Manually Configuring
the 3105B Attendant
Console
This command disables VLAN operation.
To verify the current settings use the nbxShowConfig and vcxShowConfig
command.
15 Enter this command to restart the Attendant Console and activate the
configuration changes:
nbxReset
This command copies the contents of the non-volatile memory to the
active network settings for the Attendant Console.
The Attendant Console communicates with the Primary VCX Server. Use
the Administrator Interface to:
Associate the Attendant Console with a particular phone
■
Perform the remaining configuration of the Attendant Console (for
■
example, mapping extensions to Attendant Console buttons)
For instructions on how to perform these tasks, see the VCX
Administration Guide.
To manually configure your 3Com 3105B Attendant Console:
1 Plug a standard Ethernet cable into the data port, located on the
underside of the console.
2 Plug the other end of the Ethernet cable into an active network jack.
3 Using an RJ45 to DB9 adapter cable (see
for the pin assignments) and a standard Ethernet cable, connect a serial
port on your PC to the serial port on the underside of the 3105 Attendant
Console.
4 Connect a 3Com power adapter to an AC power outlet.
5 Connect the other end of the power adapter cable to the power
connector on the underside of the 3105 Attendant Console.
6 Use a terminal emulation program such as Hyperterminal to connect to
the serial port on your PC. The configuration is:
9600 baud
■
8 data bits
■
1 stop bit
■
No parity
■
Attendant Console Installation
Table 13, earlier in this chapter
