Step
7. Configure the fax negotiation
faculty globally.
8. Configure the fax training
mode globally.
9. Configure the threshold
percentage of local training
globally.
10. Configure the ECM mode
globally.
11. Enable CNG fax switchover
globally.
12. Configure the codec type
and switching mode for SIP
Modem pass-through
function globally.
For information about how to use the global default parameters for fax, see "Configuring voice
entities."

Displaying and maintaining FoIP configuration

Task
Display the statistics of the FoIP
module.
Clear the statistics of the FoIP
module.
FoIP configuration examples
This section provides FoIP configuration examples.
Configuring FoIP
Network requirements
As shown in
transmit and receive faxes over an IP network.
Command
default entity fax nsf-on
default entity fax train-mode
{ local | ppp }
default entity fax local-train
threshold threshold
default entity fax ecm
default entity fax cng-switch
enable
default entity modem protocol
pcm { standard |
nte-compatible } { g711alaw |
g711ulaw }
Command
display voice fax statistics [ |
{ begin | exclude | include }
regular-expression ]
reset voice fax statistics
Figure 89, the headquarters of a company in City B and its branch in City A need to
280
Remarks
Optional.
By default, the fax negotiation is
based on the standard faculty.
Optional.
By default, the ppp training is
adopted.
Optional.
By default, the threshold is 10.
You must carry out the default
entity fax train-mode local
command before the
configuration made by the default
entity fax local-train threshold
threshold command takes effect.
Optional.
By default, the fax does not use
ECM.
Optional.
Disabled by default.
Optional.
By default, the SIP Modem
pass-through function is not
configured.
Remarks
Available in any view.
Available in user view.
