C.2
Sync
Pin Number Connection(s)
1
2
3
4
5
6
7
8
in Section 10.3. is a word clock with a high level during the left sample and a
FSYNC
low level during the right sample.
rate and is a master clock with a frequency of 256 or 384 times the sampling
MCK
rate. For sampling rates of 48,000 or 44,100 samples/second, the 256 divider is
used while the 384 divider is used for 32,000 samples/second.
clocks must be provided for the
playback.
Table C.2: Sync Pinout
Direction
+5V From
DAT-Link
DSPIN To
DSPOUT From
READY Bidirectional
MCK Bidirectional
SCK Bidirectional
FSYNC Bidirectional
Ground
is a serial bit clock at 64 times the sampling
SCK
+ to use an external clock for
DAT-Link
DAT-Link
+
+
DAT-Link
+
All three of these
133
