. The
area affected will become narrower as this value is
increased.
0m - 635m [17]
0 - 127 [18]
0 - 127 [19]
0 - 127 [20]
[04H, 03H]
CF Delay
0 - 127 [1]
0 - 127 [2]
0 - 127 [3]
Off/On [4]
-12 - +12 [5]
200 - 6.3k [6]
0.5/1.0/2.0/4.0/9.0 [7]
