10.3 Controlling NetAudio Server Parameters
AES/EBU:
This is the normal mode for the
the DSP32C's serial port is connected to the digital audio inputs and
outputs.
AES/EBU-Override:
DAT-Link
the
nected via the external Sync connector before beginning. This is useful
for playback and recording from a single unit when multiple units are
connected together.
GP-Int:
The DSP32C's serial port is connected to the DSP-Port . The clock
and load lines should be generated by the DSP32C and are output on
the appropriate pins of the DSP-Port .
GP-Ext:
The DSP32C's serial port is connected to the DSP-Port . The clock
and load lines should be generated externally and are inputs to the
Link
's DSP32C processor.
GPDelay-Int:
Similar to GP-Int except the incoming data is delayed by one
bit-time.
GPDelay-Ext:
Similar to GP-Ext except the incoming data is delayed by
one bit-time.
AES-Rx:
The digital audio input is used as the source of input data to the
DSP32C, but the DSP-Port is used for output. Clocking for both the
input and output is locked to the digital audio input.
AES-Tx:
Input is taken from the DSP-Port and output is sent to the digital
audio output. Clocking for both input and output is locked to the digital
audio output.
Pro8:
This mode permits both input and output to be routed via an Ariel
ProPort connected to the
for details on using the ProPort. In this particular mode the ProPort
will be set for input and output at 8,000 samples per second.
Pro11:
ProPort at 11,000 samples per second.
Pro16:
ProPort at 16,000 samples per second.
Pro32:
ProPort at 32,000 samples per second.
Pro44:
ProPort at 44,100 samples per second.
Pro48:
ProPort at 48,000 samples per second.
Pro96:
ProPort at 96,000 samples per second.
Pro-Int:
This ProPort mode uses the
clock (set by the
IR:
DAT-Link
The
input with clocks generated by the DSP32C. The DSP32C's serial output
is unused.
This is the same as the previous mode except that
+, version 1.6 or later will not wait for other devices con-
DAT-Link
+'s DSP-Port . See Section 11.3.1
DAT-Link
option above) as the ProPort's sample-rate clock.
-S
's infrared receiver is connected to the DSP32C's serial
DAT-Link
. With this setting,
DAT-
+'s digital audio output
