11.3 Hardware
time code. The current sample number is shown with each line. At line 13 the tape
was stopped and recording was begun. Line 13 shows the sample number at which
a new signal was acquired and the real time re ects the current time of day. Note
that the new passage was stored in
being done using 8 channels and that channel 2's input level was changed to 20V
maximum.
Between lines 13 and 14 the unit was stopped and sat idle for 16 minutes. At line
14 recording was resumed and the new data was stored in
seconds of recording the RD1x5T was switched to 2 channel recording and then 4
channels at double speed (2x).
Note that the 1x or 2x speed indicated in the control le or while
indicates the information stored when the tape was recorded. Since the TEAC decks
do not enforce the playback speed to agree with the recorded speed, this may not
re ect the actual playback speed. It is recommended that the TEAC's speed select
switch be set to the same value as that at which the data was originally recorded.
Transferring Data to the RD1x5T
Data can also be transferred from a host computer to the RD1x5T for recording
onto tape . To set the RD1x5T to accept 16-bit input from the
4
the following steps:
1. Power on the RD1x5T.
2. Press and hold the small reset button on the rear of the unit just below the
D In/Out connector.
3. Press and hold \
/CH
panel.
4. Release the reset button.
5. Release the \ " button.
/CH
6. The VU display should now illuminate a pattern of LED's to form the number
\16". If this does not appear, you may need to have an internal switch set in
the unit; see Section 11.3.2 below.
To return the unit to normal analog mode, repeat the above steps pressing the
\ " button instead of the \
B=R
In the 16-bit mode, data transferred from the host computer via the
be stored onto tape with the
music
, to the RD1x5T, do the following:
Note that the TEAC does NOT provide the capability to listen to the audio channels while
4
recording onto tape. i.e. record-pause mode is not functional.
test.d02
. We can also see that recording is
" button just below the unit's VU display on the front
" button.
/CH
command. For example, to transfer the le
naplay
111
test.d03
. After a few
is running
teacin
DAT-Link
+ perform
DAT-Link
can
