Townshend Computer Tools DAT-Link User Manual page 92

88
DAT-Link: Version 1.6/38
DSP Program: TS15 SIOMode: AES/EBU (0xa)
Playback
Time = 0:53
Left VU |***********
Right VU |***********
Buffering |********************|
Sampling rate = 8000->48000
Precision = 16
Encoding = Linear
Gain = 1.00
Channels = Stereo
State = Active
Error = No Error
Waiting = 0
Left CS = 040000020000000000000000 Left CS =040000020000000000000000
000000000000000000000000
Right CS= 040000020000000000000000 Right CS=040000020000000000000000
000000000000000000000000
User Bits = 00000000
clock = Internal
master = 0
Figure 10.1: Screen dump while
which change rapidly, such as sample count, playback/record time, and VU levels
are updated at regular intervals as given by the
nastatus -t 0.2
will update the display every 200 milliseconds. An example display is shown in
Figure 10.1. The following elds are displayed:
Versions
The banner line indicates the
numbers.
DSP Program
This is the name of the currently running DSP program. This is
normally of use only if you are loading your own DSP programs. See Section
10.4 for details.
SIOMode
This is the con guration of the
the command's
naset
Time = 0:00
Left VU
Right VU
Buffering |********************|
Sampling rate = 48000
Precision = 16
Encoding
Gain
Channels
State
Error
Waiting
User Bits = 00000000
locked = 1
source = RCA
skipSilence= 0 loopback = 0
nastatus
option. For example,
-t
DAT-Link
hardware and rmware revision
DAT-Link
option. See Section 10.3 for details.
-s
Utilities
Record
|
|
= Linear
= 1.00
= Mono
= Inactive
= No Error
= 0
000000000000000000000000
000000000000000000000000
AES status= 0x0000
is running.
's DSP-Port . It is set using
