Main Sub
code code
26 42

Transfer ON/OFF timing control setting

Used to set the ON/OF timing of the transfer charger (TC) individually. Select an item to be changed with the
cross key, and change the set value to a desired value, and press [OK] key or [START] key. The entered
value is saved to the EEPROM and the machine shifts to the sub code input window.
(Item selection)
Sim26-42 TC TIMING
1:TC(ON)
2:TC(OFF)
[ 1- 99]
Key

Variation in the adjustment value

Set value
99
• • •
50
• • •
38
• • •
1
* Setting range is 1 - 99.
When the set value is increased by 1, the timing is increased by 2ms.
* The default (38) of transfer ON timing means 320ms from PS release.
The default (50) of the transfer OFF timing means304ms from P-IN OFF.
[CA] key: Exits the simulation mode.
[Interruption] key: Shifts to the sub code input window.
43

Side void amount setting

Used to set the left and right side void amounts. The left side void amount and the right side void amount
can be set individually. Select an item to be changed with the cross key and change the set value to a
desired value. The setting range is 0-10. When the value is increased by 1, the void amount is increased by
0.5mm. The default is 5 (= 2.5mm).
(Item selection)
Sim26-43 SIDE VOID
1:SIDE VOID(L)
2:SIDE VOID(R)
[ 0- 10]
Key
Display: Set item
1:SIDE BOID(L) : Left side void amount setting
2:SIDE VOID(R) : Right side void amount setting
[CA] key: Exits the simulation mode.
[Interruption] key: Shifts to the sub code input window.
(Value input)
Sim26-42 TC TIMING
1:TC(ON)
38
50 2:TC(OFF)
50
1:TC(ON)
PS release TC ON
Time (ms) Difference (ms)
442 +122
• • • • • •
344 +24
• • • • • •
320 Default
• • • • • •
246 -74
(Value input)
Sim26-43 SIDE VOID
1:SIDE VOID(L)
3
2:SIDE VOID(R)
3
3
AR-M207 M165 M162 SIMULATIONS 7-23
Contents
(Settlement)
Sim26-42 TC TIMING
38
50
[ 1- 99]
60
2
10 Key
2:TC(OFF)
PIN OFF
Set value Time (ms)
99 402
• • • • • •
51 306
• • • • • •
49 302
• • • • • •
1 206
(Settlement)
3
3
[ 0- 10]
4
2
10 Key
Default:
38 (TC ON)
50 (TC OFF)
1:TC(ON)
60
2:TC(OFF)
50
[ 1- 99]
60
OK/START Key
TC OFF
Difference (ms)
+98
• • •
+2
• • •
-2
• • •
-98
Default:
5 (Voide amount:
2.5mm)
Sim26-43 SIDE VOID
1:SIDE VOID(L)
4
2:SIDE VOID(R)
3
[ 0- 10]
4
OK/START Key
Remark
