2.4 Machine Speci c Instructions 29
DAT-Link
The above assumes that the resides at SCSI ID 5, on SCSI bus 0. If
another ID was used, replaced the '5' in 'tps0d5nr' above with the appropriate
number. If a di erent bus is used, replace the '0' above by the appropriate bus
number.

2.4.9 IBM PC and Compatibles

Operating System:
5.0, 6.0
DOS
SCSI Adapter:
Adaptec AHA-1540B
Cables Required
The cable required will depend on the type of SCSI adapter installed on your com-
puter. For use with the Adaptec AHA-1540B, you will require a cable with a 50 pin
Centronics type connector on both ends. This may also be called a SCSI-1 cable.
It should be available from your hardware supplier or can be ordered from your
DAT-Link
supplier.
Installing an ASPI Driver
To use these tools, you must have a SCSI adapter installed which supports Adaptec's
ASPI
Advanced SCSI Programming Interface ( ). The software has been tested using
an Adaptec AHA-1540B SCSI Adapter. With this particular adapter, a device
ASPI
driver must be loaded to provide the interface. This is done by adding the
CONFIG.SYS
following line to the le, assuming that Adaptec's software was
C: ADAPTEC
installed in .
n
DEVICE=C:\ADAPTEC\ASPI4DOS.SYS /D
After adding the above command you will need to reboot your computer for the
driver to be loaded.
Choosing a SCSI ID
DAT-Link
Before connecting the , you need to check which SCSI ID's are already in
ASPI4DOS
use on your system. With the device driver loaded as described above,
a list of connected devices will be printed on the console during boot time. Note
DAT-Link
which SCSI ID's are in use and then choose an unused for the . Any ID's
DAT-
between 0 and 6 which do not show a connected device can be used for the
Link DAT-Link
. Note that although the 's ID switch goes up to 9, settings 8 and 9
are reserved for factory testing. ID 7 is usually reserved by the host computer. For
