Demonstration Printing Function

If FEED switch is held down while the printer is turned on with the front and rear covers closed, the
demonstration printing mode is started. Then "demonstration patterns and the setting of the software
switch" are printed. After completing the printing, the printer shifts to normal power-on status
through POWER ON RESET operation.
FROM VER. CQ01-XXXX
FROM DATE -MM/DD YY
Impact Dot Printer
CD-S500
Feature:
Print Speed: Approx. 5.0 lps
Paper-drop-in style (40 col.)
Logic Seeking Control
Selectable Paper Width
(76.2/69.5/57.5 mm)
Two Color Printing (Red/Black)
ESC/POS Compatibility
Vertical Solution
Wall Mount Kit
FONT A(9x9 dots)
<21h-FFh codes printed by BLACK>
<21h-FFh codes printed by RED>
FONT B(7x9 dots)
<21h-FFh codes printed by BLACK>
<21h-FFh codes printed by RED>
Printed by CD-S500
<Soft Control-SW> - - - - - - - - - - - - - -
Command Type
Number of Col.
Font Select
Paper Plies
Paper End
Paper Near-End
Slashed Zero
Print Direct.
Auto LF
Code Page
Buffer Size
Init Signal
Buzzer
<Interface-SW> - - - - - - - - - - - - -
Baud Rate
Data Length
Parity Bit
Stop Bit
Protocol
<Mechanical-SW> - - - - - - - - - - - - - -
Paper Width
Auto-Cutter
Color Ribbon
Take-Up Device
6-8
CD-S500 Series
-EPSON
-40/33
-7 × 9
-OFF
-ENB
-ENB
-OFF
-BI-DIR
-OFF
-437
-4K
-ENB
-ON
-19200
-8bit
-NONE
-1bit
-DTR
-76.2
-FREE
-ON
-ON
