Roland SoundCanvas SC-88 Pro Owner's Manual page 105

Storing a Drum instrument
1.
2.
3.
Select a Drum Part and Drum Set, and create a drum instrument ("Drum edit-
ing procedure" p.42).
PART INSTRUMENT
LEVEL PAN
If the above screen is displayed after you create a drum instrument, you can use the follow-
ing procedure to save your data as a User Drum Set. If the screen display is different than
the one shown above, use following procedure
Make sure that the [ALL] indicator is dark.
If it is lit, press [ALL] to turn it off.
Simultaneously press [SELECT] and EFX TYPE [l l l l ].
The display will show the Part Group (p.23), Part Mode (p.27), Drum Set number, Note
name, and Drum Instrument name (p.43).
Part Group
Part Mode
Drum set number
INSTRUMENT
PART
LEVEL
PAN
Note Name
USER
INST SELECT
EFX ON/OFF
3
Chapter 5. Convenient functions
2 3
, .
Drum Instrument name
VIB RATE VIB DEPTH
CUTOFF
ATTACK DECAY
EFX TYPE EFX PARAM
VIB DELAY
RESONANCE
RELEASE
EFX VALUE
103
