2.4 Machine Speci c Instructions
Cables Required
To connect the HP computer with the
high-density 50 pin D connector on one end and a 50 pin Centronics type connector
on the other end. This may also be called a SCSI-1 to SCSI-2 cable. It should be
available from your HP hardware supplier or can be ordered from your
supplier. Make sure to connect to the HP's external, single-ended SCSI bus. The
DAT-Link
will not work with a di erential or fast/wide SCSI bus.
Choosing a SCSI ID
DAT-Link
Before connecting the
in use on your system. SCSI ID's range from 0 to 7. The HP computer uses ID
7. Disk drives, tape drives and other peripherals connected to your computer will
use additional SCSI ID's. You will need to check which ID's are in use, and nd an
unused one to assign to the
ID switch on the rear of the
9, settings 8 and 9 should not be used as these do not correspond to a valid SCSI
ID.
Connecting the
DAT-Link
The next step is to connect the
unterminate the SCSI bus temporarily, it is recommended that you shut-down and
turn o the computer before making the connection.
The Options switches on the rear of the
and 4 down and switch 2 up. Next, follow the instructions in Section 2.3 to connect
DAT-Link
the . Once it is hooked up you can reboot the computer. If you have
trouble rebooting, verify that the SCSI ID selected on the
that was in use.
Con guring the Device Drivers
First, you should verify that system can properly see the DAT-Link. The
can be used for this and should contain some output similar to:
10/16 bc
10/16/16 ext_bus
10/16/16.5 target
10/16/16.5.0 tape
Note that above is the output for a
ended SCSI adapter card at slot 10/16/16 in a K400 machine. Di erent machine
DAT-Link
you will require a cable with a
, you need to check which SCSI ID's are already
DAT-Link
. Once an ID has been chosen, set the SCSI
DAT-Link
. Note that although the switch goes up to
DAT-Link
to the computer. Since it is necessary to
DAT-Link
should be set with switches 1, 3,
Bus Converter
HP 28655A - SCSI Interface
HP HP35450A
DAT-Link
at SCSI ID 5 connected to single-
DAT-Link
DAT-Link
was not one
ioscan
-A
