Next - Townshend Computer Tools DAT-Link User Manual

32

2.4.10 NeXT

Manufacturer:
NeXT
Operating System:
Mach 2.0
Cables Required
To connect the NeXT with the
density 50 pin D connector on one end and a 50 pin Centronics type connector on
the other end. This may also be called a SCSI-1 to SCSI-2 cable. It should be
available from your NeXT hardware supplier or can be ordered from your
supplier.
Choosing a SCSI ID
SCSI ID 4 is typically free on NeXT machines for use with tape drives, or devices
DAT-Link
such as the . This corresponds to the device 'st0'. If this ID is already in
use, check with a system administrator to select another ID. The SCSI ID for the
DAT-Link
can be chosen in the range 0 to 6.
Connecting the
DAT-Link
The next step is to connect the
unterminate the SCSI bus temporarily, it is recommended that you shut-down and
turn o the computer before making the connection.
Make sure the Options switches on the rear of the
down. Then connect the
DAT-Link
is the last device on the SCSI bus, be sure to connect the provided SCSI
terminator between the cable and the
Once it is hooked up and powered on you can reboot the computer. If you have
trouble rebooting, verify that the SCSI ID selected on the
that was in use. When the machine is starting up, you should see:
TCT DATLINK as st0 at sc0 target 4 lun 0
in the startup messages, assuming you are using SCSI ID 4.
DAT-Link
The 's SCSI ID switch goes up to 9, but the 8 and 9 settings are only for factory
9
testing. The NeXT itself uses SCSI ID 7
DAT-Link
you will require a cable with a high-
9
DAT-Link
to the computer. Since it is necessary to
DAT-Link
DAT-Link
to the computer using the SCSI cable. If the
DAT-Link
's SCSI connector.
Installation
DAT-Link
are set with all switches
DAT-Link
was not one
