Configuration procedure
To specify the global URL scheme for outgoing SIP calls:
Step
1. Enter system view.
2. Enter voice view.
3. Enter SIP client view.
4. Specify the global URL
scheme for outgoing SIP
calls.
To specify the URL scheme for outgoing SIP calls on a VoIP voice entity:
Step
1. Enter system view.
2. Enter voice view.
3. Enter voice dial program
view.
4. Enter VoIP voice entity view.
5. Specify the URL scheme for
outgoing SIP calls.

Configuring SIP extensions

Strict SIP routing
Strict SIP routing is supported. In a complicated network environment where a request from SIP UAC
to SIP UAS needs to pass through multiple proxy servers, SIP uses the Route header field and the
Record-Route header field to make sure that requests in the dialog can be routed through these
proxy servers. The strict SIP routing is enabled by default, and you do not need to configure it.
Configuring out-of-band SIP DTMF transmission mode
During the communication between caller and callee, the DTMF digits can be transmitted
transparently between them in two ways: in-band and out-of-band. In the in-band approach, the
DTMF digits are encoded in RTP voice packets, and in the out-of-band approach, in SIP messages.
Command
system-view
voice-setup
Sip
url { sip | sips }
Command
system-view
voice-setup
dial-program
entity entity-number voip
url { sip | sips }
152
Remarks
N/A
N/A
N/A
Optional.
By default, the SIP scheme is
adopted.
You can specify the SIPS scheme
only when the transport layer
protocol is TLS.
Remarks
N/A
N/A
N/A
N/A
Optional.
By default, no URL scheme is
configured.
This command is effective only
when the type of the VoIP voice
entity is SIP.
You can specify the SIPS scheme
only when the transport layer
protocol is TLS.
